Inconel Plate
| Inconel Plate Quick Information | |
|---|---|
| Plate Length | 3000 – 12000 mm |
| Plate Thickness | 4.5 – 100 mm |
| Temperature range | 980°C |
| Forms | Sheet, Coil, Foil, Clad plate |
| Brands | Outokumpu, Nippon Yakin, ATI, VDM |
| Welding Method | SAW, SMAW , PLASMA |
Inconel Alloy Sheet Supplier in India As Per ASTM B443 Standard
Inconel Plate
Inconel Alloy Sheet
Inconel Metal Strip
Table of Contents
- Inconel Plate Specification
- Size Chart of Inconel Steel Sheet
- Ready To Dispatch Stock of Inconel Plate in Following Brands
- Thickness Tolerance of Inconel Metal Polished Plate
- Inconel Flat Sheet Metric Dimension
- Weight Chart Of Inconel Alloy Sheet
- Various Types Of Inconel Plate
- Inconel Metal Alloy Chequered Plate Gauge Chart
- Welding Procedures For Inconel Steel Alloy Coil
- Documentations Of Inconel Sheet
- Weight Chart Of Inconel Metal Rolling Sheets
- Inconel Steel Alloy Hot Rolled Plate Shear Strength
- Finish Types Of Inconel Metal Strip
- Impact Strength of Inconel Steel Alloy Hot Rolled Plate
- Applications Of Inconel Steel Plate
- Inconel Metal Rolling Sheets Thermal Properties
- What Are The Advantages Of Inconel Alloy Sheet ?
- Matching Composition of Inconel Metal Alloy Perforated Plate
- HSN Code Of Inconel Plate
- Inconel Metal Strip Width Tolerance
- Length Tolerance of Inconel Alloy Sheet
- Chemical Composition Of Inconel Plate
- Inconel Shim Stock Mechanical Properties
- Equivalent Standards of Inconel Plate
Inconel Steel Strip Manufacturer in Mumbai, Check Specification And Price List
Inconel Plate Specification
Inconel Alloy Sheet Size
- Length:3000 -12000 mm
- Thickness: 0.02 – 4.0 mm
- Width:900 – 2400 mm
Inconel Plate Sizes
- Length:3000 – 12000 mm
- Thickness: 4.5 – 100 mm
- Width:900 – 2400 mm
Inconel Metal Alloy Perforated Sheet Sizes
- Length:1000- 6000mm
- Thickness:0.3-15mm
- Width:1000- 2000mm
Inconel Steel Coil Sizes
- Thickness: 2.5-10.0 mm
- Width:610-2000 mm
- Length:2000 – 6000mm
Inconel Steel Alloy Clad Plate Edges
- Slit
- Square
- Rolled
- Round
Inconel Metal Rolling Sheets Processsing
- Deburring
- Custom
- Edging
- Grinding
Inconel Metal Polished Plate Origin
- Thailand
- European
- US
- Korea
- Japanese
- Indian
- Taiwan
Inconel Plate Types
- rolling plate
- shim stock
- flat shim
- coil
- sheet
- clad plate
- flat sheet
- perforated plate
- strips
Inconel Metal Strip Finish
- Brushed finish
- hair line
- Brush
- BA
- NO.1
- Checkered
- 2D, 2B
- 8K
- Mirror Finish
Inconel Metal Polished Plate Certification
- EN 10204/3.1B,
- 100% Radiography Test Report
- Third Party Inspection Report
- Raw Materials Certificate
- Certificate of Origin legalized
Inconel Flat Sheet Inspection Methods
- Visual Inspection
- Hardness Testing
- Witnessed Chemical Analysis
- UT testing
- Dimension Verification
- PMI testing
- Packing Condition
Inconel Alloy Sheet Heat Treatment
- +NT: Normalized and tempered
- +P: Precipitation hardened
- +AT: Solution annealed
- +QT: Quenched and tempered (oil/ water)
- +A: Annealed (soft/ full/ spheroidizing)
- +N: Normalized
Inconel Metal Slitting Coil Packaging
- Wooden boxes/ crates/ pallets
- Industrial packing techniques
- Big rolls with spools
- Bundles with plastic wrapping
Inconel Foil Cutting
- Laser cutting
- Plasma cutting
- Oxy-propane flame cutting
- Waterjet cutting
Inconel Steel Alloy Perforated Plate Standards
- JIS4304-2005
- GB/T3280-2007
- EN10088-2-2005
- ASTM B443
- ASME SB443
Size Chart of Inconel Steel Sheet
| Inconel plate sizes | |
|---|---|
| Size (in mm) | Size (in inches) |
| 12.7 | 0.500 |
| 3.18 | 0.125 |
| 3.96 | 0.156 |
| 22.2 | 0.875 |
| 6.35 | 0.250 |
| 3.40 | 0.134 |
| 7.92 | 0.312 |
| 15.9 | 0.600 |
| 4.75 | 0.187 |
| 19.1 | 0.750 |
| 76.2 | 3 |
| 9.53 | 0.375 |
| 63.5 | 2.500 |
| 25.4 | 1 |
| 38.1 | 1.500 |
| 50.8 | 2 |
| 31.8 | 1.250 |
| 28.6 | 1.125 |
| 44.5 | 1.750 |
Ready To Dispatch Stock of Inconel Plate in Following Brands
Supplier of Inconel Plate in Mumbai keep ready stock in Outokumpo,Nippon Yakin
Outokumpo
Nippon Steel
Special Metals(SMC)
HAYNES International
VDM
Columbus Stainless
PED Approved Inconel Steel Alloy Coil Stockist, Refer Thickness
Thickness Tolerance of Inconel Metal Polished Plate
| Width w (mm) | 2400< w <2700 | 1200< w <1500 | 2700< w <3000 | 1500< w <1800 |
|---|---|---|---|---|
| 4.5<t <6.0 | 0.8 | 0.25 | 0.8 | 0.28 |
| 6.0<t <8.0 | 0.8 | 0.3 | 0.9 | 0.32 |
| 8.0<t <10.0 | 0.8 | 0.35 | 1 | 0.38 |
| 10.0<t <12.5 | 0.8 | 0.38 | 1 | 0.4 |
| 30<t <40.0 | 1.7 | 1.4 | 1.8 | 1.5 |
| 25.0<t <30.0 | 1.3 | 1 | 1.4 | 1.1 |
Inconel Flat Sheet Metric Dimension
| Sheet Surface Finish | Max Width (mm) | Thickness (mm) |
|---|---|---|
| Brushed, Polished plate | 1524 | 0.5 - 4 |
| 2D | 1524 | 0.4 - 6.35 |
| 2E | 2032 | 0.4 - 8 |
| 2R | 1524 | 0.25 - 3.5 |
| 2B | 2032 | 0.25 - 8 |
| 2H | 1524 | 0.4 - 6.35 |
Refer Weight Chart Before Purchasing Inconel Shim Sheet Bulk Stock
Weight Chart Of Inconel Alloy Sheet
| Thickness(inches) | Plate Weight/ Unit Area |
|---|---|
| 3/16 | 42.184176 kg/m² |
| 3/8 | 85.0714216 kg/m² |
| 5/8 | 137.8016416 kg/m² |
| 3/4 | 165.221356 kg/m² |
| 1 | 220.0607848 kg/m² |
| 1 1/4 | 274.9002136 kg/m² |
| 1 3/4 | 385.9852104 kg/m² |
| 2 | 440.8246392 kg/m² |
| 2 1/4 | 495.664068 kg/m² |
| 2 3/4 | 606.0459952 kg/m² |
| 3 | 661.5884936 kg/m² |
Various Types Of Inconel Plate
Inconel PlateSupplier in India Provides Multiple Forms Of Plates in Best Quality
Inconel Steel Coil
Inconel Steel Alloy Clad Plate
Inconel Metal Rolling Sheets
Inconel Flat Sheet
Inconel Metal Alloy Perforated Plate
Inconel Steel Alloy Hot Rolled Plate
Inconel Cold Rolled Plate
Inconel Metal Polished Plate
Inconel Metal Alloy Chequered Plate
Inconel Metal Alloy Chequered Plate Gauge Chart
Inconel Plate Manufacturer In India Provides Custom Sizes And Dimensions
| Gauge | mm | Inches | Pounds per Sa. Ft. |
|---|---|---|---|
| 7 | 47 | 187 | 7.871 |
| 10 | 3.4 | 135 | 5.670 |
| 11 | 3.0 | -120 | 5.040 |
| 12 | 2.7 | 105 | 4.427 |
| 13 | 2.3 | .090 | 3.780 |
| 14 | 1.9 | .075 | 3.154 |
| 16 | 1.5 | .060 | 2.520 |
| 18 | 1.2 | .048 | 2.016 |
| 20 | 0.9 | .036 | 1.512 |
| 22 | 0.8 | .030 | 1.260 |
| 24 | 0.6 | .024 | 1.008 |
| 26 | 0.5 | 020 | 0.756 |
Welding Procedures For Inconel Steel Alloy Coil
View List Of Documents Provide While Buying Inconel Sheet in India
Documentations Of Inconel Sheet
- Third Party Inspection Report
- 100% Radiography Test Report
- Raw Material Test Reports
- Guarantee Letter
- EN 10204 3.1 and EN 10204 3.2
- Fumigation Certificates
Weight Chart Of Inconel Metal Rolling Sheets
| Plate Thickness (mm) | Weight (kg/m) | Kg/Metr. (width : 1200 mm) | Kg/Metr. (width : 2400 mm) |
|---|---|---|---|
| 3 | 23.55 | 28.3 | 56.5 |
| 8 | 62.8 | 75.4 | 150.7 |
| 5 | 39.25 | 47.1 | 94.2 |
| 4 | 31.4 | 37.7 | 75.4 |
| 6 | 47.1 | 56.5 | 113 |
| 10 | 78.5 | 94 | 188 |
| 12 | 94.2 | 113 | 226 |
| 16 | 125.6 | 151 | 301 |
| 22 | 172.7 | 207 | 415 |
| 25 | 196.25 | 236 | 471 |
| 28 | 219.8 | 264 | 528 |
Inconel Steel Alloy Hot Rolled Plate Shear Strength
| ksi | MPa | ksi | MPa | ||
| Annealed | 60.8 | 419.2 | 85.0 | 586.1 | 71 B |
| Half-Hard | 66.3 | 456.8 | 98.8 | 681.2 | 98 B |
| Full-Hard | 82.4 | 568.1 | 152.2 | 1049.5 | 31 C |
Finish Types Of Inconel Metal Strip
- Sandblasted
- Matte
- Glossy
- Electroless Nickel Alloy Plating
- Mirror
- Brushed
Impact Strength of Inconel Steel Alloy Hot Rolled Plate
| Condition | Izod Notch | Charpy U-Notch | ||
|---|---|---|---|---|
| ft•lb | J | ft•lb | J | |
| Hot-Rolled | >120 | >163 | 230 | 312 |
| Cold-Drawn, Annealed | 70-100 | 95-136 | 151 | 205 |
| Cold-Drawn | >120 | >163 | 230 | 312 |
| Hot-Rolled, Annealed | 100-120 | 136-163 | - | - |
Applications Of Inconel Steel Plate
Inconel Metal Rolling Sheets Thermal Properties
| Temp. °F | Thermal Conductivityᵇ,ᶜ Btu·in/ft²·h·°F | Meal Linear Expansionᵃ 10⁻⁶in/in·°F | Electrical Resistivityᶜ ohm-circ mil/ft |
|---|---|---|---|
| -250 | 50 | - | - |
| -100 | 58 | - | - |
| 70 | 68 | - | 776 |
| 200 | 75 | 7.1 | 794 |
| 400 | 87 | 7.3 | 806 |
| 800 | 109 | 7.6 | 818 |
| 1000 | 121 | 7.8 | 830 |
| 1400 | 144 | 8.5 | 824 |
| 1600 | 158 | 8.8 | 818 |
| 1800 | 175 | - | 812 |
What Are The Advantages Of Inconel Alloy Sheet ?
- Good Creep resistant
- Fatigue Resistant
- Excellent mechanical Strength
- Resistant To Oxidation And Corrosion
- Resistant To High Temeprature
Matching Composition of Inconel Metal Alloy Perforated Plate
| Base Metal | Shielded Metal Arc Electrode | Flux-cored Electrode | Bare Electrode and Rod | ||||
|---|---|---|---|---|---|---|---|
| UNS | Alloy | AWS A5.14 | UNS | AWS A5.34 | UNS | AWS A5.11 | UNS |
| N06600 | 600 | ENiCrFe-3 | W86182 | ENiCr3Tx-y | W86082 | ERNiCr-3 | N06082 |
| N06625 | 625 | ENiCrMo-3 | W86112 | - | - | ERNiCrMo-3 | N06625 |
| N08825 | 825 | ENiCrMo-3 | W86112 | ENiCrMo3Tx-y | W86625 | ERNiCrMo-3 | N06625 |
HSN Code Of Inconel Plate
| Product | HS code |
|---|---|
| Inconel plate | 72083710 |
Inconel Metal Strip Width Tolerance
| Nominal length (mm) | w < 1200 | 1200 < w < 1500 | w > 1500 | |
|---|---|---|---|---|
| Mill edge | Minus | 0 | 0 | 0 |
| Plus | 20 | 20 | 20 | |
| Trimmed edge | Minus | 0 | 0 | 0 |
| Plus | 3 | 5 | 5 |
Length Tolerance of Inconel Alloy Sheet
| Nominal length (mm) | 2,000 < L < 8,000 | L < 2,000 | L > 8,000 | |
|---|---|---|---|---|
| Tolerance(mm) | Minus | 0 | 0 | 0 |
| Plus | 0.005 times L | 10 | 40 |
Chemical Composition Of Inconel Plate
| Inconel | Element (% by mass) | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Cr | Mo | Fe | Ni | Cu | Co | Nb | Al | Mn | Ti | Si | C | S | P | |
| 600 | 14.0- 17.0 | 6.0-10.0 | 72.0 | 0.5 | 1.0 | 0.5 | 0.15 | 0.015 | ||||||
| 625 | 20.0- 23.0 | 8.0- 10.0 | 5.0 | 58.0 | 0.5 | 1.0 | 3.15- 4.15 | 0.4 | 0.4 | 0.4 | 0.5 | 0.1 | 0.015 | 0.015 |
| 617 | 20.0- 24.0 | 8.0- 10.0 | 3.0 | 44.2- 56.0 | 0.5 | 10.0- 15.0 | 0.8- 1.5 | 0.5 | 0.6 | 0.5 | 0.15 | 0.015 | 0.015 | |
| X-750 | 14.0- 17.0 | 5.0-9.0 | 70.0 | 0.5 | 1.0 | 0.7- 1.2 | 0.4- 1.0 | 1.0 | 2.25- 2.75 | 0.5 | 0.08 | 0.01 | ||
| 718 | 17.0- 21.0 | 2.8- 3.3 | balance | 50.0- 55.0 | 0.2- 0.8 | 1.0 | 4.75- 5.5 | 0.65- 1.15 | 0.35 | 0.3 | 0.35 | 0.08 | 0.015 | 0.015 |
Inconel Shim Stock Mechanical Properties
Inconel Plate Supplier In India Offers Accurate Properties Of Plates
| property | Inconel 601 | Inconel 718 | Inconel 625 | Inconel 600 |
|---|---|---|---|---|
| Density | 8.1g/cm³ | 8.2 g/cm³ | 8.4 g/cm³ | 8.4 g/cm³ |
| Tensile strength - Mpa | 650min. | 965min | 760min. | 550min. |
| Brinell hardness (HB) | ≤220 | ≤363 | ≤220 | ≤195 |
| Elongation % | 30 min. | 30 min. | 30 min. | 30min. |
| Yield strength - Mpa | 300min. | 550 min. | 345min. | 240min. |
| Melting Range, °C | 1320-1370°C | 1260-1340 °C | 1290-1350°C | 1370-1425 °C |
Equivalent Standards of Inconel Plate
| Nickel Alloys | UNS no. | Werkstoff No. |
|---|---|---|
| Alloy 625 | No6625 | 2.4856 |
| Alloy 601 | No6601 | 2.4851 |
| Alloy 600 | No6600 | 2.4816 |
