Inconel 600 Flanges

Inconel 600 Flanges

Inconel 600 Flanges Quick Overview
Size  1/2 to 48"
Schedule Sch 5 - XXS
Thread Types MNPT ,BSPT, NPT, BSPP
Pressure Class 150 Lbs - 2500 Lbs
Connection Flanged
Production method Casting,Forging, Rolling

ASTM B564 UNS N06600 Blind Flange Supplier in India

Inconel 600 Flange

Inconel 600 Flange

Inconel 600 Blind Flange

Inconel 600 Blind Flange

Alloy 600 Weld Neck Flange

Alloy 600 Weld Neck Flange

Table of Contents


Inconel 600 Flanges Specification

Inconel 600 Flanges Sizes

  • NPS: 1/2″ to 48″
  • SCH: Sch 5 - SCH XXS
  • Class : 5NB – 1500NB




Sizes

Alloy 600 Flanges Threads

  • NPT
  • FNPT, MNPT
  • BSPP
  • BSPT


Threads

Inconel 600 Forgings Standards

  • ASTM: B564 | ASME : SB564
  • UNS: N06600 | WNR: 2.4816
  • DIN 17742, BS 3072-3076 (NA14)
  • DIN 1775

Standards

UNS N06600 Weld Flanges Origin

  • Korean
  • European
  • Indian
  • Janpanese

Origin

DIN 2.4816 Hot Forged Flange Face Types

  • RTJ
  • RF
  • FF
  • T&G

Face Types

Nickel Alloy 600 Forged Pipe Flange Testing

  • Hardness test
  • Pressure
  • Tensile
  • PMI

Testing

Inconel 600 Blind Flange Types

  • Slip On
  • Weld Neck
  • Lap Joint Flange
  • Blind
  • Plate Flanges
  • Socket Weld


Types

Alloy 600 Weld Neck Flange Process

  • Rolling
  • Casting
  • Forging
  • Cutting




Process

DIN 2.4816 Slip On Flange EN type

  • EN-TYPE 01/12 (slip on)
  • EN-TYPE 11 (weld neck)
  • EN-TYPE 14 (socket weld)
  • EN-TYPE 02/04 (lap joint)
  • EN-TYPE 21 (long weld neck)
  • EN-TYPE 05 (blind)
  • EN-TYPE 13 (threaded)

Finish

Nickel Alloy 600 Reducing Flange Pressure Class

  • 150 Lbs
  • 300 Lbs
  • 600 Lbs
  • 900 Lbs
  • 1500 Lbs
  • 2500 Lbs


Pressure Class

ASTM B564 Inconel 600 Lap Joint Flange Markings

  • Manufacturers logo
  • ASTM standard
  • Origin of material
  • Pressure class
  • Grade
  • Sizes
  • Face type

Markings

Inconel N06600 Plate Flanges Approx Delivery time in UAE

  • 3-7 Days (from other countries)
  • 1-3 Days (from UAE suppliers)




Delivery

Alloy 600 Forged Flange Dimension

Inconel 600 Flanges Supplier in India , supplying corrosion-resistant material in various grades, Dimensions.

Nominal Pipe Size inches Inconel 600 Class 300
No.of Bolts Bolt Circle inches Diam.of Bolt Holes inches Diam.of Flange inches Diam.of Bolts inches
1/2 4 2-5/8 0.62 3-3/4 1/2
1 / 4 4 2-1 / 4 0.62 3 – 3/8 1/2
3/4 4 3-1 / 4 0.75 4-5/8 5/8
18 24 24-3/4 1.38 28 1-1 / 4
24 24 32 1.62 36 1-1/2
1-1 / 4 4 3-7/8 0.75 5-1 / 4 5/8
5 8 9-1 / 4 0.88 11 3/4
3-1/2 8 7-1 / 4 0.88 9 3/4
8 12 13 1 15 7/8
10 16 15-1 / 4 1.12 17-1/2 1
6 12 10-5/8 0.88 12-1/2 3/4
14 20 20-1 / 4 1.25 23 1-1/8
16 20 22-1/2 1.38 25-1/2 1-1 / 4
2-1/2 8 5-7/8 0.88 7-1/2 3/4
3 8 6-5/8 0.88 8-1 / 4 3/4
2 8 5 0.75 6-1/2 5/8
4 8 7-7/8 0.88 10 3/4
12 16 17-3/4 1.25 20-1/2 1-1/8
1-1/2 4 4-1/2 0.88 6-1/8 3/4
1 4 3-1/2 0.75 4-7/8 5/8
20 24 27 1.38 30-1/2 1-1 / 4

Nickel Alloy 600 Slip On Flange Manufacturer In Mumbai With MTC

Nickel Alloy 600 Slip On Size Chart

Normal Sizes In inch Dimension Inconel Flanges Dimensional Sizes
Class 400 Class 300 Class 125 Class 150 Class 1500 Class 900 Class 600 Class 2500
mm inch. millimeter inch. mm inch. mm inch. mm inch. mm inch. mm inch
1/2" D2 34.9 1 3/8 34.9 1 3/8 34.9 1 3/8 34.9 1 3/8 34.9 1 3/8 34.9 1 3/8 34.9 1 3/8
b 14.3 9/16 14.3 9/16 11.1 7/16 22.2 7/8 22.2 7/8 14.3 9/16 30.2 1 3/16
D1 66.7 2 5/8 66.7 2 5/8 60.3 2 3/8 82.6 3 1/4 82.6 3 1/4 66.7 2 5/8 88.9 3 1/2
A 95.2 3 3/4 95.2 3 3/4 88.9 3 1/2 121 4 3/4 121 4 3/4 95.2 3 3/4 133.4 5 1/4
d 15.9 5/8 15.9 5/8 15.9 5/8 22.2 7/8 22.2 7/8 15.9 5/8 22.2 7/8
n 4 4 4 4 4 4 - 4 4 4 4 4 44 4
1" D2 50.8 2 50.8 2 50.8 2 50.8 2 50.8 2 50.8 2 50.8 2
d 19 3/4 19 3/4 15.9 5/8 25.4 1 25.4 1 19 3/4 25.4 1
A 123.8 4 7/8 123.8 4 7/8 108 4 1/4 149.2 5 7/8 149.2 5 7/8 123.8 4 7/8 159 6 1/4
D1 88.9 3 1/2 88.9 3 1/2 79.4 3 1/8 102 4 102 4 88.9 3 1/2 108 4 1/4
b 17.5 11/16 17.5 11/16 14.3 9/16 28.6 1 1/8 28.6 1 1/8 17.5 11/16 34.9 1 3/8
n 4 4 4 4 4 4 4 4 4 4 4 4 4 4
1 1/2" A 155.6 6 1/8 155.6 6 1/8 127 5 177.8 7 177.8 7 155.6 6 1/8 203 8
b 22.2 7/8 20.6 13/16 17.5 11/16 31.8 1 1/4 31.8 1 1/4 22.2 7/8 44.5 1 3/4
n 4 4 4 4 4 4 4 4 4 4 4 4 4 4
D1 114 4 1/2 114 4 1/2 4 3 7/8 124 4 7/8 124 4 7/8 114 4 1/2 146 5 3/4
d 22.2 7/8 22.2 7/8 . 15.9 5/8 28.6 1 1/8 28.6 1 1/8 22.2 7/8 31.8 1 1/4
D2 73 2 7/8 73 2 7/8 73 98 2 7/8 73 2 7/8 73 2 7/8 73 2 7/8 73 2 7/8
2" d 19 3/4 19 3/4 19 3/4 25.4 1 25.4 1 19 3/4 28.6 1 1/8
A 165.1 6 1/2 165.1 6 1/2 152.4 6 215.9 8 1/2 215.9 8 1/2 165.1 6 1/2 234.9 9 1/4
n 8 8 8 8 4 4 8 8 8 8 8 8 8 8
D1 127 5 127 5 121 4 3/4 165.1 6 1/2 165.1 6 1/2 127 5 171 6 3/4
D2 92.1 3 5/8 92.1 3 5/8 92.1 3 5/8 92.1 3 5/8 92.1 3 5/8 92.1 3 5/8 92.1 3 5/8
b 25.4 1 22.2 7/8 19 3/4 38.1 1 1/2 38.1 1 1/2 25.4 1 50.8 2
2 1/2" D2 104.8 4 1/8 104.8 4 1/8 104.8 4 1/8 105 4 1/8 105 4 1/8 104.8 4 1/8 105 4 1/8
d 22.2 7/8 22.2 7/8 19 3/4 28.6 1 1/8 28.6 1 1/8 22.2 7/8 31.8 1 1/4
A 190.5 7 1/2 190.5 7 1/2 177.8 7 244 9 5/8 244 9 5/8 190.5 7 1/2 266.7 10 1/2
D1 149.2 5 7/8 149.2 5 7/8 139.7 5 1/2 190.5 7 1/2 190.5 7 1/2 149.2 5 7/8 197 7 3/4
n 8 8 8 8 4 4 8 8 8 8 8 8 8 8
b 28.6 1 1/8 25.4 1 22.2 7/8 41.3 1 5/8 41.3 1 5/8 28.6 1 1/8 57.2 2 1/4

DIN 2.4816 Hot Forged Flange Schedule Chart

Nominal Sizes Blind (BLRF ) Threaded (NPT) Loose (Lap Joint) Slip On (SORF) Socket Weld (SWRF) Weld Neck (WRNR)
3½" 13 12 11 11 11 12
18" 220 130 160 130 130 165
3" 9 9 9 9 9 11.5
16" 180 98 140 106 98 140
20" 285 165 195 165 165 197
6" 27 19 19 19 19 26
4" 17 13 13 13 13 16.5
22" 355 185 245 185 185 225
2" 5 5 5 5 5 6
1¼" 3 3 3 3 3 3
5" 20 15 15 15 15 21
8" 47 30 30 30 30 42
12" 123 64 64 64 64 88
14" 140 90 105 90 90 114
10" 70 43 43 43 43 54
1½" 4 3 3 3 3 4
2½" 7 8 8 8 8 10
½" 2 1 1 1 2 2
1" 2 2 2 2 2 3
¾" 2 2 2 2 2 2
24" 430 220 275 220 220 268

Stockist of ASTM B564 Inconel 600 WNRF Flange in 150# to 2500#

ASTM B564 Inconel 600 WNRF Flange Pressure Rating

Working Pressures in Bar
Temperature in °C CL 300 CL 400 CL 150
400 36.5 48.9 6.5
425 35.2 46.5 5.5
625 5.1 6.8 –
650 4.7 6.3 –
500 28.2 37.6 2.8
538 16.5 22.1 1.4
550 13.9 18.6 –
450 33.7 45.1 4.6
475 31.7 42.3 3.7
575 9.4 12.6 –
600 6.6 8.9 –
Working Pressures in Bar
Temperature in °C CL 1500 CL 2500 CL 600 CL 900
400 183.1 304.9 73.3 109.8
425 175.1 291.6 70.0 105.1
500 140.9 235.0 56.5 84.7
538 82.7 137.9 33.1 49.6
550 69.7 116.2 27.9 41.8
575 47.2 78.6 18.9 28.3
450 169.0 281.8 67.7 101.4
475 158.2 263.9 63.4 95.1
600 33.2 55.3 13.3 19.9
625 25.7 42.8 10.3 15.4
650 23.6 39.4 9.5 14.2
Working Pressures in PSIG
Temperature In °F 300# 400# 150#
-20 to 100 750 1,000 290
300 730 970 230
1,050 155 205 –
1,100 105 135 –
400 705 940 200
500 665 885 170
700 570 755 110
200 750 1,000 260
750 530 710 95
800 510 675 80
850 485 650 65
900 450 600 50
600 605 805 140
650 590 785 125
950 365 485 35
1,000 240 320 20
1,150 75 100 –
1,200 70 90 –
Working Pressures in PSIG
Temperature In °F 1500# 2500# 600# 900#
-20 to 100 3,750 6,250 1,500 2,250
400 3,530 5,880 1,410 2,115
500 3,325 5,540 1,330 1,995
600 3,025 5,040 1,210 1,815
650 2,940 4,905 1,175 1,765
200 3,750 6,250 1,500 2,250
900 2,245 3,745 900 1,350
1,100 515 855 205 310
300 3,640 6,070 1,455 2,185
700 2,840 4,730 1,135 1,705
750 2,660 4,430 1,065 1,595
950 1,815 3,030 725 1,090
1,000 1,200 2,000 480 720
1,050 770 1,285 310 465
800 2,540 4,230 1,015 1,525
850 2,435 4,060 975 1,460
1,150 375 630 150 225
1,200 345 570 135 205

Inconel 600 Blind Flange Tolerance

Inconel Flanges Tolerance
Diam.of contact face 1/16in raised face: ±1/32in
1 / 4in RF, T/G,: ±1/64in
OD OD is over 24in: ±1/8in
OD is 24in or less: ±1/16in
Drilling Bolts hole spacing: ±1/32in
Circle Bolts: ±1/16in
Bolt Circle with Respect to Facing Eccentricity 2 1/2in and smaller ±1/32in max
3in and larger ±1/16in max
ID 20in and larger: -1/16in
10in and smaller: ±1/32in
12in thru 18in: +1/8in
Length of hub 12in and larger: ±1/8in
10in and smaller: ±1/16in
Hub at Base Diameter hub base is over 24in: ±1/8in
hub base is 24in or smaller: ±1/16in
Hub At Point of Welding Diameter 5in and smaller: +3/32in, -1/32in
6in and larger: +5/32in, -1/32
Thickness 20in and larger: ±3/16in, -0in
18in and smaller: ±1/8in, -0in

Alloy 600 Weld Neck Flange Sizes & Ratings

Inconel 600 Flanges Manufacturer in India supplying custom sizes.

Dimension Standard Rating Size Range
MSS-SP-44 Flanges Class 150 - 900 Lbs 12” - 60”
ASME B16.48 / API 590 Flanges Class 150 - 2500 Lbs 1/2” - 24”
DIN Flanges PN6 - PN 160 DN10 - DN3600
BS 3293 Flanges Class 150 - 600 Lbs 26” - 48”
ASME / ANSI B16.36 Flanges Class 300 - 2500 Lbs 1” - 24”
ASME / ANSI B16.5 Flanges Class 150 - 2500 Lbs 1/2” - 24”
ASME B16.47 / API 605 Flanges – 26” - 60”
API 6A Flanges 2000 Psi - 20000 Psi 2 1/16” - 30”

ASTM B564 UNS N06600 Flanges Pitting and Crevice Corrosion

Grade Test of type Number of days % Mo PREa Max. depth (mm)
Inconel 600 Washers 30 0 16 34 (0.86)

What Types of Equipment Commonly Use Inconel Alloy 600 High Hub Blind Flanges?

What Types of Equipment Commonly Use Inconel Alloy 600 High Hub Blind Flanges?

SB 564 UNS N06600 Socket Weld Flange Weight Chart

Inconel 600 Flanges Supplier in India offers an Excellent Weight Chart.

Standard Class's Diameter Diameter of Bolt Hole Number of Bolts Bolt Size Bolt Circle Diameter
AS4087 PN14 95 14 4 M12 67
AS 2129 Flange Table C 95 13 67
Table F 95 13 67
Table E 95 13 67
Table D 95 13 67
Table J 114 17 16 83
Table H 114 17 16 83
ANSI B16.5 ANSI 150 89 16 13 60
ANSI 900 121 22 19 83
ANSI 600 95 16 13 67
ANSI 300 95 16 13 67
ANSI 1500 121 22 19 83
ISO 7005 (DIN) Flange PN6 80 11 M10 55
PN20 90 16 M14 60.5
PN16 95 14 M12 65
PN10 95 14 M12 65
PN40 95 14 M12 65
PN25 95 14 M12 65
Exporter Of Alloy 600 Lap Joint Flange According To DIN, JIS, ASTM Standard

Alloy 600 Lap Joint Flange Equivalent

STANDARD JIS UNS AFNOR GOST EN BS WERKSTOFF NR.
Inconel 600 NCF 600 N06600 NC15FE11M МНЖМц 28-2,5-1,5 NiCr15Fe NA13 2.4816

Nickel Alloy 600 Reducing Flange HSN Code

Grade HSN Code
Inconel 600 Flanges 75072000

Various Types Of Inconel 600 Flanges

Inconel 600 Flanges Supplier in India Offers a Variety of the Popular Types

UNS N06600 Socket Weld Flange

UNS N06600 Socket Weld Flange

ASTM B564 UNS N06600 Threaded Flange

ASTM B564 UNS N06600 Threaded Flange

DIN 2.4816 Slip on Flange

DIN 2.4816 Slip on Flange

Nickel Alloy 600 Reducing Flange

Nickel Alloy 600 Reducing Flange

ASTM B564 Inconel 600 Lap Joint Flange

ASTM B564 Inconel 600 Lap Joint Flange

Inconel N06600 Plate Flanges

Inconel N06600 Plate Flanges

ASTM B564 N06600 Flanges Gasket Chart

Gasket ID Size Gasket OD
150 LB 600 LB 300 LB 900 LB 400 LB
6.62 6 8.75 10.5 9.875 11.375 9.75
8.62 8 11 12.625 12.125 14.125 12
4.5 4 6.875 7.625 7.125 8.125 7
5.56 5 7.75 9.5 8.5 9.75 8.375
12.75 12 16.125 18 16.625 19.625 16.5
10.75 10 13.375 15.75 14.25 17.125 14.125
1.31 1 2.625 2.875 2.875 3.125 2.875
1.66 1.25 3 3.25 3.25 3.5 3.25
1.91 1.5 3.375 3.75 3.75 3.875 3.75
2.38 2 4.125 4.375 4.375 5.625 4.375
2.88 2.5 4.875 5.125 5.125 6.5 5.125
3.5 3 5.375 5.875 5.875 6.625 5.875

Inconel 2.4816 Blind Flange Thickness

Size Weld Neck Slip On Threaded Lap Joint Socket Weld Blind
1 3 2 2 2 2 2
1¼ 3 3 3 3 3 3
¾ 2 2 2 2 2 2
2½ 10 8 8 8 8 7
4 16.5 13 13 13 13 17
3 11.5 9 9 9 9 9
5 21 15 15 15 15 20
6 26 19 19 19 19 27
½ 2 1 1 1 2 2
8 42 30 30 30 30 47
10 54 43 43 43 43 70
1½ 4 3 3 3 3 4
2 6 5 5 5 5 5
3½ 12 11 12 11 11 13
12 88 64 64 64 64 123
18 165 130 130 160 130 220
14 114 90 90 105 90 140
20 197 165 165 195 165 285
16 140 106 98 140 98 180
22 225 185 185 245 185 355
24 268 220 220 275 220 430

Ni Alloy 600 Socket Weld Flange Corrosion Tests

Grade Inconel 600 Flanges
Temperature 500°C To 600°C
Test Duration 36 Hours
Tests Hydrogen Fluoride Gas
Corrosion Rate, mpy 0.7

Inconel 6600 Weld Neck Flange Tensile Requirements

Temperature Tensile Requirements
1200°F 119,000 PSI
1600°F 40,000 PSI
600°F 132,000 PSI
1000°F 130,000 PSI
1400°F 78,000 PSI
70°F 144,000 PSI
400°F 134,000 PSI
800°F 131,500 PSI

Inconel 600 Forgings Applications

Inconel 600 Forgings Applications
SB 564 N06600 Plate Flange Distributor Provide Custom Third Party Inspection As Per Need

SB 564 N06600 Plate Flange Documentation

  • Welding Procedure Specification
  • Guarantee Letter
  • Material Test Certificates
  • Test Certificates certifying
  • Heat Treatment Charts
  • Third Party Inspection
  • Quality Assurance Plan
  • Material Traceability Records
  • Raw Material Test Reports

UNS N06600 Weld Flanges Chemical Composition

Grade Carbon Chromium Nickel Silicon Sulfur Copper Manganese Iron
Inconel 600 0.15 14-17 72 0.50 0.015 0.5 1.00 6-10

Inconel 600 Blind Flange Mechanical Properties

Grade Tensile Strength Elongation Yield Strength (0.2%Offset)
(per square inch) (megapascal) % (per square inch) (megapascal)
Inconel 600 95000 655 40 45000 310

Alloy 600 Weld Neck Flange Physical Properties

Element Density Tensile Strength Melting Point Elongation Yield Strength (0.2%Offset)
g/cm3 (megapascal) (per square inch) °Celsius °Fahrenheit % (megapascal) (per square inch)
Inconel 600 8.47 655 95000 1413 2580 40 310 45000

What Are The Inspection Methods Of Inconel 600 Pipe Flanges ?

  • Impact Test
  • Shell Pressure Test
  • Material Test
  • Tensile Test
  • Hardness Test

Offer ASTM B564 N06600 Flanges to the various Countries

Country Name Flag Country Name Flag
Algeria Algeria Nigeria Nigeria
Zambia Zambia Ghana Ghana
UAE Tunisia South Africa South Africa
Kenya Kenya Angola Angola
Tanzania Tanzania Morocco Morocco
Egypt Egypt Ethiopia Ethiopia
