IBR Approved Fittings Manufacturer
| IBR Approved Fittings Manufacturer Product Information | |
|---|---|
| Seamless Fittings | 1/2" - 10″ |
| Welded Fittings | 1/2" - 48" |
| Type | DN15-DN1200 |
| Manufacturing Standard | ANSI B16.9, ANSI B16.28, DIN 2617, MSS-SP-43, BS4504 , BS1560 |
| MTC Certificate | EN 10204 3.1 and 3.2 |
| Angle | 7D-40D, 2.5D, 1D, 2D, 3D, 4D, 5D,1.5D, 6D |
IBR Steel Elbow and Bends Manufacturer in India
IBR Approved Carbon Steel Fittings
IBR Approved Fittings
IBR Steel Elbow
Table of Contents
- IBR Approved Fittings Specification
- IBR Approved Carbon Steel Fittings Standards
- IBR Approved Elbow Applications
- Stainless Steel IBR Fittings Size Chart
- Various Types Of IBR Approved Fittings
- Why Choose Steber Steel as Your IBR Pipe Fittings Manufacturer?
- IBR Certified Buttweld Fittings Pressure Ratings
- IBR Standard Stub End Dimensions
- IBR Approved End Cap Dimensions
- IBR Steel Tee Fittings Dimension
- IBR Elbow Dimension Chart
- Weight Chart of IBR Carbon Steel Weld Fittings
- IBR Fittings Testings
- IBR Approved Fittings HSN Code
- Stainless Steel IBR Fittings Benefits
- Carbon Steel IBR End Cap Tolerance
- Selecting the Ideal IBR Pipe Fittings
IBR Approved Fittings Specification
IBR Approved Fittings Sizes
- Seamless Fittings: 1/2 - 10 inch
- Buttweld Fitting : 1/2" -36"
- Welded Fittings: : 1/2" - 48"/li>
IBR Fittings Standards
- ANSI / ASME B16.9
- BS10 , BS1560
- ANSI/ ASME B16.28
- MSS-SP-95
- MSS-SP-83 , MSS-SP-43
IBR Pipe Fittings Form
- Elbow
- Reducer
- Tee
- Cap
- Stub End
- Pipe Bend
IBR Carbon Steel Pipe Fittings Origin
- Korean
- Janpanese
- European
- American
- UAE
IBR Stainless Steel Tee Testing
- HIC tested
- Ultrasonic test
- PMI Test
- NDT Test
IBR Approved Reducer Thickness
- SCH10 -SCH 100
- SCH 120 - SCH 160
- XXS
IBR Certified Elbow Bend Radius
- 1D
- 2D
- 3D
- 5D - 10D
IBR Standard End Cap Packaging
- Bundled
- Bubble Wraps
- Wooden Box
IBR Elbow Buttweld Fittings Markings
- Grades
- Manufacturers Name
- Heat Treatment
- Size
Manufacturer of IBR Elbow in Short and Long Radius as per ASME/ ANSI B16.9
IBR Approved Carbon Steel Fittings Standards
- ASME B16.28
- BS1560
- MSS-SP-43
- BS4504
- BS10
- ASME/ANSI B16.9
- BS4504
Supplier of Schedule 40 to Heavy Wall Buttweld Fittings for Boiler & Pressure Vessel Applications
IBR Approved Elbow Applications
Manufacturer of 3D and 5D Pipe Bend as per Indian Boiler Regulation (IBR) in various Sizes and Radius
Stainless Steel IBR Fittings Size Chart
IBR Approved Fittings Manufacturer in India provides a range of sizes at Fair Price
| O.D. (Outside Daimeter) And I.D. (Inside Daimeter) | Equivalent List | Threads Size In Inches | Diameter Of Nominal Pipe |
|---|---|---|---|
| 5/16 | 0.313 | 27 | 1/16 |
| 13/32 | 0.405 | 27 | 1/8 |
| 43/64 | 0.675 | 18 | 3/8 |
| 27/32 | 0.840 | 14 | 1/2 |
| 1-3/64 | 1.050 | 14 | 3/4 |
| 1-5/16 | 1.315 | 11-1/2 | 1 |
| 1-21/32 | 1.660 | 11-1/2 | 1-1/4 |
| 1-29/32 | 1.900 | 11-1/2 | 1-1/2 |
| 2-3/8 | 2.375 | 11-1/2 | 2 |
| 2-7/8 | 2.875 | 8 | 2-1/2 |
| 3-1/2 | 3.500 | 8 | 3 |
| 4 | 4.000 | 8 | 3-1/2 |
| 4-1/2 | 4.500 | 8 | 4 |
Exporter of IBR Approved Carbon Steel Fittings in shape of Elbow, Stub End, Tee, Cap, Reducer, Bend, and Cross
Various Types Of IBR Approved Fittings
IBR Approved Fittings Supplier in India provides a wide range of the most common types
ASME B16 9 IBR Approved A234 Gr Wp12 Short Radius Bend
IBR Carbon Steel A234 Gr Wpc Hot Induction Bend
Indian Boiler Regulations Wphy 70 Long Radius Bend
IBR Approved Wphy 65 3d Bend
Carbon Steel IBR Wphy 52 5d Bend
IBR Certified Astm A420 Wpl6 90 Deg Bend
IBR Standard Astm A234 Wpb 45 Degree Bend
Carbon Steel IBR Wphy 52 Lap Joint Stub End
Indian Boiler Regulations A420 Gr Wpl3 Short Stub End
SS IBR 904l Long Stub End
IBR Certified A420 Gr Wpl6 Pressure Tank End Caps
IBR Approved A234 Gr Wp9 Pressure Vessel End Caps
IBR Approved A403 Gr Wp347 Large Diameter End Caps
IBR Carbon Steel A234 Gr Wp5 Eccentric Reducer
IBR Standard A234 Gr Wp22 Concentric Reducer
Indian Boiler Regulations A403 Gr Wp321 Flanged Tee
IBR 310s Y Tee
Stainless Steel IBR 310 Barred Tee
ASME B16 9 IBR Approved A234 Gr Wp12 Lateral Tee
IBR Approved A234 Gr Wp11 Reducing Tee
Carbon Steel IBR A234 Gr Wp1 Equal Tee
IBR Steel A403 Gr Wp316 Reducing Elbow
IBR Certified Sus 304l Short Radius Elbow
IBR Approved A403 Gr Wp304 Long Radius Elbow
IBR Steel A234 Gr Wpc 180 Deg Elbow
Indian Boiler Regulations A234 Gr Wpb 90 Deg Elbow
IBR Approved A234 Gr Wpa 45 Deg Elbow
Why Choose Steber Steel as Your IBR Pipe Fittings Manufacturer?
- Custom Manufacturing
- High Pressure & Temperature Resistance
- IBR-Certified & Tested
- Competitive Pricing
- Wide Range of Products
- Premium Materials
IBR Certified Buttweld Fittings Pressure Ratings
| Size (in) |
WT (in) |
Schedule | I.d (in) |
OD (in) |
Allowable Stress(psi) | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Temperature(oF) | |||||||||||
| Maximum Allowable Pressure(psi) | |||||||||||
| 700 | 600 | 500 | 400 | 300 | 200 | 100 | |||||
| 16800 | 17300 | 18900 | 20000 | 20700 | 21300 | 23300 | |||||
| 1/2 | .109 | 401 | .622 | .84 | 4865 | 5010 | 5473 | 5792 | 5994 | 6168 | 6747 |
| 1 | .133 | 40 | 1.049 | 1.315 | 3698 | 3808 | 4160 | 4402 | 4556 | 4688 | 5128 |
| 1 1/4 | .14 | 40 | 1.38 | 1.66 | 3039 | 3129 | 3419 | 3618 | 3744 | 3853 | 4214 |
| 1 1/2 | .145 | 40 | 1.61 | 1.9 | 2731 | 2812 | 3072 | 3251 | 3365 | 3462 | 3788 |
| 2 | .109 | 10 | 2.157 | 2.375 | 1601 | 1648 | 1801 | 1906 | 1972 | 2030 | 2220 |
| 2 1/2 | .12 | 10 | 2.635 | 2.875 | 1451 | 1494 | 1632 | 1727 | 1788 | 1840 | 2012 |
| 3 | .12 | 3.26 | 3.5 | 1184 | 1220 | 1333 | 1410 | 1459 | 1502 | 1643 | |
| 3 1/2 | .12 | 10 | 3.76 | 4 | 1033 | 1064 | 1162 | 1230 | 1273 | 1309 | 1432 |
| 4 | .12 | 10 | 4.26 | 4.5 | 916 | 943 | 1030 | 1090 | 1128 | 1161 | 1270 |
| 5 | .188 | 5.187 | 5.563 | 1167 | 1202 | 1313 | 1389 | 1438 | 1480 | 1619 | |
IBR Standard Stub End Dimensions
| Normal Pipes Size For (NPS) | O.D. For (Outside Daimeter) of barrel |
Length Of (F) | Diameter Of (G) | Radius Of(R) | ||
|---|---|---|---|---|---|---|
| (Max.) | (Min.) | ASME B16.9 Short Pattern |
ASME B16.9 Long Pattern |
|||
| 1/2″ | 22.8 | 20.5 | 51 | 76 | 35 | 3 |
| 1″ | 35.0 | 32.6 | 51 | 102 | 51 | 3 |
| 1 1/4″ | 43.6 | 41.4 | 51 | 102 | 64 | 5 |
| 2″ | 62.4 | 59.5 | 64 | 152 | 92 | 8 |
| 3″ | 91.3 | 88.1 | 64 | 152 | 127 | 10 |
| 3 1/2″ | 104.0 | 100.8 | 76 | 152 | 140 | 10 |
| 4″ | 116.7 | 113.5 | 76 | 152 | 157 | 11 |
| 6″ | 171.3 | 167.5 | 89 | 203 | 216 | 13 |
| 8″ | 222.1 | 218.3 | 102 | 203 | 270 | 13 |
| 10″ | 277.2 | 272.3 | 127 | 254 | 324 | 13 |
| 14″ | 359.9 | 354.8 | 152 | 305 | 413 | 13 |
| 16″ | 411.0 | 405.6 | 152 | 305 | 470 | 13 |
| 20″ | 514.0 | 507.0 | 152 | 305 | 584 | 13 |
| 22″ | 565.0 | 558.0 | 152 | 305 | 641 | 13 |
| 24″ | 616.0 | 609.0 | 152 | 305 | 692 | 13 |
IBR Approved End Cap Dimensions
Supplier of IBR Approved Fittings are available in various Dimensions
| NPS Of Pipe Cap | O.D. (Outside Daimeter) Of D |
Length Of (H1) |
Length Of (H) |
|---|---|---|---|
| 24 | 610 | 305 | 267 |
| 22 | 559 | 254 | 254 |
| 20 | 508 | 254 | 229 |
| 18 | 457 | 229 | 203 |
| 16 | 406.4 | 203 | 178 |
| 14 | 355.6 | 191 | 165 |
| 12 | 323.8 | 178 | 152 |
| 10 | 273 | 152 | 127 |
| 8 | 219.1 | 127 | 102 |
| 6 | 168.3 | 102 | 89 |
| 5 | 141.3 | 89 | 76 |
| 4 | 114.3 | 76 | 64 |
| 3.1/2 | 101.6 | 76 | 64 |
| 3 | 88.9 | 64 | 51 |
| 2.1/2 | 73 | 51 | 38 |
| 2 | 60.3 | 44 | 38 |
| 1.1/2 | 48.3 | 38 | 38 |
| 1.1/4 | 42.2 | 38 | 38 |
| 1 | 33.4 | 38 | 38 |
| 3/4 | 26.7 | 25 | 25 |
| 1/2 | 21.3 | 25 | 25 |
IBR Steel Tee Fittings Dimension
| NPS Of Equal Tee | Center-to-End | Outside Daimeter (O.D.) at bevel |
|
|---|---|---|---|
| (M) Outlet | (C) Run | ||
| 1/2" | 25 | 25 | 21.3 |
| 3/4" | 29 | 29 | 26.7 |
| 1 1/4" | 48 | 48 | 42.2 |
| 1 1/2" | 57 | 57 | 48.3 |
| 2 1/2" | 76 | 76 | 73.0 |
| 3 1/2" | 95 | 95 | 101.6 |
| 4" | 105 | 105 | 114.3 |
| 5" | 124 | 124 | 141.3 |
| 6" | 143 | 143 | 168.3 |
| 14" | 279 | 279 | 355.6 |
| 16" | 305 | 305 | 406.4 |
| 18" | 343 | 343 | 457.0 |
| 20" | 381 | 381 | 508.0 |
| 24" | 432 | 432 | 610.0 |
IBR Elbow Dimension Chart
| Nominal Size Of Pipe | OD | 180° Returns | 90° Elbow | 45° Elbow | ||||
|---|---|---|---|---|---|---|---|---|
| (inch.) | LR | LR | SR | LR | ||||
| (millimeter) | (inch.) | Center to Center (inch.) |
Back to face (inch.) |
Center to Face (inch.) |
Center to Face (inch.) |
Center to Face (inch.) |
Radius (inch.) |
|
| 3/4 | 26.7 | 1.050 | 2 1/4 | 1 11/16 | 1 1/8 | – | 7/16 | |
| 1 | 33.4 | 1.315 | 3 | 2 3/16 | 1 1/2 | 1 | 7/8 | |
| 1 1/2 | 48.3 | 1.900 | 4 1/2 | 3 1/4 | 2 1/4 | 1 1/2 | 1 1/8 | 3 |
| 2 | 60.3 | 2.375 | 6 | 4 3/16 | 3 | 2 | 1 3/8 | 4 |
| 2 1/2 | 73.0 | 2.875 | 7 1/2 | 5 3/16 | 3 3/4 | 2 1/2 | 1 3/4 | 5 |
| 3 | 88.9 | 3.500 | 9 | 6 1/4 | 4 1/2 | 3 | 2 | 6 |
| 3 1/2 | 101.6 | 4.000 | 10 1/2 | 7 1/4 | 5 1/4 | 3 1/2 | 2 1/4 | 7 |
| 5 | 141.3 | 5.563 | 15 | 10 5/16 | 7 1/2 | 5 | 3 1/8 | 10 |
| 6 | 168.3 | 6.625 | 18 | 12 5/16 | 9 | 6 | 3 3/4 | 12 |
| 8 | 219.1 | 8.625 | 24 | 16 5/16 | 12 | 8 | 5 | 12 |
| 10 | 273.1 | 10.750 | 30 | 20 3/8 | 15 | 10 | 6 1/4 | 15 |
| 12 | 323.9 | 12.750 | 36 | 24 3/8 | 18 | 12 | 7 1/2 | 18 |
Weight Chart of IBR Carbon Steel Weld Fittings
| Normal Size Of Pipe | Kilogram | LBS |
|---|---|---|
| 1/2 | 0.11 | 0.25 |
| 1 | 0.23 | 0.5 |
| 1¼ | 0.41 | 0.9 |
| 2 | 1 | 2.2 |
| 2½ | 1.81 | 4 |
| 3½ | 3.79 | 8.35 |
| 4 | 6.12 | 13.5 |
| 5 | 9.98 | 22 |
| 8 | 32.21 | 71 |
| 10 | 48.53 | 107 |
| 14 | 92.99 | 205 |
| 16 | 125.19 | 276 |
| 20 | 190.51 | 420 |
| 22 | 235.87 | 520 |
| 26 | 330.67 | 729 |
| 30 | 442.25 | 975 |
| 36 | 640.47 | 1412 |
IBR Fittings Testings
- Micro Test
- Positive Material Identification - PMI Testing
- Flattening Test
- Dye Penetrant Test (DP Test)
- Hardness Test
- Intergranular Corrosion (IGC) Test
- Macro Test
- Hydrostatic Test
- Sulfide Stress Corrosion Cracking (SSC), NACE TM 0177
- Pitting Resistance Test
- Flaring Test
- Radiography Test
- Chemical Analysis - Spectro Analysis
- Hydrogen-Induced Cracking (HIC) Test, NACE TM0284
- Mechanical Testing Such as Tensile, Elongation, Reduction of Area
IBR Approved Fittings HSN Code
| HSN Code | Product |
|---|---|
| 73072900 | ASTM A234 WPB Fittings |
Stainless Steel IBR Fittings Benefits
- Compliance with safety standards
- Corrosion resistance
- Durability
- Compatibility
- Easy installation
Carbon Steel IBR End Cap Tolerance
| Tolerance Of IBR Approved Pipe Fittings | |||||||
|---|---|---|---|---|---|---|---|
| All Type Of Buttweld Fitting | 45 deg & 90 deg elbows | 180 Degree Returns | |||||
| Normal Size Of Pipe (NPS) | Outside Daimeter (O.D.) at Bevel |
I.D. (Inside Daimeter) at End |
Thickness Of Wall (WT) t / t1 |
Center to End Daimeter A-B-C-M | Back to Face Daimeter (K) |
Center to Center Daimeter (O) |
Align- ment of Ends (U) |
| 1/2 a 2 1/2 | 1 | 0,8 | Not | 2 | 7 | 7 | 1 |
| 4 | +2 -1 | 1,6 | than | 2 | 7 | 7 | 1 |
| 5 a 6 | +3 -1 | 1,6 | 87,50% | 2 | 7 | 7 | 1 |
| 8 | 2 | 1,6 | of nominal | 2 | 7 | 7 | 1 |
| 10 | +4 -3 | 3,2 | tickness | 2 | 7 | 7 | 2 |
| 12 a 18 | +4 -3 | 3,2 | 3 | 10 | 2 | 7 | |
| 20 a 24 | +6 -5 | 4,8 | 3 | 10 | 2 | 7 | |
Selecting the Ideal IBR Pipe Fittings
