Stainless Steel 317L Forged Fittings
| Stainless Steel 317L Forged Fittings Description | |
|---|---|
| Standards | ASTM A403, ASME SA403, BS3799 |
| Melting Point | 2550 °F (1399 °C) |
| Types | Elbow, Tee, Coupling, Reducer |
| Pressure Class | Class 9000, Class 6000, Class 3000 |
| Size | 1/4" - 4 |
| Manufacturing Technique | Forged, CNC Machined |
| Density | 8.0 gram/ cm3 |
ASTM A403 WP317L Forged Elbow Manufacturer in India At Best Price
Stainless Steel 317L Forged Fittings
ASTM A403 WP317L Forged Elbow
SS 317L Threaded Tee
Table of Contents
- Stainless Steel 317L Forged Fittings Specification
- Popular Types of SUS 317L Forged Weld Fittings
- Size Chart of ASTM A403 WP317L Forged Elbow
- Standards of SS 317L Threaded Tee
- 317L Stainless Steel Socket Weld Fittings Test Certificates
- Mean Coefficient of Thermal Expansion of ASTM A403 WP317L Forged Elbow
- Applications of Stainless Steel 317L Forged Fittings
- Heat Treatment of 317L Stainless Steel SW Concentric Reducer
- Markings On The ASTM A403 Wp317l Screwed Fittings
- WNR 1.4438 Threaded Stub End Weight Chart
- Pressure Rating of Stainless Steel 317L Socket Weld Tee
- SS 317l Forged Fittings HSN Code
- Hot Forming of UNS S31703 Forged Reducer
- Points to Consider Before Selecting INOX 317l Forged Fittings
- What are the Features Provide ASTM A403 Wp317l Forged Tee?
- Chemical Composition of SS 317l Threaded Fittings
- WNR 1.4438 Socket Weld Inserts Mechanical Properties
- Physical & Hardness Properties of INOX 317L Threaded Elbow
- ASTM A403 Wp317l Socket Weld Fittings Equivalent Material
- What is the Difference Between 317 and Stainless Steel 317L Forged Fittings?
Stainless Steel 317L Forged Fittings Specification
American Standards of ASTM A403 WP317L Forged Elbow
- ASTM A182 S31703 (Forging)
- ASTM A479 S31703
- ASTM A276 S31703(Bar stock)
Sizes of 317L Stainless Steel Socket Weld Fittings
- Seamless : 1/2″ - 10″
- Welded : 1/2″ - 48″
ASTM A403 WP317L Forged Elbow Pressure Classes
- Class 3000
- Class 9000
- Class 6000
Threaded Types of Stainless Steel 317l Threaded Fittings
- BSP (ISO 228)
- BSPP (ISO 228-1)
- UNC (ANSI B1.1)
- UNF (ASME B1.1)
- NPT (ANSI B1.20.1)
- BSPT (DIN 2999)
- NPTF (ANSI B1.20.3)
SS 317l Forged Fittings meet Standards
- MSS SP-79
- BS 3799
- MSS SP-95
- MSS SP-97
- MSS SP-83
Form of UNS S31703 Forged Reducer
- Elbow
- Reducer
- Tee
- Cap
ASTM A403 Wp317l Forged Tee Bending Radius
- 1D
- 3D
- 2D
- 5D
SS 317l Threaded Fittings Testing
- Mechanical
- Ultrasonic
- Chemical
- PMI
Types of 317l Stainless Steel Screwed Fittings
- Socket
- Threaded
AISI 317L Forged Plug Documentation
- MTC EN 10204 type 3.1
- PMI Test Reports
- Mill Test Certificates
- Visual Inspection
Schedule of WNR 1.4438 Socket Weld Inserts
- SCH 160
- SCH XXS
- SCH 80
INOX 317L Threaded Elbow Origin
- Russia
- Janpanese
- American
- European
SUS 317L Forged Union Packaging
- Bubble Wraps
- Wooden Box
- Bundled
Manufacturing Technique UNS S31703 Forged Fittings
- Forged
- CNC Machined
AISI 317L Forged Plug Services
- Punching
- Cutting
- Welding
- Bending
Supplier Of SS 317L Threaded Tee Available in Reducing And Equal Type
Popular Types of SUS 317L Forged Weld Fittings
Stainless Steel 317L Forged Fittings Supplier in India Offers a Variety of Types Like Elbow, Cross , Coupling and Tee Etc
Stainless Steel 317L Socket Weld Elbow
SS 317L Socket Weld Tee
ASTM A403 Wp317l Socket Weld Cross
UNS S31703 Socket Weld Coupling
WNR 1.4438 Socket Weld Cap
SUS 317L Socket Weld Plug
AISI 317L Socket Weld Bushing
INOX 317L Socket Weld Hex Nipple
Stainless Steel 317L Socket Weld Boss
SS 317L Socket Weld Union
Most Common Types of Stainless Steel 317l Threaded Fittings
ASTM A403 Wp317l Threaded Elbow
UNS S31703 Threaded Tee
WNR 1.4438 Threaded Cross
SUS 317L Threaded Coupling
AISI 317L Threaded Cap
INOX 317L Threaded Plug
Stainless Steel 317L Threaded Bushing
SS 317L Threaded Hex Nipple
ASTM A403 Wp317l Threaded Boss
UNS S31703 Threaded Union
Types of 317L Stainless Steel Socket Weld Fittings Olets
Stainless Steel 317L Weldolet
SS 317L Sockolet
ASTM A403 Wp317l Thredolet
UNS S31703 Latrolet
WNR 1.4438 Elbolet
SUS 317L Nippolet
AISI 317L Sweepolet
INOX 317L Insert Weldolet
Stainless Steel 317L Brazolet
SS 317L Couplet
Ready Stock of 317L Stainless Steel SW Concentric Reducer In Odd Sizes With MTC
Size Chart of ASTM A403 WP317L Forged Elbow
| Normal Size Of Pipe | Depth Of Socket | Bore Of Socket | Thickness Of Socket | Dia Of Bore | Center-bottom of socket (A) | Thickness Of Body |
|---|---|---|---|---|---|---|
| 1/2 | 10 | 21.95 21.70 |
4.65 4.10 |
16.6 15 |
11.5 | 3.75 |
| 3/4 | 13 | 27.30 27.05 |
4.90 4.25 |
21.7 20.2 |
12.5 | 3.90 |
| 1 | 13 | 34.05 33.80 |
5.70 5.00 |
27.4 25.9 |
14 | 4.55 |
| 1¼ | 13 | 42.80 42.55 |
6.05 5.30 |
35.8 34.3 |
17 | 4.85 |
| 1½ | 13 | 48.90 48.65 |
6.35 5.55 |
41.7 40.1 |
21 | 5.10 |
| 2 | 16 | 61.35 61.10 |
6.95 6.05 |
53.5 51.7 |
25 | 5.55 |
| 2½ | 16 | 74.20 73.80 |
8.75 7.65 |
64.2 61.2 |
29 | 7.00 |
| 3 | 16 | 90.15 89.80 |
9.50 8.30 |
79.5 46.4 |
31.5 | 7.60 |
| 4 | 19 | 115.80 115.45 |
10.70 9.35 |
103.8 100.7 |
41.5 | 8.55 |
Stainless Steel 317L Forged Fittings Supplier in India, Corrosion Resistant Fittings Designed to Withstand Extreme Conditions in Oil & Gas, and Marine Industries
Stockist Of WNR 1.4438 Threaded Stub End As Per MSS SP-43 And MSS SP-79 Standard
Standards of SS 317L Threaded Tee
| Standard | |
|---|---|
| ANSI B16.11 | MSS-SP-95 |
| MSS-SP-79 | ASME B16.11 |
| BS3799 | ANSI ASME SA-182 |
| MSS-SP-83 | MSS-SP-97 |
100% Radiography Tested SUS 317L Forged End Cap Used In Petrochemical Industry
317L Stainless Steel Socket Weld Fittings Test Certificates
Mean Coefficient of Thermal Expansion of ASTM A403 WP317L Forged Elbow
| Temperature Range | |||
|---|---|---|---|
| °C | °F | cm/cm °C | in/in °F |
| 20-100 | 68-212 | 16.2 x 10-6 | 8.9 x 10-6 |
Applications of Stainless Steel 317L Forged Fittings
Heat Treatment of 317L Stainless Steel SW Concentric Reducer
| Method | Temperature |
|---|---|
| Heat Treatment | 2100-2300°F (1149-1260°C) |
Markings On The ASTM A403 Wp317l Screwed Fittings
- Material Designation
- Rating Designation
- Class Designation
- Specification Grade
- Manufacturers Name & Symbol
WNR 1.4438 Threaded Stub End Weight Chart
| DN-NPT | TAPPING DRILL SIZE MM | MAJOR DIA MM | PITCH MM | TPI |
|---|---|---|---|---|
| 1/8″ | 8.25 | 10.242 | 0.941 | 27 |
| 1/16″ | 6.00 | 7.895 | 0.941 | 27 |
| 1/4″ | 10.70 | 13.616 | 1.411 | 18 |
| 1/2″ | 17.40 | 21.223 | 1.814 | 14 |
| 3/8″ | 14.10 | 17.055 | 1.411 | 18 |
| 1″ | 28.50 | 33.228 | 2.209 | 11.5 |
| 3/4″ | 22.60 | 26.568 | 1.814 | 14 |
| 1½” | 43.50 | 48.054 | 2.209 | 11.5 |
| 1¼” | 37.00 | 41.985 | 2.209 | 11.5 |
| 2½” | 65.50 | 72.699 | 3.175 | 8 |
| 3″ | 81.50 | 88.608 | 3.175 | 8 |
| 2″ | 55.00 | 60.092 | 2.209 | 11.5 |
| 8″ | 211.673 | 219.075 | 3.175 | 8 |
| 6″ | 161.191 | 168.275 | 3.175 | 8 |
| 3½” | 94.30 | 101.316 | 3.175 | 8 |
| 12″ | 315.793 | 323.850 | 3.175 | 8 |
| 5″ | 134.384 | 141.300 | 3.175 | 8 |
| 10″ | 265.311 | 273.050 | 3.175 | 8 |
Stainless Steel 317L Forged Fittings Supplier in India, Delivering High-performance Fittings That Maintain Their Strength and Integrity at Extreme Temperatures
Pressure Rating of Stainless Steel 317L Socket Weld Tee
SS 317l Forged Fittings HSN Code
| Product | HSN code |
|---|---|
| Stainless Steel 317L Forged Fittinga | 73072200 |
Hot Forming of UNS S31703 Forged Reducer
| Method | Temperature |
|---|---|
| Hot Forming | 1652 - 2102°F (900 - 1150°C) |
Points to Consider Before Selecting INOX 317l Forged Fittings
What are the Features Provide ASTM A403 Wp317l Forged Tee?
- Good Corrosion Resistance
- Rugged Construction
- Great Finishing
- They Come With Seamless Edges
- Easy to Install
Chemical Composition of SS 317l Threaded Fittings
| Grade | SS 317L |
| P,Phosphorus | 0.045 max |
| Cr,chromium | 18.0 – 20.0 |
| Ni,Nickel | 11.0 – 15.0 |
| Mn,Manganese | 2.0 max |
| Si,silicon | 1.0 max |
| C,Carbon | 0.035 max |
| S,Sulfur | 0.030 max |
| Ni,Nickel | 11.0 – 15.0 |
| Mo,Molybdenum | 3.0 – 4.0 |
WNR 1.4438 Socket Weld Inserts Mechanical Properties
| Yield Strength | Elongation | Tensile Strength |
|---|---|---|
| 170 Mpa | 30% | 485 Mpa |
Physical & Hardness Properties of INOX 317L Threaded Elbow
| Density | Melting Point | Hardness(Brinell) | Hardness(Rockwell) |
|---|---|---|---|
| 8.0 gram/ cm3 | 1399 °C (2550 °F) | 217 max | 95 max |
ASTM A403 Wp317l Socket Weld Fittings Equivalent Material
| Grade | SS 317L |
|---|---|
| North America | UNS S31703 |
| Germany | Din X2CrNiMo18-15-4 |
| Japan | JIS SUS317L |
| Italy | UNI X 2 CrNiMo 1815 |
| UK | BSI 317S12 |
| France | AFNOR Z3CND19-15-04 |
| European | E.N 1.4438 |
| European | EURONORM X2CrNiMo18-15-4 |
| Sweden | SIS 23 67 |
| USA | AISI 317L |
Stainless Steel 317L Forged Fittings Manufacturer in India, Providing High-temperature Resistant Fittings That Perform Well in Heat Applications
What is the Difference Between 317 and Stainless Steel 317L Forged Fittings?
- Main Difference is the Carbon Content
- Made From SS 317 Grade Contain 0.08-0.15% Carbon & 317L Grade Control 0.030% Max Carbon
- Lower Carbon Content in 317L Grade Compared to the Ordinary 316 Stainless Steel Grades
