ASTM A333 Grade 6 Pipe

ASTM A333 Grade 6 Pipe

ASTM A333 Grade 6 Pipe Highlights
Size: 1/2” NB to 36” NB
Thickness 3-12mm
Specifications ASTM A333 |ASME SA333
End Plain End, Beveled End, threaded End,
Types Seamless , ERW , Welded ,Fabricated
Tensile strength 415 Mpa
Temperature range -45℃

Supplier of SA 333 GR6 Seamless Pipe in India

ASTM A333 Grade 6 Pipe

ASTM A333 Grade 6 Pipe

A333 Seamless Pipe

A333 Seamless Pipe

ASTM A333 Grade 6 ERW Pipe

ASTM A333 Grade 6 ERW Pipe


Table of Contents


ASTM A333 Grade 6 Pipe Specification

ASTM A333 Grade 6 Seamless Pipe Sizes

  • OD: 10.3- 610 mm
  • length:12000 mm
  • Wall Thickness: 1 -40 mm

Sizes

A333 Grade 6 Welded Pipe

  • Wall Thickness: 2.5-20 mm
  • OD: 21.3 - 2540mm
  • length: 12000 mm

PSL Level

CS SA333 Gr6 Pipe Indian Standard

  • IS 3589
  • IS 1239
  • IS 3601
  • IS 4923
Standards

Heavy Wall A333 Steel Pipe Surface Coating

  • Black Painting
  • CWC (Concrete Weight Coated)
  • Natural
  • FBE
  • 3PE (3LPE)
  • 3PP
Surface Coating

A333 Gr 6 Material Form

  • Coiled
  • Round
  • U Shape
  • Straight
  • Hollow
  • Square
  • Pan cake coils
  • Rectangular
Material Data

ASTM A333 Gr 6 Schedule 40 Pipe Welding Process

  • MAG-welding massive wire
  • TIG-welding
  • MAG-welding cored wire
  • Arc welding (E)
  • Submerged arc welding

Welding Process

A333 Galvanized Pipe Standards

  • BS 1965-1
  • BS 3601
  • BS 1387





Standards

ASME SA 333 gr 6 ERW Pipe Origin

  • Japanese
  • Russian
  • European
  • Ukraine
  • Dubai
  • Indian
  • UK
  • USA

Origin

A333 low temp LSAW Pipe Testings

  • (PMI)
  • Eddy current
  • Non Destructive Testing
  • IGC- Intergranular Corrosion Test
  • Charpy V Impact Test
  • Hardness Test
  • Ultrasonic

Testings

ltcs ASTM A333 gr 6 SSAW Pipe Documentation

  • Wall Thickness or Schedule No.
  • Heat Number
  • Nominal Pipe Sizes (NPS)
  • Specification of Pipe
  • Material Grade
  • Manufacturing Process

Documentation

ASME SA 333 Pipe End

  • PBE -Plain Both Ends
  • TOE -Treaded One End
  • BLE -Bevel large end
  • POE -Plain One End






End

A333 gr 6 carbon Steel Pipe Manufacturing Process

  • DSAW
  • SSAW
  • LSAW
  • SAW
  • HFW and HSAW



Manufacturing Process

ASTM A333 6 Pipe Test Certificate

  • EN 10204 3.2
  • EN 10204 3.1
  • NACE MR0175
  • Radiographic Testing (RT)
  • NACE MR0103
Material Test Certificate

A333 gr 6 SMLS Pipe Value Added Services

  • Sand Blasting
  • Bending
  • Heat Treatment
  • Machining
  • Galvanizing
Value Added Services

ASME A333 Lined Pipe Packing

  • Steel Strips Bundled
  • Wooden Boxes
  • or as per Customers Requests
  • Plastic Bags

Packing

Check A333 Gr 6 ERW and Welded Pipe Weight and Dimensions

A333 Gr 6 ERW Pipe Weight Chart

NPS Size Range O.D. Pipe Wall Thickness (WT) Pipe I.D. Schedule
Pipe #		 Standard to XXHY Weight per Foot Gallon Capacity Per Linear Foot
1/2 0.84 0.109 0.622 40 STD 0.85 .0158
3/4 1.05 0.113 0.824 40 STD 1.13 .0277
1 1.315 0.133 1.049 40 STD 1.68 .0449
1 1/4 1.66 0.140 1.380 40 STD 2.27 .0777
1 1/2 1.90 0.145 1.610 40 STD 2.72 .1058
2 2.375 0.109 2.157 10 2.64 .1898
2 1/2 2.875 0.120 2.635 10 3.53 .2833
3 1/2 4.0 0.120 3.760 10 4.98 .5768
4 4.5 0.120 4.260 10 5.62 .7404
5 5.563 0.188 5.187 10.80 1.0979
6 6.625 0.109 6.407 5 7.59 1.6748
0.280 6.065 40 STD. 18.99 1.5008
0.432 5.761 80 XHY 28.60 1.3541
0.864 4.897 XXHY 53.21 .9784

ASTM A333 Grade 6 Pipe Dimensions

Nominal Pipe Size [inches] OD [mm] OD [inches] Wt [mm] WT [inches] Weight [kilgram/m] Weight [lb/foot]
1/8 10.3 MM 0.405 1.73 MM 0.068 0.37 0.24
1/2 21.3 MM 0.840 2.77 MM 0.109 1.27 0.85
1 33.4 MM 1.315 3.38 MM 0.133 2.50 1.68
1 1/4 42.2 MM 1.660 3.56 MM 0.140 3.39 2.27
2 60.3 MM 2.375 3.91 MM 0.154 5.44 3.65
2 1/2 73.0 MM 2.875 5.16 MM 0.203 8.63 5.79
3 1/2 101.6 MM 4.000 5.74 MM 0.226 13.57 9.11
4 114.3 MM 4.500 6.02 MM 0.237 16.07 10.79
6 168.3 MM 6.625 7.11 MM 0.280 28.26 18.97
8 219.1 MM 8.625 8.18 MM 0.322 42.55 28.55
10 273.0 MM 10.750 9.27 MM 0.365 60.31 40.48
12 323.8 MM 12.750 10.31 MM 0.406 79.73 53.52
14 355.6 MM 14 11.13 MM 0.375 94.55 54.57
18 457.0 MM 18 14.27 MM 0.562 155.80 104.67
20 508.0 MM 20 15.09 MM 0.594 183.42 123.11
24 610.0 MM 24 17.48 MM 0.688 255.41 171.29
32 813.0 MM 32 17.48 MM 0.688 342.91 230.08

ADNCO approved ASTM A333 Carbon Steel GR.6 Square Pipe are available in various Sizes

A333 Welded Pipe Size Chart

Size Size WT OD Kgs./Mtr. Length
15 x Sch 40 1/2" x Sch 40 2.77 mm 21.3 OD 1.27 5 To 7
20 x Sch 40 3/4" x Sch 40 2.87 mm 26.7 mm 1.69 5 To 7
20 x Sch XXS 3/4" x Sch XXS 7.82 mm 26.7 OD 3.64 5 To 7
25 x Sch 160 1" x Sch 160 6.35 mm 33.4 mm 4.24 5 To 7
32 x Sch 40 1 1/4" x Sch 40 3.56 mm 42.2 OD 3.39 5 To 7
32 x Sch XXS 1 1/4" x Sch XXS 9.7 mm 42.2 mm 7.78 5 To 7
40 x Sch 40 1 1/2" x Sch 40 3.68 mm 48.3 OD 4.05 5 To 7
50 x Sch 40 2" x Sch 40 3.91 mm 60.3 OD 5.44 5 To 7
50 x Sch 160 2" x Sch 160 8.74 mm 60.3 mm 11.12 5 To 7
65 x Sch 80 2 1/2" x Sch 80 7.01 mm 73 mm 11.41 5 To 7
65 x Sch XXS 2 1/2" x Sch XXS 14.02 mm 73 mm 20.40 5 To 7
80 x Sch 160 3" x Sch 160 11.13 mm 88.9 mm 21.35 5 To 7
80 x Sch XXS 3" x Sch XXS 15.24 mm 88.9 mm 27.69 5 To 7
90 x Sch 80 3 1/2" x Sch 80 8.08 mm 101.6 mm 18.64 5 To 7
100 x Sch 40 4" x Sch 40 6.02 mm 114.3 OD 16.07 5 To 7
100 x Sch 120 4" x Sch 120 11.13 mm 114.3 mm 28.33 5 To 7
100 x Sch XXS 4" x Sch XXS 17.12 mm 114.3 mm 41.04 5 To 7
Manufacturer of ASME SA 333 GR 6 Seamless Pipe as per E709 and IS 1239

Standards of Large Diameter A333 Grade 6 Pipe

  • ASTM A370
  • E165
  • ASTM A671
  • E709
  • E23
  • ASTM A999/ A999M
Refer Thick Wall SA333 Pipe Thickness Chart

A333 Grade 6 Pipe Wall Thickness Wall Thickness and Tolerance

Outside Diameter, inch Tolerance, %
1/8≤OD≤2-1/2 +20.0/-12.5
3≤OD≤18, WT/OD>5% +15.0/-12.5
OD≥20, WT/OD≤5% +22.5/-12.5
OD≥20, WT/OD>5% +15.0/-12.5

Thick Wall SA333 Pipe Temperature Range

ASTM A333 Grade 6 Pipe withstand Excellent Temperature Range

Grade The lowest temperature for strike test
℃ ℉
SA 333 GR 6 -45 -50

Various Types Of ASTM A333 Grade 6 Pipe

Supplier of ASTM A333 Grade 6 Pipe in India are available in variety of Forms and Coatings

ASTM A333 Grade 6 Welded Pipe

ASTM A333 Grade 6 Welded Pipe

SA333 Gr 6 Galvanized Pipe

SA333 Gr 6 Galvanized Pipe

A333 GR 6 LSAW Pipe

A333 GR 6 LSAW Pipe

ASTM A333 Gr6 SSAW Pipe

ASTM A333 Gr6 SSAW Pipe

A333GR6 SCH 40 EFW Pipe

A333GR6 SCH 40 EFW Pipe

Heavy Wall ASTM A333 6 Pipe

Heavy Wall ASTM A333 6 Pipe

Large Diameter ASME SA 333 6 Pipe

Large Diameter ASME SA 333 6 Pipe

Schedule 40 A333 grade 6 Pipe

Schedule 40 A333 grade 6 Pipe

ASME SA 333 Grade 6 NACE Pipe

ASME SA 333 Grade 6 NACE Pipe

Schedule 40 A333 6 Round Pipe

Schedule 40 A333 6 Round Pipe

Carbon Steel A333 GR 6 FBE Lined Pipe

Carbon Steel A333 GR 6 FBE Lined Pipe

Epoxy Coated ASTM A333 6 Pipe

Epoxy Coated ASTM A333 6 Pipe

Absolute Roughness of A333 Galvanized Pipe

Type of ASTM A333 GR 6 Pipe  Roughness [inch] Roughness [mm]
A333 GR 6, used, cleaned .006 - .008 .15 - .2
ASTM A333 Grade 6, drawn, new .0008 - .004 .02 - .1
welded, new .002 - .004 .05 - .1
lightly corroded .004 - .016 .1 - .4
galvanized, new .006 .15
heavy scaling .06 - .16 1.5 - 4
severely corroded .016 - .12 .4 - 3
bitumed coated .002 .05
light scaling .04 - .06 1 - 1.5

Heavy Wall A333 Steel Pipe Testings

  • BHN Hardness & Rockwell Testers
  • Eddy Current Test
  • Hydrostatic Tests
  • Ultrasonic Testing ECT Testing
  • Metalography Test
  • Visual Inspection
  • TPP and CVN Impact Testing

Supply ASTM A333 Grade 6 Pipe in Following Brands

Baosteel

Baosteel

USL Universal Specialities Limited

USL Universal Specialities Limited

Jindal

Jindal

ISMT Limited

ISMT Limited

Tenaris

Tenaris

Maharashtra Seamless Limited

Maharashtra Seamless Limited

ASME SA 333 GR 6 Seamless Pipe Manufacturing Proocess

  • Cold Drawn or Finished Seamless (CDS)
  • Sub-merged Arc Welding (SAW) Pipe
  • Hot Finished Welding (HFW) Pipe
  • Cold Drawn Electric Resistance Welding (CEW)
  • Hand-Welding or Manual Arc Welding (MAW)
  • Electric Resistance Welding (ERW)
  • Hot Finished Seamless (HFS)
  • High Frequency Induction Welding (HFIW)
  • Electric Fusion Welding (EFW) Pipe

SA 333 Gr 6 Lined Pipe Pressure Rating

Size
(in)		 Wall Thickness
(in)		 Outside Diameter
(in)		 Schedule Inside Diameter
(in)		 Temperature (oF)
Allowable Stress (psi)
Maximum Allowable Pressure (psi)
700 650 600 500 400 300 200 100
16800 16900 17300 18900 20000 20700 21300 23300
1/2 0.109 0.84 401 0.622 4865 4894 5010 5473 5792 5994 6168 6747
1 0.133 1.315 40 1.049 3698 3720 3808 4160 4402 4556 4688 5128
1 1/4 0.14 1.66 40 1.38 3039 3057 3129 3419 3618 3744 3853 4214
1 1/2 0.145 1.9 40 1.61 2731 2747 2812 3072 3251 3365 3462 3788
2 0.109 2.375 10 2.157 1601 1610 1648 1801 1906 1972 2030 2220
2 1/2 0.12 2.875 10 2.635 1451 1460 1494 1632 1727 1788 1840 2012
3 0.12 3.5 3.26 1184 1192 1220 1333 1410 1459 1502 1643
3 1/2 0.12 4 10 3.76 1033 1039 1064 1162 1230 1273 1309 1432
4 0.12 4.5 10 4.26 916 921 943 1030 1090 1128 1161 1270
5 0.188 5.563 5.187 1167 1174 1202 1313 1389 1438 1480 1619
0.258 5.563 40 5.047 1618 1628 1667 1821 1927 1994 2052 2244
0.375 5.563 80 4.813 2394 2408 2465 2693 2850 2950 3035 3320
0.5 5.563 120 4.563 3254 3273 3351 3661 3874 4009 4126 4513
0.625 5.563 160 4.313 4148 4172 4271 4666 4938 5111 5259 5753

Large Diameter A333 Grade 6 Pipe Coatings

Large Diameter A333 Grade 6 Pipe Coatings

Heavy Wall A333 Steel Pipe Impact Test

Size of Specimen, min Minimum Notched Bar Impact Value of One Specimen Only of a Set Minimum Average Notched Bar Impact Value of Each Set of Three Specimens Impact Temperature
ft-lbf J ft-lbf J Grade Min Impact
Test Temp
10 by 2.5 3 4 4 5
10 by 3.33 3 4 5 7
10 by 5 5 7 7 9 6 -50 -45
10 by 7.5 8 11 10 14 1 -50 -45
10 by 6.67 7 9 9 12 3 -150 -100
10 by 10 10 14 13 18 F C

Carbon Steel A333 Grade 6 LSAW Pipe Markings

  • A333 GR 6 Grade and type
  • A333 Grade 6 Pipe Manufacturer’s name
  • Weight
  • SA 333 GR 6 Pipe Heat treatment
  • Type of A333GR6 material
  • Impact test temperature
  • End finish of ASTM A333 GR 6 Pipes and Tubes
  • Manufacturing process
  • ASTM A333 GR 6 Pipe Grade and type
  • Monogram marking
  • Impact test temperature
  • Heat treatment

Epoxy Lined SA333 Gr 6 Pipe Applications

Epoxy Lined SA333 Gr 6 Pipe Applications

A333 gr 6 HSN Code

HSN Code Grade
73043939 A333 gr 6 Pipe

ASTM A333 gr 6 Welded Pipe Schedule Chart

NB Sizes Sch 160 Sch 80 Sch 40 Sch 10 Sch 5
1/2 ✔ ✔ ✔ ✔
1 ✔ ✔ ✔ ✔
1.5 ✔ ✔ ✔ ✔ ✔
2 ✔ ✔ ✔ ✔ ✔
3 ✔ ✔ ✔ ✔ ✔
4 ✔ ✔ ✔ ✔ ✔
6 ✔ ✔ ✔ ✔ ✔
8 ✔ ✔ ✔ ✔ ✔
12 ✔ ✔ ✔ ✔ ✔
14 ✔ ✔ ✔ ✔ ✔
16 ✔ ✔ ✔ ✔ ✔
18 ✔ ✔ ✔ ✔ ✔
24 ✔ ✔ ✔ ✔

ASTM A333 6 Seamless Pipe Ends

Supplier of ASTM A333 Grade 6 Pipe with Plain and Threaded Ends

ASTM A333 6 Seamless Pipe Ends

A333 Carbon Steel Pipe Chemical Composition

ASTM A333 Grade 6 Pipe Manufacturer in India provides accurate chemical composition of Pipe.

Carbon Manganese Silicon Sulphur Phosphorous Nickel Molybdenum Copper Chromium Others
max 0.30 0.29 – 1.06 min 0.10 0.025 0.025 – – – – –

Ltcs ASTM A333 Gr 6 Pipe Mechanical Properties

Grade Tensile strength, min, psi (MPa) Yield strength, min, psi (MPa) Elongation (%)
A333 Gr.6 60 000 (415) 35 000 (240) 30 min

Physical Properties of Schedule 40 A333 GR 6 Pipe Pipe

Density (lb / cu. in.) 0.284
Specific Heat (Btu/lb/Deg F - [32-212 Deg F]) 0.105
Melting Point (Deg F) 2750
Specific Gravity 7.9
Mean Coeff Thermal Expansion 6.3
Thermal Conductivity 360
Modulus of Elasticity Torsion 11
Modulus of Elasticity Tension 30

ASTM A333 Grade 6 Equivalent Material Equivalent

Standards Country Value
ASTM America ASTM A333
WNR Russia 17178
BS United Kingdom NFA A 36-2051 Grade A 42 AP
ASME Australia ASME SA 333
DIN German DIN 17178
EN Europe EN P215NL Grade 10216-4

Supply Ready Stock of ASTM A333 Grade 6 Pipe to various Countries

Country Name Flag Country Name Flag
Ghana Ghana Zambia Zambia
South Africa South Africa Tunisia Tunisia
Morocco Morocco Tanzania Tanzania
Nigeria Nigeria Algeria Algeria
Ethiopia Ethiopia Egypt Egypt
Angola Angola Kenya Kenya
