• An ISO 9001 and ISO 14001 Certified Company
Steber Steel Solutions

Tubacex Pipe Distributor

Tubacex Pipe Distributor

Stockist Of Tubacex Mechanical Tubing Available in Cold Drawn Process in India

Tubacex Pipe Process

  • Mechanical trepanning
  • Hot-finished
  • Cold-finished
  • Welded and drawn pipes

Table of Contents


Tubacex Pipe Specification

Material

  • Stainless steels
  • Alloyed and martensitics steels
  • High Nickel alloys
  • Duplex and Superduplex


Size

Process

  • Hot-finished
  • Cold-finished
  • Welded and drawn
  • Mechanical trepanning


Thickness

Manufacturing Unit

  • TUBACEX Durant - Durant
  • Tubacex India- India
  • Schoeller-Bleckmann - Austria
  • Salem Tube - U.S.A
  • Tubacex Tubos Inoxidables - Spain
Length

Manufacturing Standards

  • GOST
  • BS
  • UNE
  • JIS







Size

Forms

  • Hollow
  • Tube
  • Pipe
  • Bars and Billets







Thickness

Ex Stock

  • Medium & High Pressure Tubes
  • OCTG Tubing
  • Instrumentation Tubing
  • Coiled Tubing
  • Hydraulic Tubing
  • Heat Exchanger Tubing
  • Line Pipe
  • Nuclear & Power Generation Tubing
  • Precision Tubing
  • Mechanical/DOM Tubing
Length

Dealer Of Tubacex High Pressure Stainless Steel Tubing Stock In 304, 316, 317, 904L Grades in Mumbai

Tubacex High Pressure Stainless Steel Tubing Available Grades

AUSTENITIC STAINLSS STEEL SUPER AUSTENITIC STAINLSS STEEL DUPLEX NICKEL ALLOYS PH GRADES
  • 304 / 304L
  • 310
  • 316 / 316L
  • 316L
  • 317 / 317L
  • 321
  • 347 / 347H
  • 904L
  • 6Mo
  • 2205
  • 2507
  • 25Cr SDSS
  • Alloy 200/201
  • Alloy 400
  • Alloy 600
  • Alloy 617
  • Alloy 625
  • Alloy 690
  • All0y 718
  • Alloy 825
  • Monel K500
  • 15-5
  • 17-4
  • 17-7

Tubacex Super Duplex OCTG Tubing Stock Size 2-3/8 to 9-5/8 Inch with Sour Service Performances

TUBACEX Coiled Tubing Imperial Sizes

IMPERIAL (IN) LENGTH
OD WALL M FT
1/4 0.028 336 1,103
1/4 0.049 252 826
1/4 0.065 205 673
3/8 0.049 157 514
3/8 0.065 124 407
4/9 0.035 149 489
4/9 0.065 89 291
5/8 0.035 122 401
5/8 0.065 69 226
3/4 0.049 74 242
3/4 0.083 45 148
1 0.065 42 137
1 0.109 26 86
1 0.134 21 70

Sizes Of Tubacex Medium And High Pressure Tubing

IMPERIAL
OD (IN) ID (IN) PRESSURE (PSI) WALL (IN)
1/4 ”
0.243”/0.248”		 0.125 15,000 0.063
0.083 60,000 0.084
3/8”
0.365”/ 0.370”		 0.219 15,000 0.078
0.125 60,000 0.125
  0.359 10-15,000 0.102
9/16”
0.552”/ 0.557”		 0.344 15,000 0.109
0.250 40,000 0.156
  0.187 60,000 0.188
  0.516 10-15,000 0.117
3/4”
0.740”/ 0.745”		 0.437 20,000 0.157
  0.250 60,000 0.250
  0.688 10,000 0.156
1”
0.990”/ 0.995”		 0.656 15,000 0.172
  0.438 30-43,000 0.281

Aprroval And Certifications Of Tubacex Subsea Umbilicals

  • ASME / NCA-3800
  • ASTM A789
  • ISO 9001:2008
  • ANST SNT-TC-1A
  • ASME B31.3
  • NORSOK M-650
  • ISO/DIS 13628-5
  • ASTM A1016
  • NAS 1638
  • SAE AS 4059
  • PED 97/23/EC
  • ISO 17025
Stockholder Of Tubacex Instrumentation Tubes According To MIL-T, ASTM and AMS Specifications

Ready To Dispatch Stock Of TUBACEX Pipe

Tubacex Heat Exchanger Tubing

Tubacex Heat Exchanger Tubing

Tubacex High-pressure Stainless Steel Tubing

Tubacex High-pressure Stainless Steel Tubing

Tubacex Medium Pressure Stainless Steel Tubing

Tubacex Medium Pressure Stainless Steel Tubing

Tubacex Heat Exchanger Tube

Tubacex Heat Exchanger Tube

Tubacex Hydraulic Tubes

Tubacex Hydraulic Tubes

Tubacex Instrumentation Tubes

Tubacex Instrumentation Tubes

Tubacex Boiler Tubes

Tubacex Boiler Tubes

Tubacex Line Pipes

Tubacex Line Pipes

Tubacex Coiled Tubing

Tubacex Coiled Tubing

Tubacex Precision Tubing

Tubacex Precision Tubing

Tubacex Mechanical Tubing

Tubacex Mechanical Tubing

Tubacex DOM Tubing

Tubacex DOM Tubing

Buy Tubacex Hydraulic Tubing Extremely Smooth Finishes For Aerospace Application

Applications Of TUBACEX DSS Hydraulic Tubes

Applications Of TUBACEX DSS Hydraulic Tubes

TUBACEX Hydraulic and Instrumentation Tubing Services

  • 100% Eddy-Current
  • 100% PMI Tested
  • Bright Annealed
  • 100% Hydrostatic Tested
  • Controlled Dimensional Tolerances
    • High Roundness
    • Fixed Lengths
    • End Capped
    • High Cleanliness
    • Controlled Hardness

Working Pressure Chart For Tubacex Seamless Tubing

WALL THICKNESS (MM)
1.0 1.5 1.8 2.0 2.5 2.8 3.0 4.0 5.0
OUTSIDE DIAMETER (MM) 6 461 741
10 264 412 506 571
12 218 337 413 465
16 161 247 301 338
18   218 265 297 380 431
22   177 214 240 305 346 373
25   155 187 210 266 301 324
30       170 210 240 260
32   160 200 220 240 330
50             150 210 270

Tubacex High Pressure Tube Chemical Composition

GRADE ELEMENTS (TYPICAL VALUES) IN %
C Si Cr Ni Mn Mo P Fe
310 MAX 0.25 1,50 25,0 20,0 2,0 -- MAX 0.045
304 / 304L MAX 0.03 0,50 18,5 10,2 1,3 -- MAX 0.030
316 / 316L MAX 0.03 0,40 17,0 12,0 1,7 2,2 MAX 0.040
317 / 317L MAX 0.03 0,75 19,0 13,5 2,0 3,5 MAX 0.045
316L (2.5 Min Mo) MAX 0.03 0,40 17,0 12,0 1,7 2,7 MAX 0.040
347 / 347H MAX 0.08 0,75 18,0 11,0 2,0 -- MAX 0.045
321 MAX 0.08 0,75 17,5 11,0 2,0 -- MAX 0.045
904L MAX 0.02 1,00 20,0 25,0 2,0 4,5 MAX 0.045
2205 MAX 0.03 1,00 22,5 5,5 2,0 3,0 MAX 0.030
6Mo MAX 0.02 0,80 20,0 18,0 1,0 6,25 MAX 0.030
2507 MAX 0.03 0,80 25,5 7,0 1,2 3,5 MAX 0.025
25Cr SDSS MAX 0.03 1,00 25,5 7,0 1,0 3,5 MAX 0.030
Alloy 400 MAX 0.03 0,50 -- 64 2,00 -- MAX 0.024
Alloy 200/201 MAX 0.15 0,35 -- 99* 0,35 -- MAX 0.010
Alloy 617 MAX 0.15 1,00 22,0 45 1,00 9,0 MAX 0.015
Alloy 600 MAX 0.15 0,50 15,0 72* 1,00 -- MAX 0.015
Alloy 625 MAX 0.03 0,50 21,5 59 0,50 9,0 MAX 0.015
All0y 718 MAX 0.08 0,35 18,0 52* 0,35 3,0 MAX 0.015
Alloy 690 MAX 0.05 0,50 29,0 59 0,50 -- MAX 0.015
Monel K500 MAX 0.25 0,50 -- 63* 1,50 -- MAX 0.010
Alloy 825 MAX 0.03 0,50 21,5 41 1,00 2,7 MAX 0.030
15-5 MAX 0.07 MAX 1.0 14,48 4,5 MAX 1.0 3,5 MAX 0.03 75
17-7 MAX 0.09 MAX 1.0 16-18 6.50 -
7.75		 MAX 1.0 -- MAX 0.03 BALANCE
17-4 MAX 0.07 MAX 1.0 15.0-17.5 3.0–5.0 MAX 1.0 3.0–5.0 MAX 0.03 73

Mechanical Properties Of Tubacex Super Duplex Hydraulic Tubes

GRADE MECHANICAL PROPERTIES AT ROOM TEMP
TENSILE RM MIN (MPA) YIELD RP 0.2MIN (MPA) MAX HARDNESS Elong. (%)
304 / 304L 515 205 90 40
316 / 316L 515 220 90 40
310 550 245 93 45
316L (2.5 Min Mo) 515 220 90 40
321 515 205 90 40
317 / 317L 515 205 95 40
347 / 347H 515 205 93 40
904L 530 230 190 35
6Mo 650 300 210 35
2507 800 550 32 20
2205 680 450 28 40
25Cr SDSS 752 552 28 25
Alloy 400 585 195 75 32
Alloy 200/201 380-550 105-275 75 60-40
Alloy 617 758 383 193 56
Alloy 600 550-690 170-345 88 55-35
Alloy 625 690 276 200 30
All0y 718 1276 1034 36 4
Alloy 690 758 461 190 39
Monel K500 621-758 276-448 90 45-25
Alloy 825 586 241 240 30
15-5 1380 1275 104 10
17-7 1170 965 38 6

Tubacex Pipe International Standards

GRADE UNS EN NUMBER EN NAME JIS ASME ASTM MIL-T AMS
304 / 304L S30400 / S30403 1.4301/1.4306 X2CrNi19-11 SUS304 / 304L SA213 A213, A269, A270, A312, A450, A511, A632, A908, A1016, F899 5695,6845,
8504, 8506, 8606, 8973		 5560, 5564, 5566, 5567, 5569,
5647, 5868, 6845, 8506
310 S31000 / S31008 1,434 X15CrNiSi2520 SUH310 SA312
316 / 316L S31600 / S31603 1.4401/1.4404 X2CrNiMo17-12-2 SUS316 / 316L SA213 A213, A269, A270, A312, A450, A511, A632, A1016, F899 8973 5573, 5584
316L (2.5 Min Mo) S31600 / S31603 1,440 X2CrNiMo17-12-2 SUS316 / 316L SA213 A213, A269, A270, A312, A450, A511, A632, A1016, F899 8973 5573, 5584
317 / 317L S31700 / S31703 1,444 X2CrNiMo18-15-4 SUS317 / 317L SA213 A213, A269, A312, A450, A511, A632, A1016
321 S32100 1,454 X6CrNiTi18-10 SUS321 SA213 A213, A269, A312, A450, A511, A632, A1016 8606, 8808, 8973 5557, 5570, 5576, 5645, 5896
347 / 347H S34700 / S34709 1.4550/1.4961 X6CrN-iNb18-10 SUS347 SA213 A213, A269, A312, A450, A511, A632, A1016 8606, 8808, 8973 5556, 5571,
5646, 5897
904L N08904 1,454 X1NiCrMoCu25-20-5 QS 2025 MC SA213 A213, A269, A312, A1016 -- --
6Mo S31254 1,455 X1CrNiMoCuN20-18-7 -- SA213 A213, A269, A1016 -- --
2205 S31803 1,446 X2CrNiMoN2253 QS 2205 SA789 A789 -- --
2507 S32750 1,441 X2CrNiMoN25-7-4   SA789 A789 -- --
25Cr SDSS S32760 1,450 X2CrNiMoCuWN25-7-4 -- SA789 A789 -- --
Alloy 200/201 N02200 / N02201 2.4066/2.4068 Ni 99.2 -- SB161, SB163 B161, B163 -- --
Alloy 400 N04400 2,436 NiCu30Fe QA 400 SB163, SB165 B163, B165 -- --
Alloy 600 N06600 2,482 NiCr15Fe NCF 600 SB163, SB167 B163, B167 -- 5580
Alloy 617 N0617 2,466 NiCrCoMo -- -- B167 -- --
Alloy 625 N06625 2,486 NiCr22Mo9Nb QA 625 SB444 B444 -- 558
Alloy 690 N06690 2,464 NiCr29Fe -- SB163, SB167 B163, B167 -- --
All0y 718 N07718 2,467 NiCr19Fe19Nb5Mo3 -- SB163, SB167 B163, B167 -- 5589, 5590
Alloy 825 N08825 2,486 NiCr21Mo NCF 825 SB163 B163 -- --
Monel K500 N05500 2,437 NiCu30Al -- SB163 B163 -- 4676
15-5 S15500 1,454 X5CrNiCu15-5 -- -- -- -- 5659
17-4 S17400 1,455 X5CrNiCu17-4 -- -- -- -- 5643
17-7 S17700 1,457 X7CrNiAl17-7 -- -- -- -- 5568
