Stainless Steel 317L Sheet

Stainless Steel 317L Sheet

Stainless Steel 317L Sheet Highlights
Length 3000 to 12000 mm
Width 900 to 2400 mm
Standards ASTM A240, ASME SA240 , UNS: S31703, WNR: 1.4438
Thickness 0.02 - 4.0 mm
Melting Point 1375°C-1400°C
Thermal expansion 17.2 x 10-6 /K
Cutting Laser,Waterjet, Plasma

ASTM A240 UNS S31703 Plate Supplier in India

Stainless Steel 317L Sheet

Stainless Steel 317L Sheet

SS 317L Plate

SS 317L Plate

ASTM A240 UNS S31703 Strips

ASTM A240 UNS S31703 Strips

Table of Contents


Stainless Steel 317L Sheet Specification

317L Stainless Steel Sheet Sheet Size

  • Length: 1000 - 5800mm
  • Width: 1000mm - 1219mm

Size

SS 317L Plate Plates Thickness

  • Sheet Thick : Upto 4 mm
  • Plate Thick: 0.1 - 100 mm

Thickness

317L Stainless Steel Plate Standards

  • ASME SA240 | ASTM A240
  • EN ,DIN, BS,JIS, GB

Standards

Stainless Steel 317L Coil Welding Method

  • Resistance welding
  • TIG welding
  • MIG welding


Welding Method

ASTM A240 UNS S31703 Strips Surface Treatment

  • PVC coated
  • Galvanised
  • Color coated
  • Coated
  • Film coated
Surface

Werkstoff Nr.1.4438 Checker Plate Bending Method

  • Roll bending
  • Rotary bending
  • Press braking

Bending

SS 317L Hot Rolled Plate Edges

  • Broken corner
  • Slit
  • V edge
  • Custom
  • Round
  • Deburred
  • Square
  • Rolled



Edges

UNS S31703 Cold Rolled Plate Types

  • flat shim
  • clad plate
  • coil
  • rolling plate
  • shim stock
  • flat sheet
  • sheet
  • perforated plate
  • plate
  • rolling sheets
  • strips
Types

317L Stainless Steel Clad Plate Origin

  • Taiwan
  • European
  • US
  • Japanese
  • Indian
  • Thailand
  • Korea




Origin

DIN 1.4438 Flat Sheet Marking

  • Manufacturing date
  • Origin of material
  • Material grade
  • ASTM/ ASME standard
  • Sizes
  • Manufacturer logo / name



Marking

317L SS Rolling Sheets Services

  • Forming
  • Welding
  • Polish
  • Plate Leveling
  • Beveling
  • Bending
  • Rolling
  • Heat Treatment
  • Forging
Services

ASTM A240 Type 317L Certification

  • Raw materials certificate
  • 100% radiography test report
  • Certificate of origin legalized
  • Third party inspection report
  • EN 10204/3.1B




Certification

ASTM A240 Gr 317L Packaging

  • Bundles with plastic wrapping
  • Industrial packing techniques
  • Wooden boxes/ crates/ pallets
  • Big rolls with spools



Packaging

317L Stainless Rolling Plate Cutting

  • Laser cutting
  • Oxy-propane flame cutting
  • Plasma cutting
  • Waterjet cutting



Cutting

ASTM A240 TP 317L Inspection Plan

  • UT testing
  • Dimension verification
  • Witnessed chemical analysis
  • Visual inspection
  • Packing Condition
  • PMI Testing
  • Hardness Testing
Inspection

Manufacturer of 317L SS Strip Provide Custom Thickness As Per Requirement

Thickness Chart of 2B Finish 317L Stainless Steel Perforated Sheet

Thickness Austenitic -kg/m² Ferritic -kg/m²
2.00 16.35 16.02
1.60 13.08 12.85
2.50 20.44 20.03
4.00 32.71 32.06
0.70 5.72 -
3.00 24.53 24.04
1.50 12.3 -
1.20 9.81 9.61

ASTM A240 Grade 317L Coil Gauge Thickness

Gauge Thickness (Inch) Thickness Tolerance
20 gauge 0.038 ± 0.004
22 gauge 0.031 ± 0.004
16 gauge 0.063 ± 0.006
11 gauge 0.120 ± 0.005
18 gauge 0.050 ± 0.005
12 gauge 0.109 ± 0.009
14 gauge 0.078 ± 0.007
24 gauge 0.025 ± 0.003

Dimensions of SA 240 gr 317L Strips

Grade Width (mm) Finish Thickness (mm)
317L SS 1219 2B 100

ASTM A240 Grade 317L Coil Available in Hot And Cold Rolled Process

Hot Forming and Heat Treatment of ASME SA240 Type 317L Plate

Process Temperature (°C)
Hot Forming 927 to 1204
Heat Treatment 1010 to 1121

Weight Chart of SA 240 tp 317L Sheet

Weight per Sizes Weight per Sizes
sheets -Kg (mm) sheets -Kg (mm)
77.5 2500* 1250* 3.0 36.8 3000* 1500* 1.0
49.6 2000* 1000* 3.0 25.6 2500* 1250* 1.0
51.2 2500* 1250* 2.0 20.5 2500* 1250* 0.8
44.2 3000* 1500* 1.2 8.2 2000* 1000* 0.5
112.0 3000* 1500* 3.0 19.6 2000* 1000* 1.2
24.6 2000* 1000* 1.5 12.8 2500* 1250* 0.5
38.4 2500* 1250* 1.5 11.5 2000* 1000* 0.7
73.7 3000* 1500* 2.0 14.7 2000* 1000* 0.9
32.7 2000* 1000* 2.0 13.1 2000* 1000* 0.8
40.9 2000* 1000* 2.5 23.0 2500* 1250* 0.9
92.1 3000* 1500* 2.5 16.4 2000* 1000* 1.0
55.3 3000* 1500* 1.5 17.9 2500* 1250* 0.7
63.9 2500* 1250* 2.5 33.2 3000* 1500* 0.9

Stainless Steel 317L Sheet Supplier in India Provides Various Custom Sizes

Stockist Of 2B Finish 317L Stainless Steel Rolling Plate Provide Hardness And PMI Test

ASME SA240 TP 317L Checker Plate Hardness

Properties Imperial Metric
Hardness, Rockwell B 85 85

SS 317L Coil Testing Requirements

Stainless Steel 317L Sheet Manufacturer in India Offers Various Requirements of Testing

Mirror Finish DIN 1.4438 Flat Sheet Supplier Offers Water Jet And Laser Cutting Process

What are the Processing Methods of ASME SA240 Gr 317L Strips?

Various Types Of Stainless Steel 317L Sheet

Stainless Steel 317L Sheet Supplier in India Offer Variety of Types like Strips, Sheets, Coils, Plate etc

317L Stainless Steel Coil

317L Stainless Steel Coil

DIN 1.4438 Perforated Sheet

DIN 1.4438 Perforated Sheet

ASTM A240 UNS S31703 Clad Plate

ASTM A240 UNS S31703 Clad Plate

Inox 1.4438 Hot Rolled Plate

Inox 1.4438 Hot Rolled Plate

A240 Type 317L Cold Rolled Plate

A240 Type 317L Cold Rolled Plate

ASME SA240 Gr 317L Chequered Plate

ASME SA240 Gr 317L Chequered Plate

SA 240 Gr 317L Flat Sheet

SA 240 Gr 317L Flat Sheet

Stainless Steel 317L Foil

Stainless Steel 317L Foil

ASTM A240 Gr 317L Chequered Plate

ASTM A240 Gr 317L Chequered Plate

1.4438 AISI 317L Polished Plate

1.4438 AISI 317L Polished Plate

A240 tp317L Sheet Applications

A240 tp317L Sheet Applications

Corrosion Resistance of INOX 317L Hot Rolled Plate

SS 317L sheet Properties
Super Austenitic Stainless Steel Corrosion Resistance.
150HB Steel Hardness
Less Weldable Weldable

HSN Code of A240 Type 317L Coil

Grade HSN Code
Stainless Steel 317L Sheet 72199090

Surface Finishes of ASME SA240 Gr 317L Sheet

Surface Finishes of ASME SA240 Gr 317L Sheet

ASTM A240 SS 317L Strips Mean Coefficient of Thermal Expansion

Temperature range
in/in °F cm/cm °C °F °C
8.9 x 10-6 16.2 x 10-6 68-212 20-100

What are the Features Provide 1.4438 Stainless Steel Cold Rolled Plate?

Provide Ready Extock of Stainless Steel 317L Sheet in Following Brands

Jindal

Jindal

Nippon Steel

Nippon Steel

Aperam

Aperam

Thyssenkrupp

Thyssenkrupp

Tisco

Tisco

Arcelormittal

Arcelormittal

Baosteel

Baosteel

Outokumpo

Outokumpo

Posco

Posco

ASME SA240 Grade 317L Coil Chemical Composition

Element Content (%)
Chromium, Cr 19
Iron, Fe 61
Silicon, Si 1
Manganese, Mn 2
Nickel, Ni 13
Phosphorous, P 0.045
Carbon, C 0.080
Molybdenum, Mo 3.50
Sulfur, S 0.030

Stainless Steel 317L Sheet Manufacturer in India Offers Various Requirements of Testing

Equivalent Material of SS 1.4438 Strips

Country STANDARD SS 317L
North America UNS S31703
Russia WERKSTOFF NR. 1.4438
Japan JIS SUS 317L
Europe EN X2CrNiMo18-15-4
America ASTM ASTM A240
Australia ASME ASME SA -240
America ANSI ANSI SS 317L
United States SAE SAE SS 317L
German DIN 1.4438

Mechanical Properties of SUS 317L Plate

Properties Imperial Metric
Yield strength 39900 psi 275 MPa
Elongation at break (in 50 mm) 45% 45%
Tensile strength 89900 psi 620 MPa
Elastic modulus 27993 ksi 193 GPa
Poisson’s ratio 0.27-0.30 0.27-0.30

A240 gr 317L Sheet Physical Properties

Properties Imperial Metric
Melting range 2540 - 2630°F 1390 - 1440°C
Specific heat 0.12 BTU/lb-°F (32 - 212°F) 502 J/kg-°K (0 - 100°C)
Density 0.285 lbs/in3 7.89 g/cm3
Thermal conductivity 68°F (20°C) 8.1 BTU/(hr x ft x °F) 14 W/(m x K)
Modulus of elasticity 29.0 x 106 psi 200 GPa
Electrical resistivity 33.5 Microhm-in at 68°C 85.1 Microhm-cm at 20°C
