ASTM A420 WPL6 Pipe Fittings

ASTM A420 WPL6 Pipe Fittings

ASTM A420 WPL6 Pipe Fittings Highlights
Size:  1/2″-24″
EN standards EN 10253-2
JIS (Japan) Standards JIS B2312, JIS B2313
Ends Plain Bevel, Bevelled, Compound Bevel
Testing NDT Testing , Ultrasonic test, Destructive testing
Bend angle 15°, 30°,45°, 60°, 90°, 180°
Impact Test Temp -45°C, -195°C

SA 240 Gr WPL6 Material Manufacturer in India

ASTM A420 WPL6 Pipe Fittings

ASTM A420 WPL6 Pipe Fittings

SA 240 Gr WPL6 Tee

SA 240 Gr WPL6 Tee

ASTM A420 WPL6 Elbow

ASTM A420 WPL6 Elbow


Table of Contents


ASTM A420 WPL6 Pipe Fittings Specification

A420 Wpl6 Fittings Sizes

  • Seamless : 1/2″ to 24″
  • Welded : 24″ to 96"
  • Buttweld : 1/2" to 36"
  • Schedule : SCH 5 - SCH 160, XXS


Sizes

ASTM A420 Wpl6 Pipe Fittings Standards

  • ASME B16.28
  • ANSI B16.9
  • MSS-SP-83, MSS-SP-95
  • MSS-SP-43


Standards

SA420 Wpl6 Buttweld Pipe Fittings Form

  • Reducer, Stub End
  • Cap
  • Elbow
  • Pipe Bend
  • Tee

Form

ASTM A420 WPL6 Material Origin

  • Korean
  • European
  • Janpanese
  • India
  • American



Origin

SA 420 Gr Wpl6 Welded Fittings Testing

  • HIC tested
  • Ultrasonic test
  • PMI Test
  • NDT Test




Testing

A 420 Wpl6 Elbow Bend angle

  • 15°
  • 22.5
  • 30°
  • 45°
  • 60°
  • 90°
  • 180°
  • 135°
Process

SA 420 Gr Wpl6 LR Elbow Radius

  • 1D
  • 2D
  • 3D
  • 5D
  • 10D
Radius

SA 420 Gr Wpl6 Reducer Packaging

  • Bundled
  • Bubble Wraps
  • Wooden Box


Packaging

Carbon Steel WPL6 Elbow Bending Method

  • Mandrel
  • Roll Bending
  • Ram Type
  • Hot Induction

Bending Method

ASME SA420 WPL6 Lateral Tee GOST Standards

  • GOST 17376
  • GOST 17375 (induction elbow)
  • GOST 17379
  • GOST 17375
  • GOST 17378





Marking

A420 Wpl6 Concentric Reducer DIN Standards

  • DIN 2618 (saddle)
  • DIN 2617 (Caps)
  • DIN 2616-1 (Eccentric Reducer)
  • DIN 2616-2 (Concentric Reducer)
  • DIN 28011 (Torispherical heads)
  • DIN 2605-2 (Elbow)
  • DIN 2615-2 (Tee)
  • DIN 2605-1 (Elbow)
  • DIN 2615-1 (Tee)
Finish

ASME SA420 Gr WPL6 End Cap Meet the Requirements

  • NACE MR0103
  • HIC tested
  • MTC EN 10204 3.1/ 3.2 certificate
  • Sour service
  • ISO 15156
  • NACE TM-0284
  • IBR
  • NACE MR0175
  • NORSOK

Standards

Manufacturer of ASTM A420 Grade WPL6 Elbow and Bend for extreme cold weather and deep sea pipelines

ASTM A420 Grade WPL6 ElboW Applications

ASTM A420 Grade WPL6 ElboW Applications

Exporter of SA 420 WPL6 Buttweld Tee and Pipe Cap as per ASME B16.9

ASTM A420 WPL6 Pipe Fittings Supplier offers various Standards

Carbon Steel ASTM A420 WPL6 Buttweld Fittings Standards

  • ASME B16.9
  • JIS B2313
  • JIS B2312
  • GOST 17375
  • GOST 17376
  • GOST 17379
  • GOST 17378
  • EN 10253-2
  • GOST 17375
Manufacturing A420 WPL6 Fittings via Seamless and Welded Method for High Pressure Fluids

LTCS A420 WPL6 Welded Fittings Applicable Fluids

  • Oil
  • Water
  • Air
  • Steam
  • Gas
A Saudi Aramco Approved A420 Gr WPL6 Pipe Fittings Manufacturer offer MTC 3.1 and Third Party Inspection

A420 Carbon Steel Buttweld Elbow Test Certificate

  • Third Party Inspection Report
  • NABL approved Laboratory Test Reports
  • Fumigation Certificates
  • EN 10204/3.1B,
  • Heat Treatment Charts
  • Guarantee Letter
  • Raw Materials Certificate
  • 100% Radiography Test Report
  • QAP (Quality Assurance Plan)

Various Types Of ASTM A420 WPL6 Pipe Fittings

ASTM A420 WPL6 Pipe Fittings Supplier in India provides a wide range of the most common types

LTCS A420 WPL6 Eblow Types

ASTM A420 WPL6 45 Deg Elbow

ASTM A420 WPL6 45 Deg Elbow

A420 Wpl6 90 Deg Elbow

A420 Wpl6 90 Deg Elbow

SA 420 Gr Wpl6 180 Deg Elbow

SA 420 Gr Wpl6 180 Deg Elbow

ASTM A420 Grade WPL6 Long Radius Elbow

ASTM A420 Grade WPL6 Long Radius Elbow

Carbon Steel Wpl6 Short Radius Elbow

Carbon Steel Wpl6 Short Radius Elbow

A420 WPL6 Reducing Elbow

A420 WPL6 Reducing Elbow

Types of ASTM A420 WPL6 Tee

Wpl6 Equal Tee

Wpl6 Equal Tee

ASTM A420 WPL6 Reducing Tee

ASTM A420 WPL6 Reducing Tee

SA 420 Wpl6 Lateral Tee

SA 420 Wpl6 Lateral Tee

Carbon Steel WPL6 Barred Tee

Carbon Steel WPL6 Barred Tee

A420 Wpl6 Y Tee

A420 Wpl6 Y Tee

SA 420 Gr WPL6 Flanged Tee

SA 420 Gr WPL6 Flanged Tee

Types of A420 Grade WPL6 Reducer

A420 Wpl6 Concentric Reducer

A420 Wpl6 Concentric Reducer

Carbon Steel Wpl6 Eccentric Reducer

Carbon Steel Wpl6 Eccentric Reducer

Types of Sa 420 Gr Wpl6 End Caps

ASME SA420 WPL6 Large Diameter End Caps

ASME SA420 WPL6 Large Diameter End Caps

A420 Wpl6 Pressure Vessel End Caps

A420 Wpl6 Pressure Vessel End Caps

ASTM A420 WPL6 Pressure Tank End Caps

ASTM A420 WPL6 Pressure Tank End Caps

Types of Wpl6 Carbon Steel Stub End

ASTM A420 Gr Wpl6 Long Stub End

ASTM A420 Gr Wpl6 Long Stub End

Sa 420 Gr Wpl6 Short Stub End

Sa 420 Gr Wpl6 Short Stub End

A420 Gr Wpl6 Lap Joint Stub End

A420 Gr Wpl6 Lap Joint Stub End

Types of A420 Gr Wpl6 Pipe Bend

Sa 420 Gr Wpl6 45 Degree Bend

Sa 420 Gr Wpl6 45 Degree Bend

ASTM A420 Wpl6 3 D Bend

ASTM A420 Wpl6 3 D Bend

ASME SA420 WPL6 5D Bend

ASME SA420 WPL6 5D Bend

ASTM A420 Gr Wpl6 Long Radius Bend

ASTM A420 Gr Wpl6 Long Radius Bend

A420 Gr Wpl6 Hot Induction Bend

A420 Gr Wpl6 Hot Induction Bend

Carbon Steel WPL6 Short Radius Bend

Carbon Steel WPL6 Short Radius Bend

SA 240 Gr WPL6 Pipe Fittings Weight Chart

DN (Normal Pipe Sizes) Sch 80S Sch 40S Sch 10S
90 Deg Elbow 45 Deg Elbow Equal Pipe Tee 90 Deg Elbow 45 Deg Elbow Equal Pipe tee 90 Deg Elbow 45 Deg Elbow Equal Pipe tee
8 .04 .03 .07 .03 .02 .06 .02 .01 .03
15 .10 .05 .14 .08 .04 .10 .06 .03 .09
25 .22 .14 .38 .15 .11 .29 .14 .08 .28
40 .51 .29 1.02 .40 .23 .86 .30 .17 .68
50 .91 .59 1.59 .70 .4 1.28 .50 .25 .85
80 2.97 1.50 4.45 2.20 1.08 3.31 1.25 .63 1.77
90 4.00 2.00 5.44 2.83 1.42 4.08 1.70 .75 2.67
100 6.18 2.81 7.71 4.47 2.09 5.27 2.10 1.08 3.46
150 16.32 8.16 13.61 1.89 5.44 1.99 5.45 2.72 8.07
250 51.71 25.86 49.90 38.56 19.27 35.38 18.15 9.75 26.46
300 79.38 39.69 83.91 59.42 29.71 62.14 25.80 13.62 39.46

ASME SA 420 Gr Wpl6 Buttweld Fittings Dimensions Schedule

Supplier of ASTM A420 WPL6 Pipe Fittings are available in appropriate Dimensions

Pipe Size ASTM A420 Carbon Steel 180° Return Long Radiu ASTM A420 Carbon Steel 90° Elbow ASTM A420 Carbon Steel 45° Elbow
STD X Long Radiu Short Radiu 3R Long Radiu 3R
STD X SCH. 160 XX STD X STD X STD X STD X
½ .35 .18 .25 .09 .19
1 .75 1.00 .40 .50 .60 .75 .25 0.25 .31
2 3.23 4.40 1.60 2.20 3.25 3.50 1.00 1.50 3.00 4.00 .81 1.19 1.5 2.1
3 10.25 13.00 5.00 6.50 8.50 11.0 3.00 4.25 10.0 13.0 2.63 3.50 5.00 7.00
4 18.5 25.0 9.00 13.5 18.0 20.0 6.25 8.50 18.0 25.0 4.50 6.10 9.00 13.0
6 50.0 70.0 24.5 35.0 57.0 65.0 18.0 23.0 45.0 70.0 12.0 17.5 23.0 35.0
8 95.0 142 50.0 71.0 120 118 34.0 47.5 90.0 140 23.0 35.0 45.0 70.0
10 117 215 88.0 107 260 58.0 70.0 159 218 43.0 53.0 80.0 109
14 325 400 160 205 572 105 140 298 400 80.0 100 149 200
16 412 550 206 276 132 174 390 520 100 135 195 260
20 640 830 320 420 210 275 610 810 160 206 305 405
24 890 1200 460 600 298 392 875 1170 238 300 438 585

A420 Wpl6 Stub End Testings

Suuplier of SA 240 Gr WPL6 Material offers Ultrasonic, Tensile and Hardness Test

  • Ultrasonic Testing
  • Dimensional Check
  • Tensile Testing
  • Visual Inspection
  • Hardness Testing
  • Magnetic Particle Testing
  • Pressure Testing
  • Impact Testing (Charpy)
  • Radiographic Testing (X-ray)
  • Chemical Analysis
  • Flaring Test

ASTM A420 WPL6 Pipe Fittings Size Chart

Equivalent List Diameter Of Nominal Pipe OD and ID Threads Size In In
.313 1/16 5/16 27
1.050 3/4 1-3/64 14
.675 3/8 43/64 18
.405 1/8 13/32 27
.840 1/2 27/32 14

.540

 1/4 35/64 18
1.315 1 1-5/16 11-1/2
1.660 1-1/4

1-21/32
1.900 1-1/2
2.375 2 2-3/8
2.875 2-1/2 2-7/8 8
3.500 3 3-1/2 8
4 3-1/2 4 8
4.500 4 4-1/2 8

A420 Wpl6 Low Temperature Carbon Steel Reducer Temperature Range

*DSI *Temperatures
16.8 700
17.3 650
17.9 600
20 200
20 150
20 300
19 500
19.9 400
20 -20~100

ASTM A420 WPL6 Impact Test

Specimen Size A* B*
mm J ft·lbf J ft·lbf
10 by 2.5 5.4 4 4.1 3
10 by 5.0 9.5 7 7.0 5
10 by 7.5 13.6 10 10.8 8
10 by 10.0 17.6 13 13.6 10

SA 420 Gr Wpl6 Cap Dimensions

NPS O.D.Of D Length Of (H1) Length Of (H)
1/2 21.3 25 25
1 33.4 38 38
1.1/2 48.3 38 38
2 60.3 44 38
2.1/2 73 51 38
3 88.9 64 51
3/4 26.7 25 25
3.1/2 101.6 76 64
4 114.3 76 64
5 141.3 89 76
6 168.3 102 89
8 219.1 127 102
10 273 152 127
12 323.8 178 152
14 355.6 191 165
16 406.4 203 178
22 559 254 254
24 610 305 267

How to Install ASTM A420 WPL6 Pipe Fittings ?

  • Cut the pipe to the desired length
  • Prepare the fitting
  • Align the fitting and pipe
  • Inspect the weld
  • Weld the fitting to the pipe

A420 Wpl6 Seamless Tee Dimensions

NPS O.D. at bevel Center-to-End
(C) Run (M) Outlet
1" 33.4 38 38
1/2" 21.3 25 25
3/4" 26.7 29 29
2" 60.3 64 64
1 1/4" 42.2 48 48
1 1/2" 48.3 57 57
2 1/2" 73.0 76 76
3 1/2" 101.6 95 95
3" 88.9 86 86
3" 88.9 86 86
4" 114.3 105 105
5" 141.3 124 124
6" 168.3 143 143
8" 219.1 178 178
10" 273.0 216 216
12" 323.8 254 254
14" 355.6 279 279
16" 406.4 305 305
18" 457.0 343 343
20" 508.0 381 381
22" 559.0 419 419
24" 610.0 432 432

ASTM A420 Gr WPL6 Stub End Dimensions

NPS Outside Daimeter of barrel Diameter Of (G) Radius Of(R) Length Of (F)
(Min.) (Max.) Long Pattern Short Pattern
1″ 32.6 35.0 51 3 102 51
1 1/2″ 47.5 49.9 74 6 102 51
2 1/2″ 72.2 75.3 105 8 152 64
3/4″ 25.9 28.1 43 3 76 51
3 1/2″ 100.8 104.0 140 10 152 76
1/2″ 20.5 22.8 35 3 76 51
1 1/4″ 41.4 43.6 64 5 102 51
2″ 59.5 62.4 92 8 152 64
3″ 88.1 91.3 127 10 152 64
4″ 113.5 116.7 157 11 152 76
5″ 140.5 144.3 186 11 203 76
6″ 167.5 171.3 216 13 203 89
8″ 218.3 222.1 270 13 203 102
10″ 272.3 277.2 324 13 254 127
12″ 323.1 328.0 381 13 254 152
14″ 354.8 359.9 413 13 305 152
18″ 456.0 462.0 533 13 305 152
24″ 609.0 616.0 692 13 305 152

ASME SA 420 Gr Wpl6 Bend Dimensions

Standard Of Pipe 2,5D Specification . Bauart 5
Size Dia. [OD] CLR CLR CLR
20 26,9 67 110 -
25 33,7 84 110 -
32 42,4 106 110 -
40 48,3 212 110 -
50 60,3 151 125 -
65 76,1 190 - 175
80 88,9 222 - 205
100 114,3 286 - 270
125 139,7 350 - 330
150 168,3 421 - 390
200 219,1 - - 510
300 323,9 - - 775
350 355,6 - - 850
400 406,4 - - 970
500 508 - - 1245

ASTM A420 WPL6 Pipe Fittings HSN Code

Product HSN Code
A420 Grade WPL6 73079390

Carbon Steel Wpl6 Pipe Fittings Pressure Ratings

Temperature Ratings Pressure Class
300
1/4 - 1 inch. 1 1/4 - 2 inch. 2 1/2 - 3 inch.
(oF) (oC)
550 288 300 300 300
500 260 510 450 385
450 232 725 600 475
400 204 935 750 560
350 177 1150 900 650
300 149 1360 1050 735
250 121 1575 1200 825
200 93 1785 1350 910
-20 to 150 -29 to 66 2000 1500 1000

ASTM A420 Gr WPL6 Equivalent

Material Pipes Flanges Fittings Nuts And Bolts Valves
Carbon Steel
Alloy
Low-Temp		 A333 Grade 6 A350 Grade LF2 A420 Grade WPL6 A320 Grade L7
A194 Grade 7		 A352 Grade LCB
A333 Grade 3 A350 Grade LF3 A420 Grade WPL3 A352 Grade LC3

A420 WPL6 Reducer Mechanical Properties

Properties Tensile Strength, min. Yield Strength, min. Elongation %, min
Value ksi MPa ksi MPa Longitudinal Transverse
65-95 415-655 35 240 22 12

ASTM A420 Gr WPL6 Chemical Composition

Elements Value %
Nickel [Ni] ≤0.40
Sulfur [S] ≤0.040
Vanadium[V] ≤0.08
Silicon [Si] 0.15-0.40
Chromium [Cr] ≤0.30
Phosphorus [P] ≤0.035
Manganese [Mn] 0.50-1.35
Carbon [C] ≤0.30
Columbium [Cb] ≤0.02
Copper [Cu] ≤0.40
Molybdenum [Mo] ≤0.12

Supply ASTM A 420 Gr Wpl6 to various Countries

Country Name Flag Country Name Flag
Algeria Algeria Nigeria Nigeria
Tunisia Tunisia South Africa South Africa
Kenya Kenya Angola Angola
Tanzania Tanzania Morocco Morocco
Egypt Egypt Ethiopia Ethiopia
Zambia Zambia Ghana Ghana
