Table of Contents


Aperam Heavy Plates Available In All Grades Of Stainless And Duplex Steel Material

Aperam Plate Specification

Product

  • Plate
  • Coil
  • Sheet
  • Strip


Product

Grades

  • DX2202 / 1.4062
  • DX2507 / 1.4410
  • DX2304 / 1.4362
  • DX1803 / DX2205 / 1.4462
  • DX2101 / 1.4162

Grades

Surface Finish

  • Sand blasted
  • Buffing Bright
  • Satin Finish
  • Mirror polished
  • matt finish
  • Tin-coated finish
Finish

Aperam Duplex DX2205 Sheet and Coil Size Chart

  Size range
Surface condition Width (mm) Thickness (mm)
Ferritic stainless steels
key for value		 HRAP 1,000 1.50 - 2.49
1,524 3.00 - 6.50
1,250 2.50 - 2.99
2B - 2D 1,524 0.60 - 4.00
1,250 0.40 - 0.59
2R 1,000 0.30 - 0.39
1,500 0.70 - 2.00
1,250 0.40 - 0.69
Duplex HRAP 2,000 7.00 - 10.00
1,500 4.00 - 10.00
2B - 2E 2,000 2.00 - 6.00
1,500 1.00 - 6.00
Austenitic stainless steels HRAP 2,000 5.00 - 13.00
1,250 2.50 - 2.99
1,000 1.85 - 2.49
1,524 3.00 - 4.99
HRC 2,000 4.00 - 4.99
2B - 2D 1,250 0.40 - 0.59
1,524 0.80 - 0.99
  2 000
1 000		 1.00 - 8.00
0.30 - 0.39
2R 1,250 0.40 - 0.79
  1,524 0.80 - 2.00
Heat resisting stainless steels HRAP 1,250 3.50 - 7.99
2,000 8.00 - 13.00
2D - 2B 1,250 0.40 - 0.79
2,000 1.50 - 8.00
Martensitic stainless steels 2B - 2H 1,000 0.40 - 3.50

Stockholder Of Aperam Precision Strip Stock In Hot And Cold Rolled Process

Dimension Of Aperam Plate

Hot Rolled Steels Cold Rolled Steels
Steel Grade Thickness (mm) Width (mm) (1) Thickness (mm) Width (mm) Length (mm)
301 3,00 to 6,35 1219 to 1270 0,40 to 3,50 1000 to 1270 1000 to 6100
304H 2,60 to 50,80 1000 to 1540 0,40 to 3,50 1000 to 1540
304/304L 2,60 to 50,80 1000 to 1540 0,40 to 5,00 1250 to 1270
310S 4,00 to 50,80 1000 to 1540 0,40 to 3,50 1000 to 1540
304DDQ (2) 2,85 to 6,00 1000 to 1270 0,40 to 2,50 1000 to 1270
317 4,00 to 50,80 1000 to 1320 0,40 to 3,50 1000 to 1270
316/316L 2,60 to 50,80 1000 to 1540 1,00 to 3,00 1000 to 1040
347 2,85 to 50,80 1000 to 1540 0,40 to 3,09 1000 to 1270
321 3,00 to 50,80 1000 to 1540 0,40 to 3,50 1000 to 1320
K03 3,00 to 50,80 1200 to 1520 0,60 to 3,50 1000 to 1240
K09/K09M 2,60 to 8,00 1000 to 1270 1,00 to 3,09 1000 to 1270
K30 3,00 to 3,49 1000 to 1320 0,40 to 0,80 1000 to 1320
420 3,50 to 8,00 1200 to 1240 0,40 to 3,00 1000 to 1320
K44 3,00 to 6,00 1200 to 1270 0,40 to 3,09 1000 to 1270
K39MD 3,00 to 5,00 1000 to 1270 0,40 to 3,09 1000 to 1270
2205 3,50 to 50,80 1000 to 1540 1,20 to 3,00 1000 to 1320
498 2,85 to 8,00 1000 to 1040 0,40 to 3,00 1000 to 1270
2304 3,50 to 50,80 1000 to 1540 1,20 to 3,00 1000 to 1320

Aperam DX1803 Coil Allowable Stress

Thickness (mm) Allowable Tolerances (mm)
2,60 ≤ and < 3,00 ± 0,20
3,50 ≤ and < 4,00 -0,25 / +0,30
3,00 ≤ and < 3,50 ± 0,24
4,00 ≤ and < 5,00 -0,25 / +0,33
5,00 ≤ and < 6,50 -0.25 +0.38
9,00 < and ≤ 10,00 +1.14
12,00 < and ≤ 20,00 +1.40
25,40 < and < 50,00 +1.78
50.80 +3.20
Aperam Stainless Steel Coils & Sheets Available in HRAP, 2B, NR.1, 2R And 2D Finish

Aperam DX2304 Hot Rolled Plates Surface Finish

  • Sand blasting
  • Polished
  • HRC
  • Bright annealed
  • 2R
  • Satin
  • 2D
  • Embossed
  • HRAP
  • 2B
Aperam Duplex Hot-rolled Plate Stocks In 0.3 To 13 mm Thickness In Grade DX2205, DX1803, DX2304

Aperam DX2304 Strip And Coil Thickness

Thickness (mm) Max. width (mm) Min. width (mm)
0.3 ≤ t < 0.4 1,000 8
0.4 ≤ t < 0.7 1,250 8
1.0 1,524 10
1.5 2,000 10
2.0 2,000 10
4.0 2,000 15
10.0 2,000 30
13.0 2,000 40

Thickness Of Aperam Stainless Steel DX2202 Plate

Thickness in mm Min. width in mm Max. width in mm
0.30 - 0.74 80 1,250
0.75 - 2.00 80 1,524
2.01 - 8.00 LAF 670 2,000
3.00 - 13.00 LAC 500 2,000

Applications Of Aperam DX1803 Cold Rolled Sheet

Applications Of Aperam DX1803 Cold Rolled Sheet

Width Tolerance Aperam DX2304 Hot Rolled Plates

Width (mm)
Thickness (mm)		 Width Tolerance (1)
150 to
199		 12 to 149 300 to
499		 200 to
299		 600 to
1300		 500 to
599
1,76 ≤ and ≤ 2,50 0.25 0.20 0.40 0.25 +1.0 0.50
0,40 ≤ and ≤ 1,75 0.13 0.13 0.40 0.25 +1.0 0.50
2,51 < and ≤ 3,50 0.40 0.25 0.50 0.40 +1.0 0.50

Aperam DX180 Cold Rolled Plates Thickness Tolerance

Thickness (mm) Tolerance (mm)
0,81 ≤ and ≤ 1,00 ± 0,055
0,60 ≤ and ≤ 0,80 ± 0,05
0,40 ≤ and < 0,60 ± 0,04
1,51 < and ≤ 2,50 ± 0,10
3,01 < and ≤ 4,00 ± 0,17
1,01 < and ≤ 1,50 ± 0,08
2,51 < and ≤ 3,00 ± 0,13

Length Tolerance Of Aperam DX2304 Hot Rolled Plates

Material Edge Type Tolerance Max Diff between diagonals (mm)
Squared plates Slitted - 0,0 / +2,0 3.0
Non-squared plates Mill edge - 0,0 / +7,0 –
Slitted 5.0

Chemical Compositions Of Aperam Stainless Steel Sheet

Aperam ASTM DIN Mn C N Si S P Ni Cr Mo
UNS AISI
P301A S30100 301 1.4310 2.00 0.05 0.10 1.00 0.015 0.045 6,0 to 8,0 16,0 to 18,0 -
P301F S30153 301LN - 2.00 0.03 0,07 to 0,20 1.00 0.030 0.045 6,0 to 8,0 16,0 to 18,0 -
P304A / B S30400 304 1.4301 2.00 0.07 0.10 0.75 0.015 0.045 8,0 to 10,5 17,5 to 19,5 -
P304C/D S30403 304L 1.4307 2.00 0.03 0.10 0.75 0.015 0.045 8,0 to 10,5 17,5 to 19,5 -
P304N (1) S30400 304 1.4301 2.00 0.07 0.10 0.75 0.015 0.045 8,0 to 10,5 17,5 to 19,5 -
P304H S30409 304H - 2.00 0,04 to 0,10 - 0.75 0.03 0.045 8,0 to 10,5 18,0 to 20,0 -
P316A S31600 316 1.4401 2.00 0.07 0.10 0.75 0.015 0.045 10,0 to 13,0 16,5 to 18,0 2,00 to 2,5
P304T (1) S30400 304T 1.4301 2.00 0.03 0.10 0.75 0.015 0.045 9,0 to 10,5 17,5 to 19,5 -
P316B S31603 316L 1.4404 2.00 0.03 0.10 0.75 0.015 0.045 10,0 to 13,0 16,5 to 18,0 2,00 to 2,5
P317A S31703 317L - 2.00 0.03 0.10 0.75 0.03 0.045 11,0 to 15,0 18,0 to 20,0 3,0 to 4,0
P310A S31008 310S/H 1.4845 2.00 0,035 to 0,08 - 1.50 0.015 0.045 19,0 to 22,0 24,0 to 26,0 -
P347A S34709 347/H - 2.00 0,04 to 0,08 0.02 0.75 0.03 0.045 9,0 to 13,0 17,0 to 19,0 -
P321A S32100 321 1.4541 2.00 0.08 0.10 0.75 0.015 0.045 9,0 to 12,0 17,0 to 19,0 -
K03 - - 1.4003 1.50 0.03 0.03 1.00 0.015 0.04 1.00 10,5 to 12,5 -
K09M/ S40920 409 14512 1.00 0.03 0.03 1.00 0.015 0.035 0.50 10,50 to 11,7 -
K09 S40910 409 1.4512 1.00 0.03 0.030 1.00 0.015 0.04 0.50 10,50 to 11,7 -
K30MD (2) S43000 - 1.4016 1.00 0.08 - 1.00 0.015 0.04 0.75 16,0 to 18,0 -
K30 S43000 430 1.4016 1.00 0.08 - 1.00 0.015 0.04 0.75 16,0 to 18,0 -
K39MD S43932 - - 1.00 0.03 0.030 1.00 0.015 0.04 0.50 17,0 to 19,0 -
K44 S44400 - 1.4521 1.00 0.025 0.035 1.00 0.03 0.04 1.00 17,5 to 18,5 1,75 to 2,50
K41 - - 1.4509 1.00 0.03 0.030 1.00 0.015 0.04 0.50 17,5 to 18,5 -
P498V - - 1.4116 1.00 0,45 to 0,55 - 1.00 0.015 0.04 - 14,0 to 14,5 0,50 to 0,80
P420A S42000 420 1.4028 1.00 0,15 min - 1.00 0.03 0.04 0.75 12,0 to 14,0 0.50
P399B S32205/ S31803 - 1.4462 2.00 0.03 0,14 to 0,20 1.00 0.015 0.03 4,50 to 6,50 22,0 to 23,0 3,00 to 3,50
P398A S32304 - 1.4362 2.00 0.03 0,05 a 0,20 1.00 0.015 0.035 3,50 to 5,50 22,0 to 24,0 0,10 to 0,60
P298A S20100 201 1.4618 5,50 to
7,50		 0.15 0.25 1.0 0.03 0.06 3,5 to 5,5 16,0 to 18,0 -
P201F S20153 201LN 1.4376 6,40 to
7,50		 0.03 0,15 to 0,25 0,20 to
0,60		 0.015 0.045 4,0 to 4,5 17,0 to 17,5 -

Standards Of Aperam Plate

Grade designations Standards
AISI EN UNS
Austenitic stainless steels
containing manganese		 Aperam 201 (16-4Mn) 201 1.4372 S20100
Aperam 201LN (16-5MnL) 201LN 1.4371 S20153
Aperam 201D (17-4Mn) 201-1 1.4618 S20100
Ferritic stainless steels K03 (F12N)   1.4003 S41003
K09 (F12T) 409 1.4512 S40900
K30 (F17) 430 1.4016 S43000
K09D (F12TD) 409 1.4512 S40900
K09X (F12T) 409 1.4512 S40900
K30H (F17) 430 1.4016 S43000
K30ED (F17) 430 1.4016 S43000
K39 (F18T) 439 1.4510 S43035
K33X (FNT) 433 1.4513 S43690
K36 (F17MNb) 436 1.4526 S43600
K36X (F17MNb) 436 1.4526 S43600
K41 (F18TNb) 441 (1) 1.4509 S43932/S43940
K39M (F17T) 430Ti 1.4510 S43037
K44M (F19MNb) 444 1.4521 S44400
K41X (F18TNb) 441 (1) 1.4509 S43932
K44 (F18MT) 444 1.4521 S44400
K45 (F20NbCu) 445 (1) 1.4621 S44500
K44X (F19MNb) 444 1.4521 S44400
Duplex DX1803 22-05 1.4462 S31803
DX2205 22-05 1.4462 S32205
DX2202 22-02 1.4062 S32202
DX2304 23-04 1.4362 S32304
Austenitic stainless steels
containing molybdenum		 Aperam 316T (17-11MT) 316Ti 1.4571 S31635
Aperam 316C (18-12MS) 316L 1.4432 S31603
Aperam 316B (18-13MS) 316L 1.4435 S31603
Aperam 316L (18-11ML) 316/316L 1.4401/1.4404 S31600/S31603
Austenitic stainless steels Aperam 301R (17-7E) (301) 1.4310 S30100
Aperam 301L (18-7L) 301L/301LN 1.4318 S30103/S30153
Aperam 301 (17-7A) 301 1.4310 S30100
Aperam 301M (17-7C) 301 1.4310 S30100
Aperam 304D (18-9ED) 304 1.4301 S30400
Aperam 304 (18-9E) 304 1.4301 S30400
Aperam 304L (18-9L) 304L 1.4307 S30403
Aperam 304ED (18-9DDQ) 304 1.4301 S30400
Aperam 304H (18-9H) 304H 1.4301/1.4948 S30409
Aperam 305 (18-12D) 305 1.4303 S30500
Aperam 304M (18-10L) 304L 1.4306 S30403
Aperam 321H (18-10TH) 321H 1.4541/1.4878 S32109
Aperam 321 (18-10T) 321 1.4541 S32100
Martensitic stainless steels Aperam MA2   1.4021
Aperam MA3 420 1.4028 S42000
Aperam MA4   1.4034
Aperam MA3M   1.4419
Aperam MA5
Heat resisting stainless steels Aperam 309S (R24-13S) (2) 309S / 309H 1.4833 S30908
Aperam 309 (R20-12)   1.4828

Aperam Precision Strip Mechanical Properties

Aperam Mechanical properties
Yield strength (MPa) Strength limit (MPa) Rockwell - B Hardness Elongation 50mm (%) Erichsen cup test (mm) Cold bending
P301F 400 700 90 50 - 180º
P301A 320 910 86 46 13 180°
P304C/D 320 690 80 51 12 180°
P304A / B 320 720 84 57 12 180°
P304N (1) 280 600 75 58 12 180º
P304T (1) 280 610 74 58 12 180º
P316A 340 650 82 51 12 180°
P304H 320 710 83 58 - 180º
P317A 330 650 87 45 - 180º
P316B 340 650 82 51 12 180°
P321A 260 670 78 42 12 180°
P310A 380 600 83 42 - 180º
K03 280 475 80 30 - 180°
P347A 345 645 87 51 - 180º
K09M/ 245 410 67 40 10 180°
K09 250 420 67 40 10 180°
K30MD (2) 330 480 79 31 10 180°
K30 350 520 81 30 9 180°
K41 295 460 77 35 10 180°
K39MD 305 460 76 34 10 180°
K44 350 520 83 31 9 180°
P498V - - 100 - - -
P420A 370 620 87 26 - -
P399B 660 840 98 27
P398A 560 740 96 30 - -
P298A 260 515 - 40 - -
P201F 500 700 95 45 - -

Aperam Heavy Plates Physical Properties

Aperam Physical Properties
Heat Conductivity 100 °C
(w/m.K)		 Average Heat Expansion Coefficient (µ/m °C) Specific Heat 0-100 °C (J/Kg.K) Density (g/cm2) Electric Resistivity at Room Temperature (nΩ.m) Modulus of Rigidity (GPa) Modulus of Elasticity (GPa)
P301A 16.2 17.5 500 8.0 720 86.2 193
P304A / B 16.2 17.8 500 8.0 720 86.2 193
P301F 16.2 17.5 500 8.0 720 86.2 193
P304T (1) 16.2 17.8 500 8.0 720 86.2 196
P304C/D 16.2 17.8 500 8.0 720 86.2 193
P304H 16.2 17.8 500 8.0 720 86.2 193
P304N (1) 16.2 17.8 500 8.0 720 86.2 196
P316B 16.2 16.5 500 8.0 740 86.2 193
P316A 16.2 16.5 500 8.0 740 86.2 193
P310A 14.2 16.5 500 8.0 780 86.2 200
P317A 14.4 17.5 500 8.0 790 86.2 200
P347A 16.1 17.5 500 8.0 730 86.2 193
P321A 16.1 17.5 500 8.0 720 86.2 193
K03 24.9 11.0 460 7.8 570   200
K09M/ - 11.7 - 7.8 - - -
K09 - 11.7 - 7.8 - - -
K30MD (2) 26.1 10.9 460 7.8 600 86.2 200
K30 26.1 10.9 460 7.8 600 86.2 200
K41 - - - - - - -
K39MD 24.2 10.9 460 7.8 630 86.2 200
K44 26.8 10.7 420 7.8 620 86.2 200
P498V       7.8
P420A 24.9 10.9 460 7.8 550 81 200
P399B 16 14.3 460 7.8 800 86.2 200
P398A 17 13.5 450 7.8 800 86.2 200
P298A 16.2 17.1 500 7.8 690 86.2 197
P201F 16.2 17.1 500 7.8 690 86.2 197
