Corten Steel Plate
| Corten Steel Plate Highlights | |
|---|---|
| Thickness | 2 to 460 mm |
| Width | 900 to 3200 mm |
| Lenght | 1000 to 12000 mm |
| Period of rusting | 4-10 years |
| Brand | JSW Corten steel |
| Density | 7.7 to 8.03 kg/m3 |
| MTC Certificate | EN 10204 3.1 & 3.2 |
Corten Steel Sheet Supplier in India As Per ASTM A588 Standard
Corten Steel Sheets
Corten Metal Plate
Cor Ten Sheet Metal
Table of Contents
- Corten Steel Plate Specification
- Hot And Cold Rolled Corten Metal Plate Dimensions
- Allowable Smallest Bending Radius Corten Steel Plate
- Cor-ten Flat Thickness Chart
- Corrosion Allowance Cor-ten Roof Sheets
- IRSM 41-97 Plate Technical Data
- 3mm Corten Steel Sheet Finish
- Corten Steel Plate Applications
- A588 Corten Grade A Plate HSN Code
- Is Corten Steel Suitable for Use in Retaining Walls?
- Various Types Of Corten Steel Plate
- How Long Will Corten Roof Sheet Last?
- What is the Timeline of Corten Steel's Color Transformation?
- Corten Metal Plate Weight
- Corten Gr B Plate Sizes
- 2mm Corten Steel Sheet Chemical Composition
- 10mm Thick Corten Steel Plate Mechanical Properties
- Corten Plate Equivalent
- Availability Of Corten Steel Plate ASTM A606
- What are the Standard Sizes of Corten Flat Sheet?
- Heat Treatment of Cor-ten Sheet
- Corten Roof Sheets Value Added Services
Corten Steel Plate Specification
Corten Steel Sheet/Plates Thickness
- 2 to 460 mm
Corten A Plate Size
- Width:900 to 3200 mm
- Length:1000 to 12000 mm
Corten Metal Plate Welding Method
- MIG
- Stick
- TIG
Corten B Plate Grade
- Corten A
- Corten B
- A242 Type 1
- S355J0WP
- S355J0W
- S355J2W
- A588 Grade B
- A588 Grade C
- A588 Grade A
10mm Thick Corten Steel Plate Surface Treatment
- PVC coated
- Galvanised
- Color coated
- Coated
- Film coated
Corten Steel Plate Standards
- ASTM A242
- ASTM A588
- ASTM A606
- ASTM A572
- ASTM A871
- ASTM A709
Cor-ten Roof Sheets Edges
- Quarter circle
- Straight edge
- Square end
- 45 ° Corner
- Half circle
- 90 ° Corner
Corten Flat Sheets Types
- Strip
- Sheet
- Plate
- Coil
- Roofing
- Edging
Corten Roof Sheets Origin
- Taiwan
- European
- US
- Japanese
- Indian
- Thailand
- Korea
Corten Steel Hot Rolled Steel Plate Marking
- Manufacturing date
- Origin of material
- Material grade
- ASTM/ ASME standard
- Sizes
- Manufacturer logo / name
Corten Steel Sheets Services
- Forming
- Welding
- Polish
- Plate Leveling
- Beveling
- Bending
- Rolling
- Heat Treatment
- Forging
- Shearing
Corten Steel Plate ASTM A606 Certification
- Raw materials certificate
- 100% radiography test report
- Certificate of origin legalized
- Third party inspection report
- EN 10204/3.1B
Corten B Plate Packaging
- Bundles with plastic wrapping
- Industrial packing techniques
- Wooden boxes/ crates/ pallets
- Big rolls with spools
IRSM 41-97 Plate Cutting
- Laser
- Plasma
- Waterjet
- Oxy-propane
3mm Corten Steel Sheet Inspection Plan
- Third party inspection Test
- Visual inspection Test
- Mechanical Test
- Chemical Test
Manufacturer of Hot And Cold Rolled Corten Metal Plate in Mumbai, Check Price List
Steber Steel Solutions Offers Corten Steel Price Per kg in India, Check Price Click Here
Hot And Cold Rolled Corten Metal Plate Dimensions
Corten Steel Plate Supplier in India offers an Excellent Dimensions.
| PATTERN | PITCH | OPENAREA in % | HOLE SIZE |
|---|---|---|---|
| Round Staggered | 4.52 | 46 | 3.2 |
| 5.59 | 30 | 3.2 | |
| 6.35 | 51 | 4.76 | |
| 5.59 | 46 | 3.97 | |
| 6.1 | 25 | 3.2 | |
| 3.2 | 41 | 2.06 | |
| 4.78 | 41 | 3.2 | |
| 3.66 | 40 | 2.41 | |
| 2.54 | 36 | 1.6 | |
| 3.2 | 26 | 1.6 | |
| 17.27 | 49 | 12.7 | |
| 25.4 | 51 | 19.05 | |
| 30 | 38 | 19.05 | |
| 9.53 * 6.74 | 11 | 2.41 | |
| 30 | 63 | 25.4 | |
| 7.92 | 33 | 4.76 | |
| 9.55 | 40 | 6.35 | |
| 16 | 32 | 9.53 | |
| 9.55 | 62 | 7.94 | |
| 8.89 | 46 | 6.35 | |
| 12.7 | 51 | 9.53 | |
| 12.7 | 23 | 6.35 | |
| 14.27 | 40 | 9.53 | |
| Square Diagonal Aligned | 12.7 | 19 | 5.56 |
| He*agon Staggered | 11.9 | 64 | 9.5 A/F |
| Slots Staggered | 30 * 11 | 38 | 25.4 * 6.35 |
| Square Aligned | 12 | 70 | 10 |
| Square Aligned | 15.88 | 49 | 11.11 |
| Square Aligned | 11.43 | 48 | 7.94 |
| Slots Staggered | 11.12 * 6.4 | 41 | 19.05 * 3.2 |
| Slots Aligned | 30.16 * 11.11 | 43 | 25.4 * 6.35 |
| Square Aligned | 7.62 | 69 | 6.35 |
| Square Aligned | 6.99 | 47 | 4.76 |
| He*agon Staggered | 32 | 44 | 23.81 A/F |
| Cloverleaf Aligned | 15.87 | 36 | 11.11 * 4.76 |
Allowable Smallest Bending Radius Corten Steel Plate
| Type of Atmosphere | Corrosion allowance | ||
|---|---|---|---|
| Each following 10 yr period mm | First 10 yr period mm | ||
| Urban | .05 | .20 | |
| Rural | .05 | .10 | |
| Industrial | .10 | .20 | |
Cor-ten Flat And Roof Sheets Thickness Chart
Cor-ten Flat Thickness Chart
Corten Steel Plate Supplier in India offers an Excellent Thickness Chart.
| Type | Grade | Thickness |
|---|---|---|
| Facade | Corten A | 0.50mm – 3.00 mm |
| Plate | Corten B | 2.00mm – 40.00 mm |
| Cold rolled | Corten A | 0.50mm – 3.00 mm |
| Hot rolled | Corten A | 2.00mm – 12.70 mm |
Corrosion Allowance Cor-ten Roof Sheets
| 10mm thick corten steel plate | 3-4 | 4-5 | 7-8 | 14-16 | 18-20 | 6-7 | 10-12 | 8-10 | 2-3 | 5-6 | 12-14 | 16-18 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8 | 10 | 24 | 48 | 60 | 21 | 36 | 30 | 6 | 12 | 42 | 54 |
IRSM 41-97 Plate Technical Data
| Material Type | 7/8 inch corrugated metal roofing & siding |
|---|---|
| Substrate | AZ50 min (Galvalume® / Zincalume®) |
| Available Gauges |
|
| Rib Distance (Pitch) | 2.67inch Pitch |
| Coverage Area (Wall) | 37inch |
| Rib Height | 7/8inch |
| Recommended Minimum Roof Slope | 3/12 |
| Fasteners | Exposed |
| Coverage Area (Roof) | 34.67inch |
| Panel Length | 1inch – 52inch |
| Finishes | PVDF Resin Based |
| Overall Width | 39inch |
3mm Corten Steel Sheet Finish
- Galvanized
- Color coated
- Black painted
- PE coated
- Anti rust varnished
- Anti rust oiled
Corten Steel Plate Applications
Corten Steel Plate Supplier In India Exports To Multiple Countries With Reliable Packaging.
Buy A588 Corten Grade A Plate in Cut To Size To Avoid Wasteage
A588 Corten Grade A Plate HSN Code
| Grade | HSN Code |
|---|---|
| Corten Steel Plate | 72083740 |
Is Corten Steel Suitable for Use in Retaining Walls?
- Makes sloped land more usable
- Helps manage water runoff
- Environmentally friendly option
- Suitable for all soil types
Various Types Of Corten Steel Plate
Corten Steel Plate Manufacturer In India Delivers Bulk Orders With Consistent Quality.
Corten Flat Sheets
Corten Roof Sheets
Corten Steel Hot Rolled Steel Plate
How Long Will Corten Roof Sheet Last?
- Lifespan: 40 to 100 years
- Low maintenance
- No painting needed
- High durability
- Eco-friendly
What is the Timeline of Corten Steel's Color Transformation?
Corten Metal Plate Weight
| Thickness chart of Corten steel sheet | Corten alloy sheet weight (lbs/ft) |
|---|---|
| 3/8inch | 15.315 |
| 1/4inch | 10.210 |
| 1/2inch | 20.420 |
Steber Steel Solutions Is Leading Stockist Of Corten Gr B Plate Stocks Sizes 1.6, 2, 3 And 6mm At Best Price
Corten Gr B Plate Sizes
| Stock sheet | Coiled Sheet (MOQ 130 square meter) | ||||
|---|---|---|---|---|---|
| – | 1 m * 8 m | – | 1 m * 8 m | ||
| – | 1.25 m * 8 m | – | 1.25 m * 8 m | ||
| 1.25 * 2.5 m | 1.14 m * 8 m | 1.25m * 2.5 m | 1.14 m * 8 m | ||
| 2 mm | 4, 6, 8 and 10 mm | 1.5 mm | 1.5 and 2 mm | ||
| – | 1.4 m * 8 m | – | 1.4 m * 8 m | ||
| – | 2 m * 8 m | – | – | ||
2mm Corten Steel Sheet Chemical Composition
| Grade | Ni | P | Cu | V | Si | Al | Mn | C | S |
|---|---|---|---|---|---|---|---|---|---|
| A | 0.65 | 0.07/0.15 | 0.25/0.55 | 0.25/0.75 | 0.015/0.06 | 0.20/0.50 | 0.15 | 0.03 | |
| B | 0.4 | 0.035 | 0.25/0.40 | 0.02/0.10 | 0.30/0.65 | 0.020/0.06 | 0.80/1.25 | 0.19 | 0.03 |
10mm Thick Corten Steel Plate Mechanical Properties
| Grade | Elongation A50 % Min | Tensile strength rm n/mm² Min | Plate products | Thickness (mm) Strip products | Yield strength rel n/mm² Min |
|---|---|---|---|---|---|
| Corten A | 20 | 485 | 6-12 | 2-12 | 345 |
| Corten B | 19 | 485 | 6-40 | 2-13 | 345 |
Corten Plate Equivalent
| EN 10155 | Material | BS 4360 | ASTM | NFA 35-502 | UNI | SEW 087 | JIS G3114 |
|---|---|---|---|---|---|---|---|
| S235J2W | 1.8961 | – | – | E 24 W 4 | Fe 360 DK 1 | WTSt 37-3 | – |
| S355J2WP | 1.8946 | – | A 242 | E 36 WA 4 | Fe 510 D1K1 | – | – |
| S355K2G1W | 1.8966 | – | A 709 Gr. 50 W | E 36 WB 4 | – | – | – |
| S355J2G2W | 1.8965 | – | – | – | – | – | SMA 50 CP |
| S355K2G2W | 1.8967 | – | – | – | – | – | – |
| S355J0WP | 1.8945 | – | – | Fe 510 C1K1 | WR 50 A | E 36 WA 3 | – |
| S355J2G1W | 1.8963 | WR 50 C | A 588 Gr. A | – | Fe 510 D2K1 | WTSt 52-3 | to |
| S355J0W | 1.8959 | WR 50 B | A 588 – A 242 | E 36 WB 3 | Fe 510 C2K1 | – | SMA 50 AW |
Availability Of Corten Steel Plate ASTM A606
| Gauge | 72inch Wide | 60inch Wide | 48inch Wide | 96inch * 240inch (W” * L”) |
|---|---|---|---|---|
| 1/4inch | √ | √ | √ | √ |
| 5/16inch | √ | |||
| 3/8inch | √ | √ | √ | √ |
| 5/8inch | √ | |||
| 1inch | √ | |||
| 3/4inch | √ | √ | √ | √ |
| 3/16inch | √ | √ | √ | √ |
| 1 1/2inch | √ | |||
| 2inch | √ | |||
| 1/2inch | √ | √ | √ | √ |
| 1 1/4inch | √ | |||
| 1 1/8inch | √ | |||
| 1 3/8inch | √ | |||
| 1 3/4inch | √ |
What are the Standard Sizes of Corten Flat Sheet ?
- Length between 2000 to 3000mm
- Width - 1000 to 1500mm.
- Thickness range of 1.5 to 10mm.
Heat Treatment of Cor-ten Theet
| Heat Treatment | Temperature °C |
|---|---|
| Normalising | 860 – 940 [target 910] |
| Stress Relieving | 550 – 600 [target 580] |
Corten Roof Sheets Value Added Services
- Rolling
- CNC Bending
- Drilling
- NC Cutting
- Chamfering
- Groove machining
- Milling
- Steel structure assembly
- Laser cutting
- Straightness
- Carving
- Precision welding
