Stainless Steel 317L Fittings

Stainless Steel 317L Fittings

Stainless Steel 304 Pipe Fittings Highlights
Size: 1/8” NB - 48”
Schedule SCH 5 to SCH 160
DIN standards DIN 2615-1 (Tee),DIN 2617 (Caps), DIN 2616-2 (Concentric Reducer)
Bend angle 15°, 135°, 22.5,90°, 180°, 45°, 60°
Testing NDT Testing , Macro Test, Flattening Test
Ends Bevelled, Plain Bevel, Compound Bevel

Manufacturer Of ASTM A403 WP317L Elbow in Custom Sizes

Stainless Steel 317l Fittings

Stainless Steel 317l Fittings

SUS 317L Elbow

SUS 317L Elbow

ASTM A403 Wp317l Buttweld Fittings

ASTM A403 Wp317l Buttweld Fittings


Table of Contents


Stainless Steel 317L Fittings Specification

Stainless Steel 317L Fittings Sizes

  • Seamless Fittings: 1/2" - 10″
  • Buttweld Fitting : 1/2" -36"
  • Welded Fittings: 1/2" - 48"
  • Schedule : SCH 10 to SCH 160
Sizes

WNR 1.4438 Stub End Standards

  • ANSI B16.9
  • MSS-SP-43
  • ASME B16.28
  • MSS-SP-83

Standards

INOX 317l Pipe Fittings Form

  • Reducer, Stub End
  • Cap
  • Elbow
  • Tee

Form

Stainless Steel 317l Pipe Fittings Radius

  • 5D
  • 3D
  • 2D
  • 1D
Radius

SS 317L Buttweld FittingsPackaging

  • Bubble Wraps
  • Bundled
  • Wooden Box

Packaging

317L Stainless Steel Pipe Fittings Method

  • Roll Bending
  • Mandrel
  • Hot Induction
  • Ram Type
Bending Method

SS 317l Fittings Origin

  • Janpanese
  • European
  • Korean
  • American





Origin

317l Welded Fittings Testing

  • Ultrasonic test
  • HIC tested
  • NDT Test
  • PMI Test




Testing

Stainless Steel 317L Elbow Bend angle

  • 15°
  • 30°
  • 180°
  • 90°
  • 135°
  • 45°
  • 22.5
  • 60°
Process

AISI 317l Elbow Marking

  • Heat Treatment
  • Size , Grades
  • Manufacturers Name


Marking

ASTM A403 Wp317l Buttweld Fittings Finish

  • Polish
  • Mill Finish
  • Special Finish

Finish

SS 317l Pipe Fittings Standards

  • DIN 2616
  • DIN 2615


Standards

ASTM A403 WP317L Buttweld Fittings Supplier Provide Polished And Nautral Finish

317l Welded Fittings Finishes

Finishing
Mirror 600 grit
BA Polishing Solution annealed A312gr TP317L pipe
Bright Annealed Annealed & Pickled (A&P)
No.4 Cold Drawn
2B 320,400 grit
180 grit polished Matt finish

Stainless Steel 317L Fittings Manufacturer in India Offering in Custom Sizes and Finishes, Designed to Provide Superior Corrosion Resistance in Harsh Chemical Environments

SS 317l Pipe Fittings Stocks in Seamless And Welded Type For Power Plant Applications

Applications of Stainless Steel 317L Elbow

Applications of Stainless Steel 317L Elbow
ASTM A403 Grade WP317L Reducer Available in 15 to 300 NB Sizes

Size Chart of UNS S31703 Cap

NPS Outside Dia 45° Elbows 180° Returns 90° Elbows
Long Radius Long Radius Short Radius Long Radius
Inch mm Radius Inch Center to Face Inch Back to face Inch Center to Center Inch Center to Face Inch Center to Face Inch
1/2" 0.840 21.3 5/8 1 7/8 2 – 1 1/2
1 1/2" 1.900 48.3 3 1 1/8 3 1/4 4 1/2 1 1/2 2 1/4
3 1/2" 4 101.6 7 2 1/4 7 1/4 10 1/2 3 1/2 5 1/4
3/4" 1.050 26.7 7/16 1 11/16 2 1/4 – 1 1/8
6" 6.625 168.3 12 3 3/4 12 5/16 18 6 9
10" 10.750 273.1 15 6 1/4 20 3/8 30 10 15
2" 2.375 60.3 4 1 3/8 4 3/16 6 2 3
4" 4.500 114.3 8 2 1/2 8 1/4 12 4 6
1 1/4" 1.660 42.2 – 1 2 3/4 3 3/4 1 1/4 1 7/8
1" 1.315 33.4 7/8 2 3/16 3 1 1 1/2
2 1/2" 2.875 73 5 1 3/4 5 3/16 7 1/2 2 1/2 3 3/4
5" 5.563 141.3 10 3 1/8 10 5/16 15 5 7 1/2
8" 8.625 219.1 12 5 16 5/16 24 8 12
3" 3.500 88.9 6 2 6 1/4 9 3 4 1/2
12" 12.750 323.9 18 7 1/2 24 3/8 36 12 18
To Get Recent Stainless Steel 317L Fittings Price List Click Here
Get 317L Stainless Steel Tee With Various Testing And Complete Documentation

Testings of AISI 317l Elbow

  • HIC Tested
  • Hydrostatic Test
  • PMI Test
  • 100% Radiography Tested
  • Magnetic Particle Examination
  • Ultrasonic Test

Documentation of ASTM A403 Wp317l

  • Dangerous Goods Certificate
  • Certificate of Insurance
  • IEC Code
  • Certificate of the Origin
  • Airway Bill (Awb)

Weight Chart of Stainless Steel 317l Pipe Fittings

Normal Pipe Size (A)Dia (B)Dia
 Approx. Weight - (KG)
1/4″ 0.80 0.80 0.10
1/8″ 0.69 0.66 0.06
3/8″ 0.94 0.97 0.15
3/4″ 1.24 1.38 0.32
1/2″ 1.11 1.17 0.22
1″ 1.43 1.74 0.52
1-1/2″ 1.87 2.36 0.99
1-1/4″ 1.72 2.07 0.76
2″ 2.25 2.86 1.49
3″ 3.05 4.23 4.41
2-1/2″ 2.68 3.57 2.78
4″ 3.72 5.24 6.72

Stainless Steel 317L Fittings Supplier in India Providing With High Strength-to-weight Ratios and Resistance to Corrosion, Ideal for Aerospace, and Refining Industries

SS 317L Buttweld Fittings Pressure Ratings

Temp. Ratings   Pressure Class
150 300
1 1/4 - 2 inch. 1/4 - 1 inch. 2 1/2 - 3 inch.
°C °F
-29 to 66 -20 to 150 300 1500 2000 1000
93 200 265 1350 1785 910
121 250 225 1200 1575 825
149 300 185 1050 1360 735
177 350 150 900 1150 650
204 400 - 750 935 560
232 450 - 600 725 475
260 500 - 450 510 385
288 550 - 300 300 300

HSN Code of 317L Stainless Steel Pipe Fittings

Grade HSN Code
Stainless Steel 317L Fittings 73072900

Various Types Of Stainless Steel 317L Fittings

Stainless Steel 317L Elbow

Stainless Steel 317L Elbow

SS 317L Tee

SS 317L Tee

ASTM A403 Wp317l Reducer

ASTM A403 Wp317l Reducer

UNS S31703 End Cap

UNS S31703 End Cap

WNR 1.4438 Stub End

WNR 1.4438 Stub End

SUS 317L Pipe Bend

SUS 317L Pipe Bend

AISI 317L Cross

AISI 317L Cross

INOX 317L Welded Pipe Fittings

INOX 317L Welded Pipe Fittings

317L Stainless Steel Hot Induction Bend

317L Stainless Steel Hot Induction Bend

Elbow Types

A403 Wp317l 45 Deg Elbow

A403 Wp317l 45 Deg Elbow

SUS 317L 90 Deg Elbow

SUS 317L 90 Deg Elbow

ASME 317L 180 Deg Elbow

ASME 317L 180 Deg Elbow

Stainless Steel 317L Long Radius Elbow

Stainless Steel 317L Long Radius Elbow

SS 317L Short Radius Elbow

SS 317L Short Radius Elbow

ASTM A403 Wp317l Reducing Elbow

ASTM A403 Wp317l Reducing Elbow

Tee Types

UNS S31703 Equal Tee

UNS S31703 Equal Tee

WNR 1.4438 Reducing Tee

WNR 1.4438 Reducing Tee

SUS 317L Lateral Tee

SUS 317L Lateral Tee

AISI 317L Barred Tee

AISI 317L Barred Tee

INOX 317L Y Tee

INOX 317L Y Tee

317L Stainless Steel Flanged Tee

317L Stainless Steel Flanged Tee

Reducer Types

A403 Wp317l Concentric Reducer

A403 Wp317l Concentric Reducer

SUS 317L Eccentric Reducer

SUS 317L Eccentric Reducer

End Cap Types

ASME 317L Large Diameter End Caps

ASME 317L Large Diameter End Caps

Stainless Steel 317L Pressure Vessel End Caps

Stainless Steel 317L Pressure Vessel End Caps

SS 317L Pressure Tank End Caps

SS 317L Pressure Tank End Caps

Stub End Types

ASTM A403 Wp317l Long Stub End

ASTM A403 Wp317l Long Stub End

UNS S31703 Short Stub End

UNS S31703 Short Stub End

WNR 1.4438 Lap Joint Stub End

WNR 1.4438 Lap Joint Stub End

Pipe Bend Types

SUS 317L 45 Degree Bend

SUS 317L 45 Degree Bend

AISI 317L 90 Deg Bend

AISI 317L 90 Deg Bend

INOX 317L 180 Deg Pipe Bend

INOX 317L 180 Deg Pipe Bend

317L Stainless Steel Long Radius Bend

317L Stainless Steel Long Radius Bend

A403 Wp317l Hot Induction Bend

A403 Wp317l Hot Induction Bend

SUS 317L Short Radius Bend

SUS 317L Short Radius Bend

SS 317l Pipe Fittings Tolerance Chart

NPS Outside Dia at Bevel Wall Thickness Of T I.D.at End Over-all Length Of H Center-to-End (Dimension A ,C ,B) Over-all Length Of F
1/2 to 2-1/2 +0.06 Not less than 87.5%m of nominal thickness +/- 0.06 +/- 0.06 +/- 0.12
-0.03
3 to 3-1/2 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.12
4 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.12
5 to 8 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.06 +/- 0.25
10 to 18 +0.16 +/- 0.12 +/- 0.09 +/- 0.09 +/- 0.25
-0.12
20 to 24 +0.25 +/- 0.19 +/- 0.09 +/- 0.09 +/- 0.25
-0.19
26 to 30 +0.25 +/- 0.19 +/- 0.19 +/- 0.12 +/- 0.38
-0.19
32 to 48 +0.25 +/- 0.19 +/- 0.19 +/- 0.19 +/- 0.38
-0.19

Stainless Steel 317L Fittings Supplier in India Specialized With a Perfect Balance of Strength and Corrosion Resistance, Used Extensively in Petrochemical and Oil and Gas Applications

What are the Manufacturing Standard of SS 317L Tee?

What are the Manufacturing Standard of SS 317L Tee?

ASTM A403 Wp317l Pipe Fittings Heat Treatment

Solution Treatment or Annealing 1010- 1121°C

Allowable Stress of SS 317l Fittings

Strength Mpa Ksi
Tensile 515 75

A403 Wp317l Material Welding Electrodes

Material Stick Welding Electrode Grade
ASTM A403 Wp317l Pipe Fittings E316

Equivalent of Stainless Steel 317L Fittings

Standard Type Origin of Country Value
Material USA 317L
DIN, WNr Germany 1.4438
UNS USA S31703
European steel name Europe X2CrNiMo18-15-4
Nirosta® from Krupp Thyssen Nirosta GmbH, Germany –
EN steel number Europe 1.4438
SUS/ JIS Japan SUS 317L
GOST Russia 03KH16H15M3
BS Britain (UK) 317S12
INOX Germany AISI 317L
GB China 00Cr19Ni13Mo3
UNI Italy –
SS Sweden 2367
PN Poland –
CSN Czechia 317L
SFS Finland 770
ONORM Austria –
AISI/ SAE USA 317L
SANS 50028-7 South Africa –

ASTM A403 Wp317l Reducer Chemical Composition

Grade 317L
Manganese 2
Phosphorus 0.045
Chromium 18-20
Nickel 11-15
Carbon 0.03
Silicon 1
Sulfur 0.03
Molybdenum 3.0-4.0
Iron Balance

Mechanical Properties of Stainless Steel 317l Buttweld Fittings

Grade Hardness Tensile Strength Elongation(%) Yield Point
317L 85 595 55 260

SUS 317L Welded Fittings Physical Properties

Specific Heat (0-100°C) 500 J.kg-1.°K-1
Thermal Expansion 16.5 mm/m/°C
Thermal Conductivity 14.6 W.m -1.°K-1
Electrical Resistivity 7.4 μohm/cm
Modulus Elasticity 193 GPa
Density 7.99 g/cm3

Stainless Steel 317L Fittings Supplier in India Supplying Corrosion Resistant Material in Various Finishes, Grades, and Custom Sizes, Perfect for Many Applications in Various Industries

What are Hot Forging Temperature of Stainless Steel 317l Pipe Fittings?

Temperatures Range 900 - 1150°C
