ASTM A335 P11 Pipe

ASTM A335 P11 Pipe

ASTM A335 P11 Alloy Steel Pipe Highlights
Specifications ASME SA 335 | ASTM A335
Size: 1/2″ to 24″
Outer Diameter 6 to 2500 mm
Standard ASME B36.10M
End Plain, Threaded, Beveled End
Density 7.85 g/cm³
Melting Point 600°C (1112°F)
Certificate EN 10204 3.1 & 3.2

Largest ISO Certified SA335 P11 Seamless Pipe Supplier in India For High Temperature Service

ASTM A335 P11 Pipe

ASTM A335 P11 Pipe

SA 335 gr P11 Seamless Pipe

SA 335 gr P11 Seamless Pipe

UNS K11597 Welded Pipe

UNS K11597 Welded Pipe


Table of Contents


ASME SA335 Grade P11 ERW Pipe Material Specification

ASTM A335 P11 Pipe Specification

SA 335 gr P11 Seamless Pipe Sizes

  • Size: 1/8 NB - 24 NB in.
  • OD : 19.05 - 114.3 mm
  • WT: 4.5mm to 60mm
  • Length: Single, Double Random & Cut Length
Sizes

UNS K11597 Welded Pipe Sizes

  • OD : 1/2” NB – 24” NB
  • Length : 26 Meters
  • Wall thickness: 0.8 to 12.7 mm


Sizes

ASA335 P11 EFW Pipe Manufacturing Types

  • EFW
  • DSAW, LSAW, SSAW
  • Seamless
  • ERW
  • Welded
Types

NBR 5603 P11 Chrome Pipe Other Trade Name

  • Pipe – ASTM A335 Gr P11
  • Bored/ Forged pipe – ASTM A36
  • Welded Pipe – ASTM A691 1-1/4 CR


Surface Finish

SA335P11 High Pressure Boiler Pipe Schedule

  • SCH XXS
  • SCH 80
  • SCH 40
  • 4 Inch
  • SCH XS
  • SCH 160
  • SCH STD
Schedule

SA335 gr P11 Chrome Moly Pipe End Types

  • Groove Ends
  • Plain End
  • Bevelled End
  • Threaded End



End Types

ASTM P11 High Temperature Seamless Pipe Standard

  • ASME B36.10M




Standards

SA335 P11 EFW Pipe Testing

  • Hardness
  • Mechanical
  • PMI
  • Tensile
  • Chemical
  • Flaring
  • Ultrasonic
Testing

ASTM P11 Steel Pipe Types

  • Round Pipe
  • Seamless Pipe
  • ERW Pipe
  • Welded Pipe
  • EFW pipe


Types

SA 335 gr P11 Seamless Pipe Documentation

  • Mill Test Certificates
  • MTC EN 10204 type 3.1
  • PMI Test Reports
  • Visual Inspection

Documentation

Low Alloy ASTM A335 P11 Round Pipe Origin

  • European
  • Russia
  • American
  • Indian
  • Janpanese
Origin

Condition of Delivery of UNS K11597 Welded Pipe

  • GBK – Annealed
  • BKW – Soft/ Cold-finished
  • NBK – Normalized
  • BK- Hard/ Cold-finished

Shapes

SA335P11 High Pressure Boiler Pipe Packaging

  • Bubble Wraps
  • Wooden Box
  • Bundled


Temperature Limit

Temperature Limit of ASTM A335 P11 Boiler Pipe

  • 1112°F
  • 600°C


Fluids

ASTM P11 High Temperature Seamless Pipe Services

  • Welding
  • Punching
  • Cutting
  • Bending
Services

ASTM A335 Gr P11 Chrome Moly Pipe Schedule Chart

SA335 P11 EFW Pipe Schedule Chart

Sizes Inches Schedule 5 Schedule 10 Schedule 40 Schedule 60 Schedule 80
34" 34 .312 .688
36" 36 .750
32" 32 .688
30" 30
26" 26
22" 22 .250 .875 1.125
20" 20 .593 .812 1.031
16" 16 .500 .656 .843
14" 14 .437 .593 .750
12" 12.750 .165 .180 .365 .500 .593
10" 10.750 .134 .165
8" 8.625 .109 .148 .322 .406 .500
7" 7.625
6" 6.625 .109 .134 .280 .432
5" 5.563 .258 .375
4-1/2" 5
4" 4.500 .083 .120 .237 .281 .337
3-1/2" 4 .226 .318
3" 3.500 .216 .300
3/4" 1.050 .065 .083 .113 .154
2-1/2" 2.875 .083 .120 .203 .276
2" 2.375 .065 .109 .154 .218
1-1/2" 1.900 .145 .200
1-1/4" 1.660 .140 .191
1" 1.315 .133 .179
1/2" .840 .083 .109 .147
Manufacturer of UNS K11597 High Pressure Pipe Provide Hot Rolled and Cold Drawn Process

Comparison of Hot Rolled & Cold Rolled for P11 Seamless Pipe

ASTM A450 / A450M P11 Seamless Pipe, Hot rolled Tolerance in (MM) Outside Daimeter, (MM)
+0.4/-1.6 190.5 ＜OD ≤228.6
+0.4/-1.2 101.6 ＜OD ≤190.5
+0.4/-0.8 OD ≤ 101.6
A335 P11 Pipes, Cold Drawn Tolerance in (MM) Outside Daimeter, (MM)
+0.38/-1.14 190.5 ＜OD ≤228.6
+0.38/-0.64 101.6 ＜OD ≤190.5
±0.38 76.2 ≤OD ≤101.6
±0.30 63.5 ≤OD ＜76.2
±0.25 50.8 ≤OD ＜63.5
±0.20 38.1 ＜OD ＜50.8
±0.15 25.4 ≤OD ≤38.1
±0.10 OD ＜ 25.4
ASTM A530 / SA 335 Nominal pipe Size Tolerance in (MM) Outside Daimeter, (Inch)
±1% OD>12
+2.38/-0.79 8＜OD≤12
+1.59/-0.79 4＜OD≤8
±0.79 1-1/2＜OD≤4
±0.40 1/8≤OD≤1-1/2
Low Alloy ASTM A335 P11 IBR Pipe Widely Used For High Temperature Environment

Applications of ASTM A335 P11 Pipe

Applications of ASTM A335 P11 Pipe

SA 335 gr P11 Seamless Pipe WT Tolerance

ASTM A335 GR P11 Material
(NPS)		 Tolerance of ASTM P11 Pipe
(% from the specified)
Under Over
  • WT/OD > 5%
  • Above 2 1/2 NPS [65]
 12.5 % 15.0%
  • WT/OD < or = 5%
  • Above 2 1/2 NPS [65]
 22.5%
  • 1/8 NPS to 2 1/2 NPS [6 to 65] inclusive
  • all WT/OD ratios
 20.0%
Notes:
  • OD Means = ASTM A335 P11 Pipe Specified Outside Diameter
  • WT Means = Specified ASTM A335 P11 Pipe Wall Thickness

Heat Treatment of ASTM A335 P11 Boiler Pipe

Grade Heat Treatment Type Temperature Range in C [F] Temperature Range Normalization F [C]
ASTM A335 P11 Pipe Normalize & Temper 650 C & [1200 F] *****
Full & Isothermal Anneal

ASTM A335 P11 Pipe Size Chart In Mm

ASTM P11 Steel Pipe Outside Daimeter in
(MM)		 Pipe Wall Thickness in
(MM)		 Kg/m Schedule Inches
219.08 23.012) 112.97 160 8
219.08 18.23 91.30 120 8
219.08 8.18 43.20 40S 8
168.28 18.262) 68.59 160 6
168.28 10.97 43.21 80S 6
168.28 7.11 28.69 40S 6
141.30 15.882) 49.87 160 5
141.30 6.55 22.10 40S 5
114.30 13.492) 34.05 160 4
114.30 3.05 8.50 10S 4
101.60 8.08 18.92 80S 3½
101.60 5.74 13.78 40S 3½
101.60 3.05 7.53 10S 3½
88.90 11.132) 21.67 160 3
88.90 7.62 15.51 80S 3
88.90 3.05 6.56 10S 3
73.03 7.01 11.59 80S 2½
73.03 5.16 8.77 40S 2½
73.03 3.05 5.35 10S 2½
60.33 8.742) 11.29 160 2
60.33 3.91 5.52 40S 2
60.33 2.77 3.99 10S 2
48.26 5.08 5.49 80S 1½
48.26 3.68 4.11 40S 1½
48.26 2.77 3.16 10S 1½
42.16 6.352) 5.69 160 1¼
42.16 4.85 4.53 80S 1¼
42.16 2.77 2.73 10S 1¼
33.40 6.352) 4.30 160 1
33.40 3.38 2.54 40S 1
33.40 2.77 2.13 10S 1
26.67 3.91 2.23 80S 3/4
26.67 2.87 1.71 40S 3/4
26.67 2.11 1.30 10S 3/4
21.34 3.73 1.65 80S 1/2
21.34 2.11 1.02 10S 1/2
17.15 3.20 1.12 80S 3/8
17.15 1.65 0.64 10S 3/8
13.72 3.02 0.81 80S 1/4
13.72 1.65 0.50 10S 1/4

UNS K11597 Welded Pipe Weight Chart

An Amazing Pipe Weight Chart is Provided by ASTM A335 P11 Pipe Supplier in India.

Nominal Pipe Size (NPS) Outside Diameter (OD) Standard Wall Thickness SCH # Inside Diameter (ID) Section Modulus Weight Chart per Foot Capacity in Gallon Per Linear Foot
1/2 0.84 XXHY 0.294 0.252 .0577 1.72 .0026
0.188 160 0.464 .0528 1.31 .0088
XHY 0.147 80 0.546 .0478 1.09 .0122
STD 0.109 40 0.622 .0407 0.85 .0158
1 1.315 XXHY 0.436 1.503 1.1043 9.04 .0922
0.344 160 1.687 .9806 7.47 .1161
XHY 0.218 80 1.939 .7309 5.03 .1534
STD 0.154 40 2.067 .5606 3.66 .1743
0.133 40 1.049 .1328 1.68 .0449
3 3.50 XXHY 0.600 2.300 3.4243 18.6 .2158
0.438 160 2.624 2.8774 14.34 .2811
XHY 0.300 80 2.900 2.2253 10.26 .3431
STD. 0.216 40 3.068 1.7241 7.58 .3840
0.156 3.188 1.3122 5.58 .4147
0.120 3.260 1.0411 4.34 .4336
4 4.5 XXHY 0.674 3.152 6.7927 27.57 .4054
0.531 160 3.438 5.8997 22.53 .4822
0.438 120 3.624 5.1790 19.02 .5361
XHY 0.337 80 3.826 4.2713 15.00 .5972
STD. 0.237 40 4.026 3.2145 10.80 .6613
0.188 4.124 2.6296 8.67 .6942
0.156 4.188 2.2354 7.24 .7156
0.120 10 4.260 1.7612 5.62 .7404
5 5.563 XXHY 0.750 4.063 12.0954 38.59 .6734
0.625 160 4.313 10.7976 32.99 .7590
XHY 0.375 80 4.813 7.4300 20.80 .9449
0.281 5.001 5.8644 15.87 1.0204
STD. 0.258 40 5.047 5.4500 14.63 1.0391
0.219 5.125 4.7279 12.51 1.0716
0.188 5.187 4.1161 10.80 1.0979
6 6.625 XXHY 0.864 4.897 20.025 53.21 .9784
0.500 5.625 13.711 32.74 1.2909
XHY 0.432 80 5.761 12.224 28.60 1.3541
0.312 6.001 9.3416 21.06 1.4688
STD. 0.280 40 6.065 8.4958 18.99 1.5008
0.134 10 6.357 4.3475 9.30 1.6488
0.109 5 6.407 3.5769 7.59 1.6748

Types of ASTM A335 P11 Steel Chrome Pipe

Supplier of ASTM A335 P11 Pipe in India Are Available in Various Types and Ends

ASTM A335 P11 Boiler Pipe

ASTM A335 P11 Boiler Pipe

ASTM A335 P11 steel SAW Pipe

ASTM A335 P11 steel SAW Pipe

ASTM P11 High Temperature Seamless Pipe

ASTM P11 High Temperature Seamless Pipe

SA335 P11 EFW Pipe

SA335 P11 EFW Pipe

NBR 5603 P11 Chrome Pipe

NBR 5603 P11 Chrome Pipe

ASTM A335 gr P11 ERW Pipe

ASTM A335 gr P11 ERW Pipe

SA335 gr P11 Chrome Moly Pipe

SA335 gr P11 Chrome Moly Pipe

SA335P11 High Pressure Boiler Pipe

SA335P11 High Pressure Boiler Pipe

Low Alloy ASTM A335 P11 Round Pipe

Low Alloy ASTM A335 P11 Round Pipe

ASTM A335 P11 Pipe Chemical Composition

ASTM A335 P11 Pipe Mo Si C S Cr P Mn
0.44 – 0.65 0.50 – 1.00 0.05 – 0.15 0.025 Max 1.00 – 1.50 0.025 Max 0.30 – 0.60

Tensile Strength of ASTM A335 gr P11 ERW Pipe

Properties Values
Tensile Strength Min, in (psi) 415 MPa
60 ksi
Yield Strength Min, in (psi) 205 MPa
30 ksi

ASTM A335 P11 Pipe Mechanical Properties

The Best Pipes With Exceptional Mechanical Properties Are Offered by ASTM P11 Steel Pipe Manufacturer in India.

Elements Elongation Yield Strength, in MPa Tensile Strength, in MPa
Values 30 Min 205 Min 415 Min

Hardness Test of Low Alloy ASTM A335 P11 Round Pipe

Grade Hardness Test
ASTM P11 Steel Pipe 250 HB/265 HV [25HRC]

ASTM A335 gr P11 ERW Pipe Temperature Range

Properties Values
Temperature Range 1200 °F or 650 °

ASTM A335 P11 Pipe Dimensions

Nominal Pipe Size Inside Diameter (Inches) WEIGHT (LB/FT) Outside Diameter (Inches) Wall Thickness (Inches)
24 22.624" 171.30 24.000" 0.688"
20 18.812" 123.10 20.000" 0.594"
18 16.876" 104.70 18.000" 0.562"
16 15.000" 82.77 16.000" 0.500"
14 13.124" 63.50 14.000" 0.438"
12 11.938" 53.52 12.75" 0.406"
10 10.020" 40.48 10.750" 0.365"
8 7.981" 28.55 8.625" 0.322"
6 6.065" 18.97 6.625" 0.280"
5 5.047" 14.62 5.563" 0.258"
4 4.026" 10.79 4.500" 0.237"
3-1/2 3.548" 9.11 4.000" 0.226"
3 3.068" 7.58 3.500" 0.216"
3/8 0.493" 0.57 0.675" 0.091"
2-1/2 2.469" 5.79 2.875" 0.203"
2 2.067" 3.65 2.375" 0.154"
1-1/4 1.380" 2.27 1.660" 0.140"
1-1/2 1.610" 2.72 1.900" 0.145"
1 1.049" 1.68 1.315" 0.133"
1/8 0.269" 0.24 0.405" 0.068"
1/4 0.364" 0.42 0.540" 0.088"
1/2 0.622" 0.85 0.840" 0.109"

Allowable Stress of ASTM A335 P11 Boiler Pipe

Temperature (°F) 700 750 600 650 500 400 -20
Stress (ksi) 4.2 2.8 9.3 6.3 13.6 14.0 14.4
Temp. (°F) 1050 1100 950 1000 900 850 800
Stress (ksi) 15.0 14.8 15.0

Low Alloy ASTM A335 P11 Pipe Material Welding

Metal A335 P11 Pipe
Process Welding Gas Arc Welding, or SAW
Filler Metal E8018 - B2 F No. 4 A No.3

Heat Capacity of NBR 5603 P11 Chrome Pipe

Properties Values
Poisson's Ratio 0.29
Heat Capacity 448 - 502 J / (kg·K)

ASTM A335 gr P11 ERW Pipe Dimensional Tolerance

Nominal Size Designator Over Under
(MM) (Inches) (Inches) (MM)
Over 8 to 12, Inclusive 2.38 3 ⁄ 32 1 ⁄ 32 0.79
Over 4 to 8, Inclusive 1.59 1 ⁄ 16 1 ⁄ 32 0.79
Over 1 1⁄2 to 4, Inclusive 0.79 1 ⁄ 32 1 ⁄ 32 0.79
Over 12 ± 1 %
1⁄8 to 1 1⁄2 , Inclusive 0.40 1 ⁄ 64 1 ⁄ 64 0.40

Advantages of ASTM A335 P11 Boiler Pipe

  • Cost-Effective
  • High Temperature Resistance
  • Compliance
  • Corrosion Resistance
  • Weldability
  • Excellent Strength

ASTM A335 P11 Pipe Equivalent Material

ASTM ABS ASME NK ISO JIS G 3458 LRS UNS DIN BS
A335 P11 ABS 11 SA335 P11 KSTPA 23 - STPA 23 - K11597 - 3604 P1 621

Germany DIN Germany WNR France AFNOR Spain UNE Italy UNI
13CrMo4-4 1.7335 15CD3.5 14CrMo45 14CrMo45
ASTM UNS ASME Japanese British
ASTM A335 Grade 11 K11597 SA 335 Gr 11 G 3458 STPA23 3604 CFS621

Provides ASTM P11 Steel Pipe Ex Stock in the Following Brands

Nippon Steel

Nippon Steel

Outokumpo

Outokumpo

Posco

Posco

Jindal

Jindal

Thyssenkrupp

Thyssenkrupp

Acronis

Acronis

SA335 gr P11 Chrome Moly Pipe Elongation Requirements

WT (Wall Thickness) Longitudinal Transverse
Inches Millimetre
9 ⁄ 32 7.2 28 19
7 ⁄ 32 5.6 26 …
5 ⁄ 32 4 22 …
5 ⁄ 16 8 30 20
3 ⁄ 32 2.4 20 …
3 ⁄ 16 4.8 24 …
1 ⁄ 16 1.6 18 …
1 ⁄ 8 3.2 21 …
1 ⁄ 4 6.4 27 18

ASTM A335 P11 Boiler Pipe Testing

  • Bend Test
  • Tensile Test
  • Flattening Test
  • Hardness Test

Physical Properties of UNS K11597 Welded Pipe

Properties Values Temp.
Melting point   600°C (1112°F)
Thermal Conductivity   36 - 43 W/(m·K)   23.0 °C
Coefficient of Thermal Expansion 1.1E-5 - 1.4E-5 1/K
Specific Heat Capacity 448 - 502 J/(kg·K)

ASTM A335 P11 Pipe HSN Code

Material HSN Code
ASTM A335 P11 Pipe 730451

Deliver ASTM A335 P11 Alloy Steel Pipe Ex Stock to the Countries Below

Country Name Flag Country Name Flag
Dubai Dubai Morocco Morocco
South Africa South Africa Tunisia Tunisia
Nigeria Nigeria Algeria Algeria
Ethiopia Ethiopia Egypt Egypt
Tanzania Tanzania UAE UAE
Angola Angola Kenya Kenya
Ghana Ghana Zambia Zambia
