Mild Steel Pipe
| Mild Steel Pipe Highlights | |
|---|---|
| OD | 21.3MM~762MM |
| Thickness | 4.5mm to 60mm |
| Origin | Asian, Africa,Indian, UK,Chinese, American, Japan, Korean, Gulf, European, |
| MTC | EN 10204 3.1, ISO 9001:2005 |
| Cutting Techniques | Tapping, Burrless Cuts, Laser |
| Quenching Temperature | 910℃±10℃ |
MS Seamless Pipe Manufacturer in India
Mild Steel Pipe
MS Seamless Pipe
Mild Steel ERW Pipe
Table of Contents
- Mild Steel Pipe Specification
- MS Seamless Pipe Pressure Rating Chart
- Mild Steel Pipe Manufacturing Process
- Mild Steel Pipe Size Chart
- MS Rectangular Pipe Ex Stock
- Mild Steel Pipe HSN Code
- MS Round Pipe Tolerance
- Various Types Of Mild Steel Pipe
- Thin Wall MS Pipe Roughness Coefficient
- Mild Steel Pipe Available Grades
- MS Pipe Grades Chart
- Mild Steel Casing Pipe Test Certificate
- Heat Treatment of MS Hollow Pipes
- Galvanized Mild Steel Seamless Pipe Dimensions
- Black Mild Steel Pipe Coatings
- MS Square Pipe Weight Chart
- MS Round Pipe Applications
- Mild Steel cement lined Pipe Testings
- MS Welded Pipe Maximum Permissible Pressure And Temperature
- Mild Steel Pipe Chemical Composition
- MS Exhaust Pipe Mechanical Properties
Refer Mild Steel ERW Pipe Specification And Size Chart
Mild Steel Pipe Specification
MS Exhaust Pipe Sizes
- Size: 15 to 900 NB
- Width: 500 mm – 2500 mm
MS Pipe Form
- Square
- Round
- Rectangular
MS Seamless Pipe Length
- Double Random
- Single Random
- Cut length Pipe
MS Pipe Grades
- IS 3589 pipe
- IS 1239 pipe
- IS 3589 Fe 330 Pipe
- IS 3589 Fe 410 Pipe
- IS 2062 Pipe
- IS 1161 Yst 310 Pipe
- IS 3601 Pipe
- IS 1161 Yst 210 Pipe
- IS 1978 Pipe
Mild Steel Pipe Standard
- DIN
- JIS
- SAE
- ASTM
- AISI
- GB
- EN
- AMS
- ASME
Mild Steel Casing Pipe Schedule
- Schedule XXS
- Schedule 160
- Schedule 80
- Schedule 40
- Schedule 20
- Schedule 10
- Schedule 5
Galvanized Mild Steel Seamless Pipe Allowable stress
- 108 MPa
MS Welded Pipe Tolerance
- ±1%
MS Seamless Pipe Hardness
- 131 to 156 HBS
Mild Steel Erw Pipe Marking
- Standard
- Grade
- Heat No.
- Manufacturer/Supplier name
- Length
MS Hollow Round Pipe Cutting Techniques
- Burrless Cuts
- Sawing
- Laser
- Tapping
- Water-Jet
Thin Wall Mild Steel Pipe Technique
- Bright annealed
- Cold drawn
- Hot extruding
- Hot drawn
- Solid solution
Mild Steel cement lined Pipe Packaging
- Pasltic bag
- Wodden box
- Bundles
- Wrapped with polypropylene sheets
MS Hollow Pipes Testing Methods
- Intergranular Corrosion Test
- Hardness Test
- Ultrasonic Test
- Surface Roughness Test
- Non Destructive Test
- Positive Material Identification
- Radiography Test
- Macro & Micro Test
MS Exhaust Pipe Value Added Services
- Mechanical finishing
- Polishing & grinding
- Cold extrusion molding
- Recrystallization annealing
- Annealing
- Forging mold blank
- Blanking
- Carburizing
- Tempering
- Mechanical rough machining
MS Sqaure Pipe Pressure Rating Chart
MS Seamless Pipe Pressure Rating Chart
| NPS | 1 | 2 | 3/4 | 3 | 4 | 6 | 10 | 12 |
|---|---|---|---|---|---|---|---|---|
| SCH | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 |
| 100 | 2857 | 1783 | 2447 | 1693 | 1435 | 1143 | 913 | 855 |
| 200 | 2857 | 1783 | 3059 | 1693 | 1435 | 1143 | 913 | 855 |
| 400 | 2857 | 1783 | 3059 | 1693 | 1435 | 1143 | 913 | 855 |
| 500 | 2857 | 1783 | 3059 | 1693 | 1435 | 1143 | 913 | 855 |
| 600 | 2857 | 1783 | 3059 | 1693 | 1435 | 1143 | 913 | 855 |
| 700 | 2743 | 1712 | 2937 | 1625 | 1378 | 1098 | 876 | 819 |
| 750 | 2476 | 1545 | 2651 | 1467 | 1244 | 991 | 791 | 741 |
Supplier of MS Round Pipe in Mumbai, Check Manufacturing Process
Mild Steel Pipe Manufacturing Process
Steber Steel Solution Mostly Supply Mild Steel Galvanised Pipe in 25, 40, 50 and 100 mm
Mild Steel Pipe Size Chart
| O.D. | W.T. (mm) | O.D. | W.T. (mm) |
|---|---|---|---|
| 24″ | 5.75-17.75 | 4″ | 2.2-9 |
| 20″ | 5.75-17.75 | 3 1/2″ | 2.2-9 |
| 18″ | 5.75-17.75 | 3″ | 2.2-8 |
| 16″ | 5.75-13.75 | 2 1/2″ | 2-7 |
| 14″ | 5.5-13.75 | 2″ | 1.8-7 |
| 12″ | 1 1/2″ | 1.5-7 | |
| 10″ | 5-13.75 | 1 1/4″ | 1.1-4 |
| 8″ | 2.75-12 | 1″ | 1.1-4 |
| 6″ | 2.5-10 | 3/4″ | 1.1-2.87 |
MS Rectangular Pipe Ex Stock
| Material | Sch. & Swg. | Size (in mm) | Specification |
|---|---|---|---|
| Mild Steel (M. S.) & G. I. | 'A' Class 'B' Class 'C' Class |
15 NB to 150 NB |
IS 1239 |
| 4.85 mm to 12.7 mm Thk. |
200 NB to 500 NB |
IS 3589 (Fe 330, Fe 410) |
Mild Steel Pipe HSN Code
| Grade | HSN Code |
|---|---|
| Mild Steel Pipe | 73069090 |
MS Round Pipe Tolerance
| (a) Thickness | ||
|---|---|---|
| (1) | Seamless Tubes | +Not Limited – 12.5 percent |
| (2) | Butt welded Light tubes | +Not limited – 8 percent |
| Medium and Heavy tubes | + Not Limited – 10 percent |
|
Tolerance By Weight
| (b) Weight : | ||
|---|---|---|
| (1) | Single tube (medium & heavy Series) |
+10 percent |
| (2) | Single tube (light series) | +10 percent – 8 percent |
Various Types Of Mild Steel Pipe
Mild Steel Pipe Supplier in India, offers Most Common Types
Mild Steel Galvanised Pipe
MS Sqaure Pipe
Mild Steel Welded Pipe
MS Round Pipe
Mild Steel Casing Pipe
MS Hollow Pipes
Mild Steel cement lined Pipe
MS Rectangular Pipe
Black Mild Steel Pipes
Schedule 40 Mild Steel Pipe
MS Exhaust Pipe
Thin Wall MS Pipe Roughness Coefficient
| Roughness Condition | New Pipe | Cleaned | Corroded |
| mm | .045 to .060 | .060 to .080 | .080 to .100 |
| inches | .0018 to .0024 | .0024 to .0031 | .0031 to .0040 |
Mild Steel Pipe Available Grades
- IS 1239 pipe
- IS 3589 pipe
- IS 3589 Fe 410 Pipe
- IS 3589 Fe 330 Pipe
- IS 4923 Square Tube
- IS 4923 Yst 310 Hollow Section
- IS 4923 Yst 210 Hollow Section
- IS 4923 Yst 240 Hollow Section
- IS 4923 Yst 355 Hollow Section
- IS 2062 Pipe
- IS 1161 Yst 210 Pipe
- IS 1161 Yst 310 Pipe
- IS 1161 Yst 355 Pipe
- IS 1161 Yst 240 Pipe
- IS 3601 Pipe
- IS 1978 Pipe
- IS 5504 Pipe
- IS 9295 Tubes
MS Pipe Grades Chart
| ASTM A500 | EN 10219 | IS 1239 | IS 3589 | BS 1387 |
Mild Steel Casing Pipe Test Certificate
- Laboratory Test Certificate from Govt. Approved Lab
- Manufacturer Test Certificate
- Under Third Party Inspection
Heat Treatment of MS Hollow Pipes
| Carburizing | 899-927°C |
|---|---|
| Stress Relieving | 677-927°C |
| Normalizing | 899-954°C |
| Hardening | 788-816°C |
| Annealing | 843-871°C |
Galvanized Mild Steel Seamless Pipe Dimensions
| Nominal Bore | Outside Diameter | Medium (B-Class) Thickness Weight | Light (A-Class) Thickness Weight | Heavy (C-Class) Thickness Weight | |||||
|---|---|---|---|---|---|---|---|---|---|
| Inch | MM | Inch | MM | MM | kg/mtr | MM | kg/mtr | MM | kg/mtr |
| 6 | 150 | 6.500 | 165.10 | 4.85 | 19.20 | – | – | 5.40 | 21.2 |
| 5 | 125 | 5.500 | 139.70 | 4.85 | 16.20 | – | – | 5.40 | 17.8 |
| 4 | 100 | 4.500 | 114.30 | 4.50 | 12.10 | 3.65 | 9.890 | 5.40 | 14.4 |
| 3 | 80 | 3.500 | 88.90 | 4.05 | 8.470 | 3.25 | 6.810 | 4.85 | 10.1 |
| 2.1/2 | 65 | 3.004 | 76.20 | 3.65 | 6.610 | 3.25 | 5.840 | 4.47 | 7.90 |
| 2 | 50 | 2.375 | 60.30 | 3.65 | 5.100 | 2.90 | 4.110 | 4.47 | 6.17 |
| 1.1/2 | 40 | 1.906 | 48.40 | 3.25 | 3.610 | 2.90 | 3.250 | 4.05 | 4.43 |
| 1.1/4 | 32 | 1.656 | 42.90 | 3.25 | 3.140 | 2.65 | 2.580 | 4.05 | 3.84 |
| 1 | 25 | 1.312 | 33.80 | 3.25 | 2.440 | 2.65 | 2.010 | 4.05 | 2.97 |
| 3/4 | 20 | 1.094 | 27.20 | 2.65 | 1.580 | 2.35 | 1.410 | 3.25 | 1.90 |
| 1/2 | 15 | 0.844 | 21.43 | 2.65 | 1.122 | 2.00 | 0.952 | 3.25 | 1.45 |
| 3/8 | 10 | 0.872 | 17.10 | 2.35 | 0.852 | 1.80 | 0.674 | 2.90 | 1.02 |
| 1/4 | 6 | 0.532 | 13.49 | 2.35 | 0.407 | 1.80 | 0.517 | 2.90 | 0.769 |
| 1/8 | 3 | 0.406 | 10.32 | 2.00 | 1.80 | 0.361 | 2.65 | 0.493 | |
Black Mild Steel Pipe Coatings
- Anti rust varnished
- PE/PVC/PP coated
- Color coated
- Epoxy coating
- Anti rust oiled
- Galvanized
- Black painted
MS Square Pipe Weight Chart
A large range of weights and sizes are available at affordable costs from Steber Steel Solutions, Trustworthy Mild Steel Pipe Supplier in India
| Wall thickness T | Width A | Weight per m of pipe |
|---|---|---|
| mm | mm | kg |
| 1.3 | 5 | .1717 |
| 1 | 10 | .2690 |
| 1.5 | 25 | 1.0700 |
| 3 | 35 | 2.8900 |
| 4 | 42 | 4.5600 |
| 5 | 90 | 13 |
| 6 | 42 | 6.3000 |
| 7 | 60 | 11 |
| 8 | 90 | 19.7300 |
| 9 | 120 | 30.2800 |
| 12 | 180 | 61.3600 |
MS Round Pipe Applications
Mild Steel cement lined Pipe Testings
Supplier of Mild Steel Pipe provides Flattening and Non-Destructive Test
- Metal Flow Test
- Universal Testing
- Flattening Testing
- Eddy Current Testing
- Non-Destructive Test
- Destructive Test
MS Welded Pipe Maximum Permissible Pressure And Temperature
| Size | Max Permissible Pressure (N/mm2) | Max PermissibleTemp (°C) |
|---|---|---|
| 25mm | 1.2 | 260 |
| 25mm – 40mm | 1.03 | 260 |
| 40mm – 80mm | .86 | 260 |
| 80mm – 100mm | .69 | 260 |
| 100mm – 125mm | .69 | 171 |
| 125mm – 150mm | .5 | 160 |
Mild Steel Pipe Chemical Composition
| Manganese | 1.03 |
| Iron | 98 |
| Copper | 0.20 |
| Sulfur | 0.05 |
| Phosphorus | 0.04 |
| Silicon | 0.28 |
| Carbon | 0.25 – 0.29 |
MS Exhaust Pipe Mechanical Properties
Mild Steel Pipe Manufacturer in India provides Pipes with high mechanical properties
| Tensile Strength | 400 – 550 MPa |
| Shear Modulus | 79.3 GPa |
| Yeild Strength | 250 MPa |
| Poisson’s ratio | 0.260 |
| Modulus of Elasticity | 200 GPa |
| Elongation | 20-23 % |
| Bulk Modulus | 140 GPa |
