• An ISO 9001 and ISO 14001 Certified Company
Steber Steel Solutions

Stainless Steel 304L Sheet

Stainless Steel 304L Sheet

Stainless Steel 304L Sheet Highlights
Plate Thickness 4.5 – 100 mm
Sheet Thickness 2.5-10.0 mm
Temperature 1650°F (899°C)
Lead Time Within 15 Days
Standards ASME SA240 , ASTM A240, JIS4304-2005, EN10088-2-2005
Surface Finishing 2B, NO.3 , BA, Mirror, NO.1
Thermal expansion 17.2 x 10-6 /K

ASTM A240 Type 304L Plate Supplier in India

Stainless Steel 304L Sheet

Stainless Steel 304L Sheet

ASTM A240 Type 304L Plate

ASTM A240 Type 304L Plate

304L Stainless Steel Strip

304L Stainless Steel Strip

Table of Contents


Stainless Steel 304L Sheet Specification

304L Stainless Steel Sheet Size

  • Length: 4 - 3 mm or Custom
  • Width: 10 - 2500 mm
Size

ASME SA240 304l 2b Plates Thickness

  • Sheet Thickness : Upto 4 mm
  • Plate Thickness : 0.1 - 100 mm
Thickness

Stainless Steel 304L Sheet Standards

  • ASME SA240 | ASTM A240
  • EN ,DIN, BS,JIS, GB
Standards

UNS S30403 Cold Rolled Plate Welding Method

  • Resistance welding
  • TIG welding
  • MIG welding


Welding Method

DIN 1.4307 Polished Plate Surface Treatment

  • PVC coated
  • Galvanised
  • Color coated
  • Coated
  • Film coated
Surface

SS 304L Plates Bending Method

  • Roll bending
  • Rotary bending
  • Press braking


Bending

ASTM A240 Type 304L Plate Edges

  • Broken corner
  • Slit
  • V edge
  • Custom
  • Round
  • Deburred
  • Square
  • Rolled


Edges

Brushed Stainless Steel 304L Sheet Types

  • flat shim
  • clad plate
  • coil
  • rolling plate
  • shim stock
  • flat sheet
  • sheet
  • perforated plate
  • plate
  • strips
Types

SUS 304L Plate Origin

  • Taiwan
  • European
  • US
  • Japanese
  • Indian
  • Thailand
  • Korea




Origin

INOX 304L Strip Markings

  • Manufacturing date
  • Origin of material
  • Material grade
  • ASTM/ ASME standard
  • Sizes
  • Manufacturer logo / name





Marking

AISI 304L SS Coil Services

  • Forming
  • Welding
  • Polish
  • Plate Leveling
  • Beveling
  • Bending
  • Rolling
  • Heat Treatment
  • Forging
  • Shearing
Services

SS 304L Flat Sheet Certification

  • Raw materials certificate
  • 100% radiography test report
  • Certificate of origin legalized
  • Third party inspection report
  • EN 10204/3.1B




Certification

304L Stainless Steel Rolling Plate Packaging

  • Bundles with plastic wrapping
  • Industrial packing techniques
  • Wooden boxes/ crates/ pallets
  • Big rolls with spools




Packaging

SA 240 TP 304L Perforated Sheet Cutting

  • Laser cutting
  • Oxy-propane flame cutting
  • Plasma cutting
  • Waterjet cutting




Cutting

A240 gr 304L Clad Plate Inspection Plan

  • UT testing
  • Dimension verification
  • Witnessed chemical analysis
  • Visual inspection
  • Packing Condition
  • PMI Testing
  • Hardness Testing

Inspection

Top Leading Manufacturer of 304L Stainless Steel Strip In Mumbai With MTC

ASTM A240 Type 304L Plate Test Certificates

  • Manufacturer Test Certificate as per EN 10204-3.1
  • Third Party Inspection
  • NABL approved Lab Testing
  • 100% Radiography Report
  • EN 10204-3.2, Raw Materials Certification

Buy Bulk Stock of SS 304L Coil With 2B, Mirror and Polished Surface Finish

UNS S30403 Cold Rolled Plate Finish

  • Brushed finish
  • 8K
  • Hair line
  • NO.8
  • Sand blast
  • 2D
  • Polished Finish
  • NO.1
  • NO.4
  • 2B
  • BA
  • Mirror Finish
  • Embossed
Ready Stock Of ASTM A240 Grade 304L Rolling Sheets For Various Applications

ASTM A240 UNS S30403 Clad Plate Applications

ASTM A240 UNS S30403 Clad Plate Applications
Stockist of SA 240 TP 304L Perforated Sheet in Mumbai, Check Welding Procedure

DIN 1.4307 Polished Plate Welding Procedure

  • Resistance welding
  • TIG - Tungsten Inert Gas
  • MIG - Metal arc welding

Various Types Of Stainless Steel 304L Sheet

Stainless Steel 304L Sheet Supplier in India offers various Common types including Sheet, Plate, Strip and Coils

ASTM A240 Type 304L Clad Plate

ASTM A240 Type 304L Clad Plate

Stainless Steel 304L Flat Sheet

Stainless Steel 304L Flat Sheet

AISI 304L Perforated Sheet

AISI 304L Perforated Sheet

Werkstoff Nr. 1.4307 Coil

Werkstoff Nr. 1.4307 Coil

ASME SA 240 Grade 304L SUS 304L Foil

ASME SA 240 Grade 304L SUS 304L Foil

UNS S30403 Cold Rolled Plate

UNS S30403 Cold Rolled Plate

SS 304L Hot Rolled Plate

SS 304L Hot Rolled Plate

304L Stainless Steel Rolling Plate

304L Stainless Steel Rolling Plate

DIN 1.4307 Polished Plate

DIN 1.4307 Polished Plate

Stainless Steel 304L Plate Weight

Nominal Plate Size's in MM Weight per in Kg
2000 x 1000 x 3 51
4000 x 1500 x 12 612
2500 x 1250 x 3 79.7
2500 x 1250 x 10 266
3000 x 1500 x 3 115
2500 x 1250 x 8 213
2000 x 1000 x 4 68
4000 x 2000 x 8 544
2500 x 1250 x 4 106
3000 x 1500 x 8 306
3000 x 1500 x 4 153
4000 x 2000 x 6 408
2000 x 1000 x 5 85
2500 x 1250 x 12 319
2500 x 1250 x 5 133
3000 x 1500 x 10 383
3000 x 1500 x 5 191
4000 x 2000 x 12 816
4000 x 2000 x 5 340
3000 x 1500 x 12 459
2000 x 1000 x 6 102
4000 x 1500 x 10 510
2500 x 1250 x 6 159
4000 x 2000 x 10 680
3000 x 1500 x 6 230

SA 240 TP 304L Perforated Sheet Key Features

  • Good Corrosion Resistance
  • Hot Workability
  • Lower Temperature Performances is Excellent
  • Welding Characteristics is Good
  • Heat Resistance Performance

Stainless Steel 304L Sheet Size Chart

Supplier of Stainless Steel 304L Sheet Size Chart are offer a range of sizes

Nominal Plate Size
MM Inch
12.7 .500
3.40 .134
3.96 .156
9.53 .375
4.75 .187
6.35 .250
7.92 .312
19.1 .750
22.2 .875
25.4 1
44.5 1.750
50.8 2
63.5 2.500
28.6 1.125
15.9 .625
38.1 1.500
31.8 1.250
76.2 3
3.18 .125

How & Why SS 304L Sheets Resistance to Corrosion ?

SUS 304L Thin Strips Corrosion Resistance

ASME SA 240 Grade 304L Cold Rolled Plate Weight Chart

Plate Size's in mm Weight in Kg
4000 x 2000 x 2 136
2500 x 1250 x 6 159
4000 x 2000 x 3 204
3000 x 1500 x 5 191
2500 x 1250 x 4 106
4000 x 2000 x 6 408
3000 x 1500 x 4 153
3000 x 1500 x 6 230
4000 x 2000 x 4 272
4000 x 2000 x 5 340
2500 x 1250 x 5 133

SS 304L Flat Sheet Thickness

Sheet Size's Range 36 x 96 30 x 120 36 x 144 36 x 120 36 x 96 30 x 120 30 x 96 36 x 96 48 x 120 48 x 96 48 x 120 36 x 144 48 x 144
Thickness Inch .015 .0291 .0291 .0178 .0355 .0355 .0291 .0291 .0291 .0235 .0178 .0235 .0291
Surface Area per Unit weight kg/m² 3.1 6.12 6.14 3.70 7.39 7.39 6.16 6.16 6.16 4.93 3.71 4.91 6.15
lbs/ft² .63 1.26 1.26 .756 1.512 1.512 1.26 1.26 1.26 1.008 .756 1.008 1.26
Thickness mm .381 .73914 .73914 .45212 .9017 .9017 .73914 .73914 .73914 .5969 .45212 .5969 .73914
Appro. Weight per Sheet kg 6.85 14.27 2.56 1 .28 16.44 17.13 11.42 13.70 22.84 14.62 13.70 16.44 27.41
lbs 15.12 31.5 45.37 22.68 36.29 37.8 25.2 3 .24 5 .41 32.26 3 .24 36.29 6 .49

AISI 304L Flat Sheet Testings

Stainless Steel 304L Sheet Manufacturer in India supplies Hardness and PMI Testings

AISI 304L Flat Sheet Testings

304L Stainless Steel Sheet HSN Code

Grade HSN Code
Stainless Steel 304L Sheet 7219

Werkstoff Nr. 1.4307 Rolling Sheets Gauge Chart

Gauge Nominal decimal (Approx. Inch) Standard Variance from Nominal Decimal (+/- Inch)
7 0.1793 0.0080
9 0.1495 0.0080
13 0.0897 0.0050
11 0.1196 0.0050
8 0.1644 0.0080
12 0.1046 0.0050
10 0.1345 0.0070
14 0.0747 0.0040

304L SS Strip Thickness Tolerance

SS 304 Gauge Tolerance in Inch/MM Thck. in Inch/MM
11 ± 0.005 & 0.13 0.120 & 3.05
18 ± 0.003 & 0.076 0.048 & 1.219
14 ± 0.004 & 0.102 0.075 & 1.905
22 ± 0.002 & 0.05 0.031 & 0.79
12 ± 0.005 & 0.127 0.105 & 2.667
16 ± 0.004 & 0.102 0.059 & 1.499
20 ± 0.002 & 0.051 0.035 & 0.889
24 ± 0.002 & 0.05 0.025 & 0.64

Brushed Stainless Steel 304L Sheet Thermal Properties

Grade Thermal conductivity (W/m.K) Mean coefficient of thermal expansion (μm/m/°C) Specific Heat 0-100°C (J/kg.K)
at 500°C at 100°C 0-538°C 0-315°C 0-100°C
SS 304L 21.5 16.2 18.4 17.8 17.2 500

SUS 304L Perforated Plate Electrical Resistivity Properties

Temperature Microhm - cm Microhm - in.
°F °C
68 20 72 28.3
1112 600 111 43.7
392 200 86 33.8
1652 900 126 49.6
212 100 78 30.7
752 400 100 39.4
1472 800 121 47.6

AISI 304L Cold Rolled Plate Chemical Composition

Grade Carbon Sulfur Manganese Phosphorus Chromium Silicon Nickel
Stainless Steel 304L 0.035 (Max.) 0.030 (Max.) 2 (Max.) 0.045 (Max.) 18 - 20 1 (Max.) 8 - 13

Stainless Steel 304L Sheet Equivalent

Grade UNS Werkstoff NR. GOST JIS EN BS AFNOR
SS 304L S30403 1.4306 / 1.4307 03Х18Н11 SUS 304L X2CrNi18-9 / X2CrNi19-11 3304S11 Z3CN18‐10

SS 304L Coil Mechanical Properties

Grade Density Yield Strength (0.2%Offset) Tensile Strength Melting Point Elongation
Stainless Steel 304L Sheet 8.0 g/cm3 MPa - 205, Psi - 30000 MPa - 515, Psi - 75000 2550°F (1400°C) 35%

304L Stainless Steel Strip Physical Properties

Grade Electrical Resistivity Mean Coeff of Thermal Expansion (μm/m/ °C) Heat 0 to 100 °C Thermal Conductivity Modulus of Elastic
0 to 315 °C 0 to 100 °C 0 to 538 °C at 100 °C at 500 °C
304L 720 nΩ.m 17.8 17.2 18.4 500 J/kg.K 16.2 W/m.K 21.5 W/m.K 193 GPa

ASTM A240 TP 304L Chequered Plate Melting Point

Grade Melting point
304L 1400°C - 1450°C (2550°F - 2640°F)

AISI 304L Foil Machinability Charts

Cutting speed, sfm
Feed
( in / rev )		 Cutting depth
( in )		 C5 C6 C7 High speed Steel
< 0.012 0.08 – 620 780 95
0.020-0.040 0.20-0.40 260 295 – 50
0.012-0.020 0.08-0.20 460 560 – 80
