Stainless Steel 316 Pipe

Stainless Steel 316 Pipe

Stainless Steel 316 Pipe Highlights
Standard Size: 1/8″to 16″
Specifications ASTM A312 | ASME SA312
Schedule SCH 20 to XXS
End Threaded, Beveled, Plain End
Shape Round, Square, Rectangle, Hex
Surface Finish Pickled, Cleaned, Passivated, Precleaned
MTC MTC EN 10204 Type 3.1
Material Group ISO Group M
DN DN 6 to DN 750
Elongation 40%

ASTM A312 TP316 Seamless Material Supplier in India

Stainless Steel 316 Pipe

Stainless Steel 316 Pipe

316 Stainless Steel Seamless Pipe

316 Stainless Steel Seamless Pipe

SS 316 Welded Pipe

SS 316 Welded Pipe


Table of Contents


Stainless Steel 316 Pipe Specification

316 Stainless Steel Seamless Pipe Sizes

  • 6NB – 1200NB
  • OD : 1/8″ – 12″ NPS
  • WT : 0.6 – 12.7 mm
  • Length: Single, Double Random & Cut Length
Sizes

SS 316 Welded Pipe Sizes

  • OD 1/4” – 36”
  • OD 6.35 – 114.3 mm
  • 1/8” – 36” NB
  • WT : 0.8 – 12.7 m
  • Length: up to 26 Meters
Sizes

Stainless Steel 316 Pipe Manufacturing Types

  • EFW
  • Seamless
  • Welded
  • ERW

Types

INOX 316 Round Pipe Surface Finish

  • 2B, 2D, No 4 and Mirror Finish
  • AP (Annealed and Pickled)
  • BA (Bright Annealed)
  • Polished
Surface Finish

UNS S31600 Square Pipe End Types

  • Groove Ends
  • Threaded End
  • Plain End
  • Bevelled End
End Types

DIN 1.4401 Rectangular Pipe Schedule

  • Schedule 80, 60, 120
  • Schedule STD , XXS
  • Schedule 10 , 20 , 40

Schedule

ASTM A312 TP316 Cold Finished Pipe Types

  • Round Pipe
  • Polish Pipe
  • Welded Pipe
  • ERW Pipe
  • Rectangular Pipe
  • Square Pipe
  • EFW pipe
  • Seamless Pipe


Types

316 Stainless Steel Pipe Testing

  • Flaring
  • Ultrasonic
  • Mechanical
  • Chemical
  • Hardness
  • PMI
  • Tensile



Testing

AISI 316 ERW Pipe Standards

  • EN 10088-3
  • EN 10088-2
  • DIN 17458
  • ASME B36.19M
  • EN 10216 – 5
  • EN 10217-7
  • ASME B36.19
  • NSF 61
  • DIN 17456
  • EN 10216 – 2
Standards

INOX AISI 316 Hot Finished Pipe Origin

  • European
  • Janpanese
  • Russia
  • American

Origin

DIN 1.4401 Rectangular Pipe Shapes

  • Square
  • Rectangle
  • Round
  • Hex

Shapes

SA 312 TP 316 Electropolished Pipe Documentation

  • Visual Inspection
  • PMI Test Reports
  • MTC EN 10204 type 3.1
  • Mill Test Certificates
Documentation

SA 312 TP 316 Electropolished Pipe Services

  • Bending
  • Cutting
  • Punching
  • Welding
Services

ASTM A312 TP316 Cold Finished Pipe Fluids

  • Oxygen service
  • Liquids
  • Gasses
  • Corrosive fluids

Fluids

SUS316 Stainless Steel Polished Pipe Packaging

  • Wooden Box
  • Bubble Wraps
  • Bundled


Packaging

Refer AISI 316 SS Welded Pipe Size Chart in mm

Stainless Steel 316 Pipe Size Chart in mm

There Are Several Sizes of Stainless Steel 316 Pipe Available From Indian Supplier.

SS 316 Pipe Outer Daimeter in
(MM)		 Pipe Wall Thickness in
(MM)		 Kg/m SCH Inches.
219.08 8.18 43.20 40S 8
219.08 23.012) 112.97 160 8
168.28 14.27 54.75 120 6
168.28 10.97 43.21 80S 6
141.30 15.882) 49.87 160 5
141.30 9.53 31.44 80S 5
114.30 13.492) 34.05 160 4
114.30 8.56 22.67 80S 4
168.28 7.11 28.69 40S 6
168.28 3.4 14.04 10S 6
114.30 6.02 16.32 40S 4
114.30 3.05 8.50 10S 4
101.60 8.08 18.92 80S 3½
101.60 5.74 13.78 40S 3½
88.90 11.132) 21.67 160 3
88.90 7.62 15.51 80S 3
73.03 7.01 11.59 80S 2½
73.03 3.05 5.35 10S 2½
60.33 8.742) 11.29 160 2
60.33 5.54 7.60 80S 2
21.34 3.73 1.65 80S 1/2
21.34 2.77 1.29 40S 1/2
21.34 2.11 1.02 10S 1/2
17.15 3.20 1.12 80S 3/8
17.15 2.31 0.86 40S 3/8
13.72 2.24 0.64 40S 1/4
13.72 1.65 0.50 10S 1/4

Manufacturer of WNR 1.4401 ERW Pipe Provide Plain and Bevel Ends

Ends Types of AISI 316 ERW Pipe

  • Compression End
  • Plain End
  • Socket Weld End
  • Beveled End
  • Flanged End
  • Threaded End
Check Cold and Hot Rolled 316 Stainless Steel Pipe Roughness and Allowable Stress

Stainless Steel 316 Pipe Roughness

Surface of the Material ɛ Absolute Roughness in mm
316 SS Pipe 0.015

Allowable Stress 316 Stainless Steel Pipe

Strength Mpa Ksi
Tensile Strength 515 Mpa 75 Ksi
ASTM A312 Grade 316 Round Pipe Withstand At Excellent Temperature in Corrosive Environment

316 SS Pipe Temperature Range

Gr. Temperature Range
Stainless Steel 316 Pipe -40 °F to 1600 °F

Welding Electrodes of SA 312 TP 316 Electropolished Pipe

Material Grade of Stick Welding Electrode
SA 312 TP316 Pipe Welding E316

DIN 1.4401 Rectangular Pipe Schedule Chart

NPS (NOMINAL PIPE SIZE) Outer Daimeter SCH 80 SCH 40 SCH 10 SCH 5
4″ 4.5 0.337 0.237 0.12 0.083
3-1/2″ 4 0.318 0.226 0.12 0.083
3″ 3.5 0.3 0.216 0.12 0.083
3/4″ 1.05 0.154 0.113 0.083 0.065
2-1/2″ 2.875 0.276 0.203 0.12 0.083
2″ 2.375 0.218 0.154 0.109 0.083
1-1/4″ 1.66 0.191 0.14 0.109 0.065
1-1/2″ 1.9 0.2 0.145 0.109 0.065
1″ 1.315 0.179 0.133 0.109 0.065
1/2″ 0.84 0.147 0.109 0.083 0.065

Types of 316 Stainless Steel Pipe

Stainless Steel 316 Pipe Supplier in India Offer a Variety of Types and Ends

SUS316 Stainless Steel Polished Pipe

SUS316 Stainless Steel Polished Pipe

AISI 316 ERW Pipe

AISI 316 ERW Pipe

ASTM A312 TP316 Cold Finished Pipe

ASTM A312 TP316 Cold Finished Pipe

SUS 316 EFW Pipe

SUS 316 EFW Pipe

INOX 316 Round Pipe

INOX 316 Round Pipe

SA 312 TP 316 Electropolished Pipe

SA 312 TP 316 Electropolished Pipe

UNS S31600 Square Pipe

UNS S31600 Square Pipe

DIN 1.4401 Rectangular Pipe

DIN 1.4401 Rectangular Pipe

INOX AISI 316 Hot Finished Pipe

INOX AISI 316 Hot Finished Pipe

ASTM A312 TP316 Cold Finished Pipe Gauge Chart

OD in (INCHES) Size in (INCHES) Guage Chart
SCH 160S SCH 80S SCH 40S SCH 10S SCH 5S
12.750 12" 0.500 0.300 0.250 0.090 0.090
10.750 10" 0.500 0.300 0.250 0.090 0.090
8.625 8" 0.500 0.300 0.250 0.090 0.090
6.625 6" 0.375 0.250 0.200 0.090 0.090
5.563 5" 0.375 0.250 0.200 0.090 0.090
4.500 4" 0.250 0.180 0.140 0.065 0.065
3.500 3" 0.250 0.180 0.140 0.065 0.065
2.875 2-1/2" 0.250 0.180 0.140 0.065 0.065
2.375 2" 0.250 0.180 0.140 0.065 0.065
1.050 3/4" 0.250 0.180 0.140 0.065 0.065
1.660 1-1/4" 0.250 0.180 0.140 0.065 0.065
1.900 1-1/2" 0.250 0.180 0.140 0.065 0.065
1.315 1" 0.250 0.180 0.140 0.065 0.065
0.840 1/2" 0.250 0.180 0.140 0.065 0.065
0.540 1/4" 0.250 0.180 0.140 0.065 0.065

Surface Finish of UNS S31600 Square Pipe

Surface Finish Exterbal Surface (OD) Internal Surface (ID)
RA (Roughness Average) RA (Roughness Average)
μm μ inch μm μ inch
Electro Polish EP 0.8 32 0.38,0.25,0.20;0.13 15,10,7,5
Mechanical Polish MP 0.8 32 1.0,0.8,0.6,0.5 40,32,25,20
Beight Annealed BA 0.8 32 1.0,0.8,0.6,0.5 40,32,25,20
Annealed and Pickled AP 1.0 or Not Defined 40 or Not Defined Not Defined Not Defined

316 Stainless Steel Pipe Weight Chart

Nominal Size Outer Daimeter WT Weight Weight
MM INCHES MM INCHES Lb/ft kg/Mtr
48″ 1219 48.000 9.525 0.375 190.738 284.112
42″ 1067 42.000 7.925 0.312 138.911 206.914
36″ 914 36.000 6.350 0.250 95.453 142.180
30″ 762 30.000 6.350 0.250 79.433 118.318
24″ 610 24.000 6.350 0.250 63.413 94.456
20″ 508 20.000 6.350 0.250 52.733 78.547
18″ 457 18.000 5.563 0.219 41.588 61.948
16” 406 16.000 4.775 0.188 21.748 47.290
14″ 356 14.000 4.775 0.188 27.732 41.308
12″ 324 12.750 4.775 0.188 25.222 37.570
10″ 273 10.750 4.775 0.188 21.207 31.588
8″ 219 8.625 4.775 0.188 16.940 25.233
6″ 168 6.625 4.775 0.188 12.924 19.252
4″ 114 4.500 6.020 0.237 10.790 16.073
3″ 89 3.500 5.486 0.216 7.576 11.284
3/4″ 27 1.050 2.870 0.113 1.131 1.684
2 1/2″ 73 2.875 5.516 0.203 5.793 8.629
2″ 60 2.375 3.912 0.154 3.653 5.441
1 1/4″ 42 1.660 3.556 0.140 2.273 3.385
1 1/2″ 48 1.900 3.683 0.145 2.718 4.048
1″ 33 1.315 3.378 0.133 1.679 2.501
1/2″ 21 0.840 2.769 0.109 0.851 1.268

Hardness of SUS316 Stainless Steel Polished Pipe

Hardness Metric English
Vickers 155 155
Brinell 149 149
Rockwell B 80 80

Applications of Stainless Steel 316 Pipe

Applications of Stainless Steel 316 Pipe

316 Stainless Steel Seamless Pipe Tolerance Chart

Outside Daimeter of 316 SS Pipe Tolerance of SA 312 TP 316 Pipes
60 & above +/- 0.25 (MM)
38 to 60 (MM) +/- 0.20 (MM)
35 to 38 (MM) +/- 0.15 (MM)
4 to 35 (MM) +/- 0.08 (MM)

316 SS Pipe Chemical Composition

Grade Mo, (Molybdenum) Ni, (Nickel) N, (Nitrogen) Si, (Silicon) Mn, (Manganese) S, (Sulfur) Cr, (Chromium) C, (Carbon) P, (Phosphorous)
Min Max Min Max Max Max Max Max Min Max Max Max
316 SS Pipe 2.0 3.0 10.0 14.0 0.10 0.75 2.0 0.03 16.0 18.0 0.08 0.045

Stainless Steel 316 Pipe Mechanical Properties

Gr. Elongation in (% 50 MM) Min Yield Strength in 0.2% Proof (MPa) Min Tensile Strength in (MPa) Min Hardness
Brinell (HB) Max Rockwell B (HR B) Max
SS 316 Pipe 40 % 205 MPa 515 MPa 95 217

Physical Properties of SA 312 TP 316 Electropolished Pipe

Properties Values
Density 8.0 g/cm³
Modulus of Elasticity 193 GPa
28,000 ksi
Specific Heat 500 J/kg·K at 25°C
Poisson’s Ratio 0.27 to 0.30
Melting Point 1375 to 1400°C (2500 to 2550°F)
Coefficient of Thermal Expansion 16.0 µm/m·K
Electrical Resistivity 0.72 µΩ·m
Thermal Conductivity 16.3 W/m·K at 100°C

ASTM A312 TP316 Cold Finished Pipe Equivalent Grades

Grade BS WERKSTOFF NR. JIS AFNOR ASTM GOST UNS
SS 316 Pipe 316S31 / 316S33 1.4401 / 1.4436 SUS 316 Z7CND17‐11‐02 ASTM A312 08KH16N11M3 S31600

Value Added Services of Stainless Steel 316 Pipe

Value Added Services of Stainless Steel 316 Pipe

316 SS Pipe Pressure Rating

316 SS Pipe Outside Daimeter in (Inches) Working Pressure in (Pounds Per Square Inch Gauge) Weight in (kg/m) Pipe Wall (Inches)
5/8 2 900 0.45 0.049
4000 0.58 0.065
3/8 6 500 0.32 0.065
4 800 0.25 0.049
3 300 0.19 0.035
3/4 2 400 0.56 0.049
3 300 0.71 0.065
1/8 8 500 0.04 0.028
10 900 0.05 0.035
1/6 8 100 0.01 0.014
12 000 0.01 0.020
1/4 10 200 0.19 0.065
7 500 0.16 0.049
5 100 0.12 0.035
1/2 5 100 0.45 0.065
2 600 0.26 0.035
6 700 0.55 0.083
3 700 0.35 0.049
1 3 100 1.2 0.083

Heat Treatment of SUS 316 ERW Pipe

Grade SS 316 Pipe Finish Heating Temprature UNS
316 SS Pipe Cold 1040 °C, 1900 (°F) S31609
Hot 1040 °C, 1900 (°F) S31610

Stainless Steel 316 Pipe Dimensions

An Indian Manufacturer of SS 316 Pipe Provides Pipes in Numerous Dimensions

Sizes Wall / OD Wt./Ft.
105 1/8" * .010 0126
101 1/8" * .012 .0149
.093 1/8" * .016 .0191
.085 1/8" * .020 0231
.069 1/8" * .028 .0298
062 3/32" * .016 .0136
.055 1/8" * .035 .0346
.054 3/32" * .020 .0162
.042 1/16" *.010 .0057
.038 3/32" * .028 .0202
.030 1/16" * .016 .0080
.022 1/16" * .020 .0092

Test Certificates of ASTM A312 TP316 Seamless Pipe

Test Certificates of ASTM A312 TP316 Seamless Pipe

Stainless Steel 316 Pipe HSN Code

Grade HSN Code
SS 316 Pipe 73061000

Manufacturing Process of 316 Stainless Steel Seamless Pipe

  • Heat Treatment
  • Preparing Material
  • Inspection
  • Welding & Sizing
  • Pipe Formation
