Monel Pipe

Monel Pipe

Monel Pipe At a Glance
Plate Size 3-600mm
Schedule Sch 10 - XXH
Elongation 48%
Melting Point 1300-1450°C (2370-2640°F)
Standards ASTM B165/ ASME SB165
Grades Monel 400 , K500
Finish Mill finish, Annealing , Cold Finish

Monel 400 Seamless Pipe Supplier in India With MTC As Per EN 10204 3.1/3.2

Monel Pipe

Monel Pipe

Monel 400 Seamless Pipe

Monel 400 Seamless Pipe

Monel K500 Welded Pipe

Monel K500 Welded Pipe

Table of Contents


Manufacturer of Monel K500 Welded Pipe Stock Size Up To 600 mm OD

Monel Pipe Specification

Monel Seamless Pipe

  • OD: 3-600mm
  • Length : 0.5-12 meter
  • Thickness: 0.5 – 30mm

Size

Monel Alloy Welded Pipe

  • OD : 6-200mm
  • Length : 0.5-12 meter
  • Thickness : 0.35 – 6.00mm

Thickness

AMS 4574 Thick Walled Pipe

  • Wall thickness:2.5 – 100 mm
  • OD : 10 – 600 mm
  • Length:1/2 to 12 meter
Standards

Monel K500 Welded Pipe Welding Method

  • TIG welding
  • SMAW welding
  • MIG welding
Welding Method

Monel ERW Pipe Grades

  • Monel K500 pipe
  • Monel 400 pipe


Surface

Monel 400 UNS N04400 Round Pipe Standards

  • ASTM B165
  • ASME SB165

Bending

Werkstoff NR. 2.4375 Square Pipe Finish

  • Mill finish
  • Polished
  • Custom
  • Annealing
  • Bright
  • Pickling



Edges

Monel Seam Welded Pipe Types

  • Hot finished pipe
  • Seamless pipe
  • Round pipe
  • Welded pipe
  • Cold drawn pipe
  • Rectangular pipe
  • Exhaust pipe
  • Square pipe

Types

Monel Pipe Origin

  • European
  • Taiwan
  • Japanese
  • US
  • Thailand
  • Indian
  • Korea



Origin

UNS N04400 Rectangular Pipe Marking

  • Origin of material
  • Manufacturing date
  • ASTM/ ASME standard
  • Material grade
  • Manufacturer logo / name
  • Sizes




Marking

Monel Alloy 400 Solution Annealed Pipe Services

  • Welding
  • Polish
  • Plate Leveling
  • Beveling
  • Bending
  • Rolling
  • Heat Treatment
  • Forging
  • Forming
  • Shearing
Services

UNS N05500 Seamless Pipe Certification

  • 100% radiography test report
  • Raw materials certificate
  • Third party inspection report
  • Certificate of origin legalized
  • EN 10204/3.1B





Certification

Monel Alloy K500 Cold Drawn Pipe Packaging

  • Wooden Boxes
  • Custom
  • PE Fabric Bundles
  • Crates (steel/wooden)
  • Bundles (hexagonal)


Packaging

Monel 400 ASTM B165 Clad Pipe SWG

  • 20 Swg.
  • 18 Swg.
  • 16 Swg.
  • 14 Swg.
  • 12 Swg.
  • 10 Swg.

Cutting

Monel Alloy K5000 Square Pipe Manufacturing Types

  • Seamless
  • Fabricated
  • EFW
  • LSAW
  • Electric Resistance Welded (ERW)
  • CDW
Inspection

Buy 100% Hydrostatic Pressure Tested Monel Alloy Square Pipe in Mumbai

Monel Alloy Square Pipe Standards

  • Hardness Test
  • Micro and MacroTest
  • Flattening Test
  • PMI Testing
  • Hydrostatic Test
  • Pitting Resistance Test
  • Chemical Analysis
  • Flaring Test
  • Intergranular Corrosion (IGC) Test
  • Mechanical Testing
Stockist Of K-Monel Hot Finished Pipe in India As Per International Standard

K-Monel Hot Finished Pipe Standards

  • ASME B36.10
  • ASME B36.19
  • ASME SB165
  • ASTM B165
Monel 400 ERW Pipe Widely Used For Nuclear Power And Marine Engineering

Monel K500 Pipe Applications Applications

Monel K500 Pipe Applications

Alloy 400 Pipe HSN Code

Grade HSN Code
Monel 400 75071200

Monel Pipe Available Grades

Manufacturer of Monel Pipe provides various Grades

  • Monel 625 Pipe
  • Monel 600 Pipe
  • Monel 500 Pipe
  • Monel K500 Pipe
  • Monel 405 Pipe
  • Monel 400 Pipe

Monel Alloy K5000 Round Pipe Weight Chart

Nominal Pipe Size OD Weight Weight
inches millimeter Sched kilogram-meter pound-foot
1/2 0.840 21 40 STD 1.268 0.851
1″ 1.315 33 40 STD 2.501 1.679
1 1/2″ 1.900 48 40 STD 4.048 2.718
2″ 2.375 60 40 STD 5.441 3.653
4″ 4.500 114 – 16.073 10.790
8″ 8.625 219 – 25.233 16.940
– – 40 42.352 28.554
– – 60 53.085 35.638
10″ 10.750 273 – 31.588 21.207
– – 20 41.759 28.035
– – 40 STD 63.301 40.483
– – 60 XHY 81.530 54.735
– – 80 95.969 64.429
14″ 14.000 356 – 41.308 27.732
– – STD 81.281 54.568
– – XHY 107.381 72.090
20″ 20.000 508 – 78.547 52.733
– – 30 XHY 155.106 104.130
– – 40 183.378 123.110
30″ 30.000 762 – 118.318 79.433
– – STD 176.731 118.648
– – 20 XHY 234.647 157.530
48″ 48.000 1219 STD 284.112 190.738

Monel Pipe Size Chart

Supplier of Monel Pipe offering various Size at Reasonable rate

Monel pipe OD (millimeter) kg-m Pipe WT(millimeter) inches Sch
13.72 0.50 1.65 1/4 10S
17.15 0.86 2.31 3/8 40S
21.34 1.65 3.73 1/2 80S
26.67 1.30 2.11 3/4 10S
26.67 2.23 3.91 3/4 80S
33.40 2.13 2.77 1 10S
33.40 3.29 4.55 1 80S
42.16 3.44 3.56 1¼ 40S
48.26 4.11 3.68 1½ 40S
60.33 7.60 5.54 2 80S
73.03 8.77 5.16 2½ 40S
88.90 15.51 7.62 3 80S
101.60 18.92 8.08 3½ 80S
101.60 13.78 5.74 3½ 40S
114.30 16.32 6.02 4 40S
114.30 34.05 13.492 4 160
141.30 22.10 6.55 5 40S
141.30 49.87 15.882 5 160
168.28 14.04 3.4 6 10S
168.28 43.21 10.97 6 80S
17.15 0.64 1.65 3/8 10S
219.08 43.20 8.18 8 40S
219.08 112.97 23.012 8 160

Nickel Alloy 400 Welded Pipe Gauge Chart

Gauge No. U.S.G B.W.G
inch mm inch mm
6 .2031 5.16 .203 5.156
8 .1719 4.37 .165 4.191
10 .1406 3.57 .134 3.404
12 .1094 2.78 .109 2.769
14 .0781 1.98 .083 2.108
16 .0625 1.59 .065 1.651
18 .0500 1.27 .049 1.245
20 .0375 .953 .035 .889
22 .0313 .794 .028 .711
24 .0250 .635 .022 .559
26 .0188 .478 .018 .457
28 .0156 .396 .014 .356
30 .0125 .318 .012 .305
32 .0102 .259 .009 .229
34 .0086 .218 .007 .178
35 .0078 .198 .005 .127

Various Types Of Monel Pipe

Monel Pipe Supplier in India, with various Forms and Finishes

Monel Alloy Annealed Pipe

Monel Alloy Annealed Pipe

Monel Clad Pipe

Monel Clad Pipe

ASTM B165 N04400 Exhaust Pipe

ASTM B165 N04400 Exhaust Pipe

Nickel Alloy K500 Cold Drawn Pipe

Nickel Alloy K500 Cold Drawn Pipe

DIN 2.4360 Cold Finished Pipe

DIN 2.4360 Cold Finished Pipe

K500 Monel Hot Finished Pipe

K500 Monel Hot Finished Pipe

Monel Round Pipe

Monel Round Pipe

Monel 400 ASTM B165 Square Pipe

Monel 400 ASTM B165 Square Pipe

DIN 2.4375 Rectangular Pipe

DIN 2.4375 Rectangular Pipe

Alloy 400 Bright Annealed Pipe

Alloy 400 Bright Annealed Pipe

Nickel Alloy K500 Solution Annealed Pipe

Nickel Alloy K500 Solution Annealed Pipe

WNR 2.4360 Hot Finished Pipe Thickness Chart

Pipe OD Wall Thickness (Inches)
.010 .012 .016 .020 .028 .035 .049 .065 .083 .095 .109 .120
1/16 6,422 7,872 10,768 13,484
1/8       6,422 9,325 11,823
1/4         4,305 5,518 8,053 10,946
1/2           2,595 3,721 5,078 6,699
3/8           3,530 5,107 7,029
3/16       4,081 5,935 7,630 11,005
7/8           1,446 2,051 2,764 3,592 4,161 4,842 5,391
5/8           2,051 2,927 3,970 5,200 6,056
1           5,040 7,140 9,595 12,445 14,390 16,715 18,585

Monel 400 Seamless Pipe Pressure Ratings

Pipe O.D.
(in.)		 Working Pressure (psig)
Wall Thickness of Pipe (inches)
.028 .035 .049 .083 .109 .065 .120 .095
3/8   3100 4400     6100
5/16   3700 5400     7300
1/8 7900 10100
3/4     2200 4000   3000   4600
1/4 3700 4800 7000     9500
1       2900 3900 2200 4300 3400
1/2   2300 3200     4400

Monel Pipe Welding

Monel Pipe Welding

ASTM B165 UNS N04400 Seamless Pipe Allowable Pressure

Pipe OD Allowable Pressure
0.5 0.6 0.8 1.0 1.2 1.6 1.8 2.0 2.2 3.0
3 464 567 775 965
12     169 215 262 360 411 464
4 335 411 567 723 873
22       113 137 186 211 236 262 369
6     360 464 567 775
16       158 192 262 298 335 372 528
8     262 335 411 567
18       140 169 230 262 294 326 464
10     206 262 320 442
25       99 120 162 184 206 228 320
14       182 222 303 345 389 433 612

Monel Rectangular Pipe Annealing Temperature

Monel Pipe Supplier in India provides premium-grade Pipes with high-temperature performance

Monel Alloy Annealing Temperature Range (°F) Annealing Temperature Range (°C)
Monel 400 1,650 to 1,832 900 to 1,000
Monel K500 1,886 to 1,976 1,030 to 1,080
Monel 500 2,012 to 2,102 1,100 to 1,150
Monel 600 2,012 to 2,102 1,100 to 1,150
Monel 625 1,922 to 2,102 1,050 to 1,150

K-Monel Cold Drawn Pipe Brinell Hardness

Monel Grade Brinell Hardness (HB)
Monel 400 170 - 210
Monel 404 160 - 200
Monel 405 160 - 200
Monel 500 200 - 250
Monel K-500 200 - 300

Monel Alloy Pipe Chemical Composition

Grade Carbon Nickel Iron Manganese Copper Titanium Aluminum
Monel 400 0.12 65.0 1.5 1.0 32.0 – –
Monel k500 0.13 64.0 1.0 0.8 30.0 0.6 2.8

Monel Steel Square Pipe Mechanical Properties

Grade Yield Strength (0.2%Offset) Tensile Strength Elongation
(per square inch) (megapascal) (per square inch) (megapascal) %
Monel 400 35000 240 80000 550 40
Monel k500 115000 790 160000 1100 20

Monel Pipe Equivalent

Standards Country Monel k500 Monel 400
UNS North America N05500 N04400
WNR Russia 2.4375 2.4360
ASTM America B165 B165
ASME Australia SB165 SB165
JIS Japan – NW 4400
BS United Kingdom – NA 13
GOST Russia – МНЖМц 28-2,5-1,5
AFNOR France – NU-30M
EN Europe – NiCu30Fe
AMS United States – 4574
DIN German 2.4375 2.4360

Monel Metal Hot Finished Pipe Thermal Properties

Monel Grade Thermal Conductivity (W/m·K) Thermal Expansion (10⁻⁶ /°C)
Monel 400 35 - 45 13.8
Monel 404 30 - 40 14.0
Monel 405 30 - 40 14.0
Monel 500 35 - 50 15.0
Monel K-500 50 - 60 13.6

Monel Pipe Density

Element Density Melting Point
Monel K500 8.44 g/cm3 1350 °C (2460 °F)
Monel 400 8.8 g/cm3
