Steber Steel Solutions

Salzgitter Mannesmann Pipe Distributor

Salzgitter Mannesmann Pipe

Stockist Of Salzgitter Mannesmann Seamless Pipe Available in Large Diameter in India

  • Diameter Range: 114.3mm - 610mm

Table of Contents


Salzgitter Mannesmann Pipe Specification

Mannesmann Large-diameter pipe Joining Techniques

  • Flange connection
  • Coupling
  • Butt-weld joint
  • Slip welding joint




Size

Mannesmann Drilmax® Tubes Coatings And Lining

  • MAPEC® solutions
  • MAPEC® advanced solutions
  • Fusion-bonded epoxy
  • Epoxy flow coat
  • anticorrosion paints
  • zinc Coatings
  • polyurethane coatings

Thickness

Salzgitter Mannesmann HPK Tubes Tests

  • Bending tests
  • Collapse tests
  • Internal pressure tests
  • HIC test





Length

Mannesmann Stainless Steel Line pipe Dimension

Nominal size Outside diameter OD 0.2 0.5 1.0 1.5 2.0 2.5 3.0
mm inch¹ 0.008 0.020 0.031 0.059 0.079 0.098 0.118
1.5 0.059 1.1² 0.5²
3.0 0.118 2.6² 2.0¹ 1¹
5.0 0.197 4.0±0.15 3±0.15 1.4²
7.0 0.276 6.0±0.15 5±0.15 4±0.15 3²
8.0 0.315 6.4±0.15 5.6±0.15 4.4±0.15 3.6±0.15
10.0 0.394 8.4±0.15 7.6±0.15 6.4±0.15 5.6±0.15 4.4±0.25
14.0 0.551 12.4±0.08 11.6±0.15 10.4±0.15 9.6±0.15 8.4±0.15 7±0.15
16.0 0.630 14.4±0.08 13.6±0.08 12.4±0.15 11.6±0.15 10.4±0.15 9±0.15
20.0 0.787 17.6±0.08 16.4±0.08 15.6±0.15 14.4±0.15 13±0.15
22.0 0.866 19.6±0.08 18.4±0.08 17.6±0.08 16.4±0.15 15±0.15
26.0 1.024 24±0.08 23±0.08 22±0.08 21±0.08 20±0.15
28.0 1.102 26±0.08 25±0.08 24±0.08 23±0.08 22±0.15
32.0 1.260 30±0.15 29±0.15 28±0.15 27±0.15 26±0.15
38.0 1.496 36±0.15 35±0.15 34±0.15 33±0.15 32±0.15
40.0 1.575 38±0.15 37±0.15 36±0.15 35±0.15 34±0.15
45.0 1.772 42.6±0.20 41.4±0.20 40.6±0.20 39.4±0.20 38±0.20
48.0 1.890 45.6±0.20 44.4±0.20 43.6±0.20 42.4±0.20 41±0.20
55.0 2.165 52.6±0.25 51.4±0.25 50.6±0.25 49.4±0.25 48±0.25
60.0 2.362 57.6±0.25 56.4±0.25 55.6±0.25 54.4±0.25 53±0.25
70.0 2.756 67.6±0.30 66.4±0.30 65.6±0.30 64.4±0.30 63±0.30
80.0 3.150 77.6±0.35 76.4±0.35 75.6±0.35 74.4±0.35 73±0.35

Mannesmann Stainless Steel Boiler Tubes Stock In Size Range 20 to 63.5 mm in Mumbai

Sizes Of Mannesmann Pipe

Wall Thickness
Welded & size-rolled precision steel tubes 0.985 - ​4.5'' 25 - ​114.3 mm
Welded & drawn precision steel tubes 0.630 - ​4.724'' 16 - ​120 mm
Seamless & drawn precision steel tubes 0.059 - ​7.008'' 1.5 - ​178 mm
Hot-rolled steel tubes 0.677 - ​5.236'' 17.2 - ​133 mm

Buy Mannesmann Drill Pipe in Wall Thickness Range 1.5 to 10 mm At Best Price

Mannesmann Stainless Steel Cylinder Tubes Wall Thickness

Wall Thickness
Seamless & drawn precision steel tubes 0.008 - ​0.689'' 0.2 - ​17.5 mm
Welded & drawn precision steel tubes 0.031 - ​0.295'' 0.8 - ​7.5 mm
Welded & size-rolled precision steel tubes 0.069 - ​0.334'' 1.75 - ​8.5 mm
Hot-rolled steel tubes 0.079 - ​0.787'' 2 - ​20 mm

Salzgitter Mannesmann Mechanical Tubing Test

  • Steel heat analysis
  • Peel resistance of plastic coatings
  • SSC-4-point bending test (sulfide stress cracking)
  • Internal pressure tests
  • Bending tests
  • Notched-bar impact bending test
  • Cement-mortar test
  • HIC test (hydrogen-induced cracking)
  • CD tests
  • Collapse tests
Salzgitter Mannesmann Line Pipe Available In HSAW, HFI And LSAW Type

Mannesmann HFI Pipe Production Process

Mannesmann HFI Pipe Production Process
Mannesmann Mechanical Tubing Ex-stocks In Alloy And Carbon Steel Material

Material Of Mannesmann Stainless Steel Cylinder Tubes

Material Seamless & drawn precision steel tubes Welded & drawn precision steel tubes Welded & size-rolled precision steel tubes Hot-rolled steel tubes
Structural steels E235, E460, E355, E420 E145, E235,E420, E460, E355 S420MC, E195, E420, S460MC, E235, E355, E460, S235 up to P460NL2
Special steels Air-hardening : MW1000L, MW700L KSG44, KSG1000, KSG800 -
  • Ball bearing steels: 100Cr6
  • Air-hardening steels: MW1000L, MW700L
Quench-and-temper steels
  • Manganese-boron steels: 26MnB5, 34MnB5, 22MnB5,
  • Non-alloyed steels: C60, C35, C45, C50, Cf53
  • Alloyed steels: 25CrMo4, 42CrMo4, 34CrMo4
  • Manganese-boron steels: 22MnB5, 26MnB5, 34MnB5
  • Non-alloyed steels: C35, C22, C45, C60
  • Manganese-boron steels: 26MnB5, 22MnB5, 34MnB5
  • Non-alloyed steels: C22, C45, C35, C60
  • Non-alloyed steels: C35, C50,C45, C60
  • Manganese-boron steels: 26MnB5, 22MnB5, 34MnB5
  • Alloyed steels: 25CrMo4, 34CrMo4, 42CrMo4
Case-hardening steels 20MoCr4, SAE8617H ,16MnCr5, 20MnCr5, - - 20MoCr4, SAE8617H, 16MnCr5, 20MnCr5,

Salzgitter Mannesmann HPS Tubes Certificate And Approvals

  • DIN EN ISO 14001
  • DIN EN ISO 9001
  • DIN EN ISO 50001
  • DIN ISO 45001
  • AD 2000 HP0 / W0
  • DNV GL
  • DCA certificate
  • AD 2000 HP0 / W0
  • Lloyds Register
  • API 5L / API 5CT
  • KIWA
  • Bureau Veritas
  • TÜV Nord Certificate for HFI-welded structural hollow section
  • DVGW certificate
  • TÜV Süd Certficate on load securing

Tolerances Of Mannesmann Stainless Steel HPL Tubes

Nominal size OD Tolerance
mm inch¹ inch¹
1.5 0.059 ± 0.10 ± 0.004
3.0 0.118 ± 0.10 ± 0.004
5.0 0.197 ± 0.08 ± 0.003
7.0 0.276 ± 0.08 ± 0.003
8.0 0.315 ±0.08 ± 0.003
10.0 0.394 ± 0.08 ± 0.003
14.0 0.551 ±0.08 ± 0.003
16.0 0.630 ±0.08 ± 0.003
20.0 0.787 ± 0.08 ± 0.003
22.0 0.866 ± 0.08 ± 0.003
26.0 1.024 ± 0.08 ± 0.003
28.0 1.102 ± 0.08 ± 0.003
32.0 1.260 ±0.15 ± 0.006
38.0 1.496 ±0.15 ± 0.006
40.0 1.575 ±0.15 ± 0.006
45.0 1.772 ±0.20 ± 0.008
48.0 1.890 ±0.20 ± 0.008
55.0 2.165 ± 0.25 ± 0.010
60.0 2.362 ±0.25 ± 0.010
70.0 2.756 ± 0.30 ± 0.012
80.0 3.150 ± 0.35 ± 0.014

Benefits Of Salzgitter Mannesmann Pipe

Benefits Of Salzgitter Mannesmann Pipe

Mannesmann Stainless Steel Economizer Tubes Standards

Product Standards
Seamless & drawn precision steel tubes EN 10305-1, EN 10305-4
Welded & drawn precision steel tubes EN 10305-2
Welded & size-rolled precision steel tubes EN 10305-3
Hot-rolled steel tubes EN 10210-1, EN 10216-1 up to -4,EN ISO 3183, ASTM A519,EN 10294, EN 10297,ASTM A106, ASTM A192,ASTM A213,ASTM A210

Applications Of Salzgitter Mannesmann Mechanical Tubing

  • Minerals & Exploration
  • Driveline
  • Heat Transfer & Renewables
  • Alternative Drives
  • Vehicle Chassis
  • Mechanical Engineering
  • Hydraulic Machinery
  • Oil & Gas

Mannesmann HPZ Tubes Delivery Condition

Designation Symbol
Cold-finished, soft +LC
Cold finished, hard +C
Normalized +N
Soft annealed +A
Cold finished and stress-relieved +SR
As rolled +AR
Welded and size-rolled +CR1
Welded and size-rolled +CR2
Quenched and tempered +QT
